Location And Installation - Beko CLEARPOINT V 80 Installation And Operation Manual

4.2

Location and Installation

Serious consideration should be given when selecting the installation site for the carbon
tower, as an improper location could directly affect the proper operation of the carbon tower.
This unit is not suitable to be used in explosive atmospheres, where risk of fire could exist, in
the presence of gaseous or solid pollutants or in outdoor applications or areas exposed to the
elements.
Do not use water to extinguish fire on the unit or in the surrounding area.
Machine level noise at the area of installation could be higher than 85 dBA. Install the unit
in a dedicated area where people are not normally present. The installer and/or end user is
responsible to install proper safety signs at the installation site.
Technicians servicing the carbon tower in an area with excessive noise must wear hearing and
eye protection. Each employee must select a proper personal protection device (PPD) hearing
protector such as earmuffs, ear canal caps, or earplugs in order to prevent permanent hearing
damage or loss.
Minimum Installation Requirements:
+ Select a clean, dry room that is free of dust and protected from atmospheric disturbances.
+ The foundation must be smooth, horizontally level, able to bear the weight of the carbon tower and
be vibration free
+ The location area must fall within the ambient conditions as listed in section 3
+ Allow a clearance of at least 3ft on all sides of the carbon tower in order easily facilitate all
maintenance needs
+ While recommended, the carbon tower is not required to be anchored to the supporting surface
+ An upstream dryer and filtration must be installed
+ The location of an air receiver tank will vary depending on compressor type and application
Incorrect installation may void warranty.
NOTE: All piping connections should be inspected prior to installation to ensure they have
maintained their integrity during shipping and locating the unit.
First, make the initial connections as follows:
1. Coalescing Pre-filter
2. Inlet piping including an isolation valve
3. Outlet piping including an isolation valve
4. Particulate post-filter
CLEARPOINT V Series Activated Carbon Tower
®
10
(Rev. D)
