Lenovo ThinkSystem ST250 V2 Quick Start

ThinkSystem ST250 V2
Type 7D8F and 7D8G
Quick Start
In the box
• ST250 V2
• Material box, including printed documentation
If any item is missing or damaged, contact your place of
purchase. Ensure that you retain your proof of purchase
and packing material. They might be required to receive
warranty service.
Depending on the configuration, the illustrations in this
document might differ slightly from your server.
First glance
Server front view
Server front panel
1
Power button with power
status LED (green)
2
Drive activity LED (green)
3
Network activity LED
(green)
4
System ID button with
system ID LED (blue)
1
Front panel
2
Optical-drive bay 2
3
Optical-drive bay 1
4 5
Storage drive bays
5
System error LED
(yellow)
6
XClarity Controller
USB 2.0 connector
7
USB 3.2 Gen 1
connector
Server rear view
Setting up the system
1. Install the required components.
2. Install the server into the rack if necessary.
3. Connect the cables.
4. Power on the server.
5. Configure the system
For detailed information about installing hardware options
and configuring the system, see the following website:
https://thinksystem.lenovofiles.com/help/topic/st250-v2/
introduction.html
For the Rail Installation Guide that is provided on
ThinkSystem Documentation Center, see the following
website: https://thinksystem.lenovofiles.com/help/topic/
rail_options/rail_options_tower_servers.html
1
Power cord connector
2
VGA connector
3
Serial connector
4
Dedicated XClarity
Controller (XCC) network
connector
5
Ethernet 1 connector
(shared with XCC
network port)
6
Ethernet 2 connector
7
USB 3.2 Gen 2
connectors
8
USB 3.2 Gen 2
connectors
9
PCIe slots
1 1
