Limited Lifetime Warranty - Juniper EX 3200 24T Specifications

Carrier-Class Operating System
The EX3200 runs the same Junos OS used by Juniper Networks
routers to power the world's largest and most complex networks.
By utilizing a common operating system, Juniper delivers a
consistent implementation and operation of control-plane features
across all products—functions ranging from chassis management
to spanning tree to OSPF. To maintain that consistency, Junos OS
adheres to a highly disciplined development process that utilizes
a single source code, follows a single quarterly release train, and
employs a highly available modular architecture that prevents
isolated failures from bringing an entire system down.
These attributes are fundamental to the core value of the
software, enabling all products powered by the Junos OS—routers
and switches—to be updated simultaneously with the same
software release. All features, new and old, are fully regression-
tested, making each new release a true superset of the previous
version. Customers can deploy a new Junos OS release with
complete confidence that all existing capabilities will operate in
the same way and be compatible on all Juniper Networks switches
and routers in the network.
9.4
J Series
TX Matrix
One OS One Release
Figure 2: Junos OS utilizes a single source code, adheres to a
consistent and predictable release train, and employs a single
modular architecture.
Converged Environments
The EX3200 provides the highest levels of availability in their
class for the most demanding converged data, voice and video
environments, delivering a reliable platform for unifying enterprise
communications.
By providing a full 15.4 watts of Class 3 PoE to power voice over
IP (VoIP) telephones, closed-circuit security cameras, wireless
access points and other IP-enabled devices, the EX3200 delivers
a future-proofed solution for converging disparate networks onto
a single IP infrastructure. The base system, which offers eight PoE
ports, lowers the cost and complexity of designing the access layer
by supporting a small number of WLAN access points or IP phones
rather than requiring the purchase of PoE on all 24 or 48 ports.
To ease deployment, the EX3200 supports the industry-standard
Link Layer Discovery Protocol (LLDP) and LLDP-Media
Endpoint Discovery (LLDP-MED) protocol, enabling the switches to
automatically discover Ethernet-enabled devices, determine their
power requirements, and assign virtual LAN (VLAN) membership.
In addition, the EX3200 supports rich quality of service (QoS)
functionality for prioritizing data, voice and video traffic. The
switches support eight class-of-service (CoS) queues on every
port, enabling them to maintain multi-level, end-to-end traffic
prioritizations. The EX3200 also supports a wide range of policy
options, including strict priority, low-latency, weighted random
early drop (WRED) and shaped deficit weighted round-robin
(SDWRR) queuing.
9.5 9.6
Frequent Releases
One Architecture
Security
The EX3200 fully integrates with the Juniper Networks Unified
Access Control (UAC), which consolidates all aspects of a user's
identity, device and location. This enables administrators to enforce
access control and security down to the individual port or user levels.
Working as an enforcement point within UAC, the EX3200
provides both standards-based 802.1X port-level access
control for multiple devices per port, as well as Layer 2-4 policy
enforcement based on user identity, location and/or device. A
user's identity, device type, machine posture check and location
can be used to determine whether access should be granted and
for how long. If access is granted, the switch assigns the user's
device to a specific VLAN based on authorization policy. The
switch can also apply security and/or QoS policies, or it can mirror
user traffic to a central location for logging, monitoring or threat
detection by intrusion prevention systems.
The EX3200 also provides a full complement of integrated port
security and threat detection features, including DHCP (Dynamic
Host Configuration Protocol) snooping, DAI (Dynamic ARP
Inspection) and MAC limiting to defend against internal and external
spoofing, man-in-the-middle and denial-of-service (DoS) attacks.
Simplified Management and Operations
Module
The EX3200 includes port profiles that allow network
X
administrators to automatically configure ports with security, QoS
and other parameters based on the type of device connected to
the port. Six preconfigured profiles are available, including default,
desktop, desktop plus IP phone, WLAN access point, routed uplink
and Layer 2 uplink. Users can select from the existing profiles
or create their own and apply them through the command line
interface (CLI), J-Web interface or management system.
Four system management options are available for the
EX3200 line of Ethernet switches. The standard Junos OS CLI
management interface offers the same granular capabilities and
scripting parameters found in any router powered by Junos OS.
The EX3200 also includes the integrated J-Web management tool,
an embedded Web-based device manager that allows users to
configure, monitor, troubleshoot and perform system maintenance
on individual switches via a browser-based graphical interface.
When managing a group of EX3200 line of Ethernet switches, the
Juniper Networks Network and Security Manager (NSM) provides
system-level management across all Juniper switches in the
network from a single console.
Finally, the EX3200 configuration, fault, and performance data
can be exported to leading third-party management systems such
as HP OpenView, IBM Tivoli and Computer Associates Unicenter
software, to provide a complete, consolidated view of network
operations.

Limited Lifetime Warranty

The EX3200 includes a limited lifetime hardware warranty that
provides return-to-factory switch replacement for as long as the
original purchaser owns the product. Power supplies and fan trays
are covered for a period of five years. For complete details please
visit www.juniper.net/support/warranty/.
3
