DT-R24L4D
DT-R17L4D
MULTI FORMAT LCD MONITOR
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
CAUTION: To reduce the risk of electric shock. Do
not remove cover (or back). No user
serviceable parts inside. Refer servicing
to qualified service personnel.
The illustration of the monitor is of DT-R24L4D.
The lightning flash with arrowhead
symbol, within an equilateral triangle is
intended to alert the user to the presence
of uninsulated "dangerous voltage"
within the product's enclosure that may
be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
INSTRUCTIONS
EN
Advertisement
Table of Contents
Related Manuals for JVC DT-R17L4DU
Summary of Contents for JVC DT-R17L4DU
- Page 1 (or back). No user serviceable parts inside. Refer servicing to qualified service personnel. INSTRUCTIONS The illustration of the monitor is of DT-R24L4D. The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...
-
Page 2: Table Of Contents
Table of Contents Safety Precautions IMPORTANT SAFEGUARDS ... 3 Caution for use of the product for many hours... 5 Caution for use of the product in the high temperature ... 5 Maintenance ... 5 Installation Connections Rear panel ... 8 Daily Operations Front panel ... -
Page 3: Safety Precautions
Safety Precautions WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS. IMPORTANT SAFEGUARDS Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety. -
Page 4: Important Safety Instructions
FCC NOTICE CAUTION: Changes or modifi cations not approved by JVC could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 5: Caution For Use Of The Product For Many Hours
Caution for use of the product for many hours In the case that you use the monitor for many hours, we recommend that you set “NO SYNC ACTION” in “SYNC FUNCTION” to “P.SAVE” in MAIN MENU. This will reduce power consumption and relieve strain on the monitor. -
Page 6: Installation
Do not touch the LCD panel when installing the monitor. • Be sure to install the monitor securely to prevent the monitor from falling over, which may cause damage to the monitor or injury. To install the monitor on a shelf or any other... - Page 7 • The monitor should be mounted to a wall that can adequately hold the total weight of the monitor and stand over a long period of time and which can adequately withstand earthquakes, conceivable vibrations, and other external forces.
-
Page 8: Connections
Turns AC power on or off. • You need to press button (☞ t on page 10) to use the monitor after turning on the POWER switch. 2 AC IN terminal AC power input connector. Connect the provided AC power cord to an AC outlet. -
Page 9: Attaching The Power Cord Holder
AUDIO HD/SD SDI (IN 1 or IN 2) input terminal. • The signal is output from this terminal only when the monitor is on or in “P.SAVE” (power save) mode (☞ “NO SYNC ACTION” on page 15). • The EMBEDDED AUDIO signal... -
Page 10: Daily Operations
(power save) mode. (☞ “NO SYNC ACTION” in “SYNC FUNCTION” on page 15) button Turns on and off (on standby) the monitor. • The power switch is equipped on the rear panel of the monitor (☞ 1 on page 8). - Page 11 Audio Channel Selection Select audio channels emitted from the speakers (L/R) and the AUDIO ASSIGN (DT-R24L4D) / AUDIO (DT-R17L4D) (MONITOR OUT) (OUT1(L)/OUT2(R)) terminals, when EMBEDDED AUDIO signals come in to the E. AUDIO HD/SD SDI terminal (IN1 or IN2) and SDI input (1 or 2) is selected.
-
Page 12: Menu Configuration
Menu Confi guration The operation procedure Display the menu. To display the MAIN MENU Press MENU button. To display the SET-UP MENU Press button while holding button. Press buttons to select an item, then press • For some items, adjustments will be made by pressing Press buttons to select an item, then press Press MENU button to fi... -
Page 13: Main Menu
MAIN MENU PICTURE FUNCTION Setting for the picture quality Item To do APERTURE Activates/deactivates the function at the level set in “APERTURE LEVEL.” APERTURE LEVEL Compensate the frequency response of the luminance signal of the video signal. 01 – 10 Adjust the clearness of the outlines of the chrominance signal. -
Page 14: Audio Setting
Menu Confi guration (cont.) MARKER *1*2 Settings for marker functions Item To do R-AREA MARKER Activate/deactivate the area marker and select the style of it. R-MARKER ASPECT Select the aspect ratio of the area marker. R-SAFETY MARKER Activate/deactivate the safety marker and select the style of it. R-SAFETY AREA Adjust the area of the safety marker. -
Page 15: Set-Up Menu
Setting for the color reproduction range. (DT-R24L4D only) ITU-709: The monitor displays using a color gamut conforming to ITU-R BT.709. Adobe: The monitor displays using a color gamut suitable for Adobe RGB. The coverage is about 98%. PICTURE SUB ADJ. - Page 16 Menu Confi guration (cont.) SIZE/POSI. ADJ. Adjusts the size and position of the picture. Item To do H SIZE Adjust the horizontal picture size. H POSITION Adjust the horizontal picture position. V SIZE Adjust the vertical picture size. V POSITION Adjust the vertical picture position.
- Page 17 Display the model name of the monitor. VERSION Display the version of the monitor. HOUR METER Display the total hours of use (unit: hour). This item is used for maintenance of the monitor. You cannot reset this item. Memorized for each input. Ancillary time code CONTROL LOCK Setting value: OFF, VOL.LOCK, ALL LOCK...
-
Page 18: External Control
You can use external control even when “CONTROL LOCK” is set to “VOL.LOCK” or “ALL LOCK” (☞ page 17). • When the monitor is off (on standby), external control is not available. But certain external controls (starting/terminating communication, turning on the monitor) are available through the serial communication (☞... - Page 19 <Functions controlled by the MAKE/TRIGGER system> Display Functions to be controlled TALLY SEL Selects the color of the tally lamp. SDI 1 Changes the input to “SDI 1.” SDI 2 Changes the input to “SDI 2.” Changes the input to “DVI.” VIDEO 1 Changes the input to “VIDEO 1.”...
-
Page 20: Using The Serial Communication
External Control (cont.) Using the serial communication You can control the monitor from a personal computer etc. via the RS-485 or RS-232C terminal. • Consult your dealer for the details of the external control specifi cation. <Communication specifi cations> Input terminal... - Page 21 (No. 13) can be used while the monitor is off (on standby). Enter the monitor’s ID for “ **.” The initial setting of the monitor’s ID is “00.” When connecting several monitors, “00” is a command for controlling all monitors at once.
-
Page 22: Troubleshooting
Troubleshooting Solutions to common problems related to the monitor are described here. If none of the solutions presented here solve the problem, unplug the monitor and consult an authorized dealer or service center. Symptom No power supply No picture with the power on No sound “OTHERS”... -
Page 23: Self-Check Program
Contact your dealer with the information about which lamps were fl ashing. • If you turn on the monitor soon after turning it off (or after a short-term power failure), the INPUT SELECT lamps may fl ash and no image may be displayed. -
Page 24: Specifications
Specifi cations General Model name Type Multi format LCD monitor Screen size Type 24 wide format Aspect ratio 16:10 Horizontal/vertical frequency H: 31.469 kHz – 75.000 kHz (computer signal) V: 48 Hz – 65 Hz * Some signals within this frequency range may not be displayed (“Out of range” is displayed). -
