Operational Notes - Emerson PACSystems RX3i PROFINET Scanner Important Product Information

GFK-2738AB
Description
Subject
Feature
The following minimum backplane hardware revision must be used:
or
RX3i backplane
hardware
or
When installing, operating, or maintaining the PNS, personnel must ensure any electrostatic charge is
discharged through the use of a grounded ESD strap or other means.
For new installations using AC power supplies, the PNS requires an IC695PSA040H or IC695PSA140D (or
higher) revision power supply to ensure compatibility.
Rx3i AC Power
Supply
For retrofit installations using AC power supplies, the PNS may require an IC695PSA040H or IC695PSA140D (or
higher) revision power supply depending on the total current load in the backplane. If the total current load
Compatibility
exceeds the existing power supply's minimum current threshold, no power supply change is required.
IC695SPC100A or later
Small form-
IC695SPF002A or later
factor pluggable
IC695SPF550A or later
modules
IC695SPF010A or later
For a complete list, refer to
RX3i modules
Supported Modules, Power Supplies, and Backplanes.
Restrictions and Open Issues
Subject
None

Operational Notes

Subject
Invalid Module Configurations
will cause the respective RX3i
I/O module to fail configuration
IC695CHS012-BAMP
IC695CHS012CA-BAMP
IC695CHS012-CA (or later)
IC695CHS012CA-CA (or later)
IC695CHS007-AA (or later)
N/A
Description
When the PNS rejects the configuration of an individual I/O module, that
configuration is not delivered to the I/O module, leaving the module in an un-
configured state. In many modules, this is indicated by the OK Led on the I/O
Module blinking. In addition, I/O point faults will be asserted for that module's I/O.
Correct the configuration of the I/O module and store HWC again.
Refer to the section entitled RX3i PROFINET Scanner Configuration Validation in
PACSystems RX3i PROFINET Scanner Manual, GFK-2737.
Minimum PNS Version Required
IC695CHS016-BAMP
IC695CHS016CA-BAMP
IC695CHS016-CA (or later)
IC695CHS016CA-CA (or later)
Description
Jul 2022
Minimum Version Required
