Rinnai MON3H07B Operation Manual

Multi split type air conditioner

Hide thumbs Also See for MON3H07B:

Installation manual (32 pages)

Installation manual (56 pages)

Installation manual (44 pages)

Table Of Contents

Table of Contents

Quick Links

Download this manual

Rinnai Inverter Multi Split System Models

Outdoor

MON3H07B

MON4H09B

MON5H11B

Multi Split Type Air Conditioner

Operation Manual

Indoor Wall

Indoor Ducted

HINRP20M

DINSD26MB

HINRP26M

DINSD35MB

HINRP35M

DINSD50MB

HINRP50M

DINSD70MB

HINRP60M

HINRP70M

Indoor Cassette

CIN020MB

CIN026MB

CIN035MB

CIN050MB

REFRIGERANT

R32

Table of Contents

Summary of Contents for Rinnai MON3H07B

Page 1 Rinnai Inverter Multi Split System Models REFRIGERANT Outdoor Indoor Wall Indoor Ducted Indoor Cassette MON3H07B HINRP20M DINSD26MB CIN020MB MON4H09B HINRP26M DINSD35MB CIN026MB MON5H11B HINRP35M DINSD50MB CIN035MB HINRP50M DINSD70MB CIN050MB HINRP60M HINRP70M Multi Split Type Air Conditioner Operation Manual...
Page 2 The design and specifications are subject to change without prior notice for product improvement. Consult with the Dealer or manufacturer for details. Any updates to the manual will be uploaded to the service website, please check for the latest version. Rinnai Multi Split Type AC OM...
Page 3: Table Of Contents
Save a Service Call �� 20 Troubleshooting Tips �� 21 When to Call for Service �� 22 Disposal Guidelines �� 22 Warranty Contacts PLEASE REFER TO ANY OPERATING MANUALS AND USER OPERATING GUIDES ACCOMPANYING ANCILLARY EQUIPMENT (WHERE FITTED) IMPORTANT Rinnai Multi Split Type AC OM...
Page 4: Warnings And Important Information
-25°C ~ 30°C WARRANTY EXCLUSIONS Rinnai product warranty excludes faults and failures caused by improper use and abuse; fair wear and tear; or failure to follow instructions regarding service and maintenance. It is very important that you maintain your appliance and have it serviced regularly. It is a condition of warranty that you adhere to the maintenance and service requirements as set out in this manual.
Page 5: Safety Precautions
CLEANING AND MAINTENANCE WARNINGS Turn o the device and disconnect the power before cleaning. Failure to do so can cause • electrical shock. Do not clean the air conditioner with excessive amounts of water. •   Rinnai Multi Split Type AC OM...
Page 6 A NOTE ON ILLUSTRATIONS The illustrations used in this manual are for explanatory purposes only and the shape of your indoor unit NOTE may vary slightly from that which is shown in this manual. Rinnai Multi Split Type AC OM  ...
Page 7 WARNING for Using R32 Refrigerant For R32 frigerant models: X m² X m² Appliance shall not be installed in an unventilated space, if that space is smaller than (Please see the following page). Rinnai Multi Split Type AC OM  ...
Page 8 For safety and warranty purposes, appliances that may be damaged or incorrect MUST NOT be installed or operated under any circumstances. Installation of damaged or incorrect appliances may contravene local government regulations. Rinnai disclaims any liability or responsibility whatsoever in relation to the installation or operation of damaged or incorrect appliances.
Page 9: Operation
Outdoor unit 6. Drain hose, refrigerant connecting pipe 10. Drain hose, refrigerant connecting pipe 7. Connective cable 11. Connective cable 8. Stop valve 12. Stop valve 9. Fan hood 13. Fan hood   Rinnai Multi Split Type AC OM...
Page 10 2. Drain hose 3. Air outlet 4. Air inlet 5. Air-in grill 6. Display panel 7. Remote controller Outdoor unit 8. Refrigerant connecting pipe 9. Connective cable 10. Stop valve 11. Fan hood Rinnai Multi Split Type AC OM  ...
Page 11: Operating Temperature
Keep doors and windows closed. • Limit energy usage by using TIMER ON and TIMER OFF functions. • Do not block air inlets or outlets. • Regularly inspect and clean air lters. •   Rinnai Multi Split Type AC OM...
Page 12: Features
ON/OFF button on the smoke. remote control. If the system has an auto restart function, the unit will restart using the same settings.   Rinnai Multi Split Type AC OM...
Page 13: Energy Saving Tips
Closing curtains during heating also Doors and windows should be helps keep the heat in kept closed Closing curtains during heating also Doors and windows should be helps keep the heat in kept closed   Rinnai Multi Split Type AC OM  ...
Page 14: Manual Operation - Mode Selection
RECOMMENDED For units that feature an electric heater, when the outside ambient temperature is below 0°C, it is strongly recommended that you to keep the machine plugged in so as to guarantee smooth operation. Rinnai Multi Split Type AC OM...
Page 15: Care & Maintenance
NOTE when operated in cooling mode during humid conditions. For replacement filters, please contact Rinnai. Turn off the power before you perform any maintenance; otherwise it may cause electric shock.
Page 16: Cleaning The Outdoor Unit
Check that the wiring is not broken off or disconnected. • Check that the air filter is installed. • Make sure nothing is blocking all air inlets and outlets of both the indoor or outdoor units Rinnai Multi Split Type AC OM...
Page 17: Installation Record - Installer Details
Please ensure you register your product warranty on line at rinnai.com.au. The Rinnai Customer Care Program is designed to help you get the most out of your new system. Service and maintenance in accordance with the Service Maintenance Schedules on page 18 and page 19 are essential in ensuring the prolonged useful life of your system, and help ensure it operates at optimum efficiency.
Page 18: Service Maintenance Schedule - Non Ducted Air Conditioning Systems
SERVICE MAINTENANCE SCHEDULE - NON DUCTED AIR CONDITIONING SYSTEMS Your Rinnai Air Conditioning System should be maintained annually after the date of installation by a qualified licensed technician in accordance with the Schedule below. Failure to do so during the product warranty period may void your warranty.
Page 19: Service Maintenance Schedule - Ducted Air Conditioning Systems
SERVICE MAINTENANCE SCHEDULE - DUCTED AIR CONDITIONING SYSTEMS Your Rinnai Ducted Air Conditioning System should be maintained annually after the date of installation by a qualified licensed technician in accordance with the Schedule below. Failure to do so during the product warranty period may void your warranty.
Page 20: Save A Service Call
The unit’s filters have become mouldy and should be cleaned. The fan of the outdoor unit does not During operation, the fan speed is controlled to optimise operate. performance. Rinnai Multi Split Type AC OM...
Page 21: Troubleshooting Tips
Cold air is entering through doors and Make sure that all doors and windows windows are closed during use Low refrigerant due to leak or long- Check for leaks, re-seal if necessary and term use top off refrigerant Rinnai Multi Split Type AC OM...
Page 22: When To Call For Service
• If the unit has been exposed to flooding DO NOT ATTEMPT TO FIX THESE YOURSELF! TURN OFF THE AIR CONDITIONER, AND CONTACT RINNAI OR AN AUTHORISED SERVICE PROVIDER IMMEDIATELY. DISPOSAL GUIDELINES This appliance contains refrigerant and other potentially hazardous materials. When disposing of this appliance, the law requires special collection and treatment.
Page 23: Warranty
WARRANTY TERMS OF WARRANTY – AUSTRALIA Rinnai Australia Pty. Ltd. ABN 74 005 138 769, 100 Atlantic Drive, Keysborough VIC 3173. NOTICE TO CONSUMERS UNDER AUSTRALIAN CONSUMER LAW Our goods and services come with guarantees that cannot be excluded under the Australian Consumer Law.
Page 24 Normal Business Hours by an Authorised Service Representative. Repair by persons other than an Authorised Service Representatives may void the Warranty. 2.4 Alternatively to clause 2.3 above, Rinnai can at its discretion elect to pay you an amount equivalent to the cost of repairing or replacing the Product.
Page 25 Service or Owner’s Manual; b) complies with clause 7 “Purchaser’s Responsibilities” page 26; c) notifies Rinnai within 30 days of a defect occurring or, in the case of a latent defect, becoming apparent, that a claim is being made under this Warranty; and d) provides, in support of the claim made under this Warranty, a Proof of Purchase.
Page 26 Rinnai to enquire about alternative arrangements. If you wish to make a warranty claim in respect of any fixed Product, please contact Rinnai on the details set out below to make arrangements for an Authorised Service Representative to inspect the product.
Page 27 NOTES Rinnai Multi Split Type AC OM...
Page 28: Contacts
Monday to Friday, 8.00 am to 5.00 pm EST. *Cost of a local call may be higher from a mobile phone. (National calls from public phones in Australia are free.) For further information visit www.rinnai.com.au or email enquiry@rinnai.com.au innai has a Service and Spare Parts network with...
