Capresso Espresso Ultima 121 User Manual

Jura espresso ultima 121: user guide
Hide thumbs Also See for Espresso Ultima 121:
Table of Contents

Advertisement

Quick Links

1
2
3
4
5
6
7
8a
8b
9
10
11
fig. 2
fig. 1
1 Knob
2 Handle Bar
3 LEVER
4 Carousel (removable)
5 Funnel for coffee (removable)
6 Operating Panel
fig 1.1
6a Main On/Off Switch (illuminated)
6b Pump On/Off Switch
6c Red Indicator Light (empty coffee
container / tray missing)
6d Thermostat Light (yellow)
fig. 1
fig. 1.1
6a
16
6b
15
6c
6d
14
13
fig. 1.2
7c
12
7b
7a
10b
fig. 1.3
10b
10c
10a
7 Selector Switch
fig 1.2
7a Coffee Position (spout)
7b Hot Water Position
7c Steam/Frothing Position
8 Frother
8a Cylinder (movable)
8b Frother Tip (removable)
9 Grid (removable)
10 Tray (removable)
fig 1.3
10a Tray Base
10b Overflow Indicator
10c Used Coffee Container
11 Measuring Scoop
12 Dual Coffee Spout (height-adjustable)
13 Tab to move spout up and down
14 Water Tank (removable)
15 Lid for Water Tank
16 Lid for Coffee Funnel

Advertisement

Table of Contents
loading

Related Manuals for Capresso Espresso Ultima 121

Summary of Contents for Capresso Espresso Ultima 121

  • Page 1 fig. 1 fig. 2 fig. 1 1 Knob 2 Handle Bar 3 LEVER 4 Carousel (removable) 5 Funnel for coffee (removable) 6 Operating Panel fig 1.1 6a Main On/Off Switch (illuminated) 6b Pump On/Off Switch 6c Red Indicator Light (empty coffee container / tray missing) 6d Thermostat Light (yellow) fig.
  • Page 2 First squeeze Then raise or lower rotate counter clockwise only First squeeze Then raise or lower fig. 3 fig. 4 fig. 5 fig. 6 fig. 7 fig. 8 fig. 8a fig. 9...
  • Page 3 Steam Froth fig. 11 fig. 10 fig. 10a fig. 10b fig. 12 fig. 12a fig. 12 b fig. 15 fig. 13b fig. 16 fig. 13 fig. 14 fig. 17...

  • Page 4: Table Of Contents

    Contents Chapters Page 1. EQUIPMENT ...4 2. PLEASE DO NOT...4 3. CAPRESSO Plus Service™ ...4 4. AFTER UNPACKING ...4 5. WORKING WITH THE CAROUSEL ...4-5 6. INITIAL PREPARATION ...5 7. HOW THE THERMOSTAT LIGHT WORKS ...5 8. WHICH COFFEE GRIND? ...5-6 9.

  • Page 5: Equipment

    1. EQUIPMENT The CAPRESSO "Ultima" (#121) comes with the following parts: • Coffee Scoop • Removable tray with grid, internal used coffee container and overflow indicator • Removable water container with lid • Removable coffee funnel insert with lid • Mail Order Insert 2.

  • Page 6: Initial Preparation

    e. When the lever is raised you can turn the carousel counter clockwise indefinitely. Just hold the knob and turn the carousel (see fig. 6) f. The carousel has two positions with an audible "click": • lever in front of machine (see fig. 5) •...

  • Page 7: Beverages

    no or hardly any coffee comes out of the spout, then your coffee is ground too fine. 9. BEVERAGES... BEVERAGES... The Capresso "Ultima" lets you pro- duce the following beverages: • Espresso (coffee spout) 1 to 1 1/2 oz. per cup; make one or two cups at a time.

  • Page 8: Making Cappuccino (Frothing Milk)

    k. Raise the lever and turn the knob counter clockwise until the funnel is in front of the machine again (fig 8). You are now ready to make more espresso. (While turning the caro- usel the used coffee is automatically thrown into the internal used coffee container).

  • Page 9: Cleaning The Frother Immediately

    selector switch back to the spout symbol. 13. CLEANING THE FROTHER IMMEDIATELY If you clean the frother immediately after frothing, it will be faster and eas- ier than at a later time, when the milk has hardened around the tip. a.

  • Page 10: Overflow Water Indicator

    15.2 OVERFLOW WATER INDICATOR (fig. 13b) After brewing coffee, the machine automatically releases the pressure of the brewing chamber together with some water into the tray. If too much water collects in the tray the little red indicator will pop up. Pull out the tray, remove the used coffee container and the water level indicator.

  • Page 11: What If

    16. WHAT IF a. No water comes through the coffee spout • Make sure the water tank is inserted properly and water is in the water tank. • Make sure the lever points towards the front of the machine and is in the closed position.
  • Page 12 f. Can I use the machine overseas with a converter? No. The machine is designed for 120 volts / 60 Hz. Other voltage and Hz levels might damage the machine. g. Can I send a machine to another country with 120 volt / 60 Hz configuration.
