Press [L ] to activate the C-MAP Weather Download: the whole data pack-
OAD
age (see the previous "Weather data package" table) are downloaded. [S
allows to interrupt the data download.
At the end of the operation press [E

Copy from C-CARD

[MENU] + "C-MAP WEATHER SERVICE" + [ENTER] + "COPY FROM C-CARD"
+ [ENTER]
Allows the whole data package C-MAP Weather loading from the C-CARD.

Prediction

[MENU] + "C-MAP WEATHER SERVICE" + [ENTER] + "PREDICTION" +
[ENTER]
Allows selecting the Layer of specific weather data to be displayed on the screen
and to change date and time of the forecast preview.
The following functions are available:
Panning
Zoom In/Out
Set of Date and Time : [D
Layer selection
Exit

Real Time View

[MENU] + "C-MAP WEATHER SERVICE" + [ENTER] + "REAL TIME VIEW" +
[ENTER]
The following selections are available:
Real Time View On
Real Time View Off
The layer displayed is the one selected into the previous menu item.

Type of Data

[MENU] + "C-MAP WEATHER SERVICE" + [ENTER] + "TYPE OF DATA" +
[ENTER]
Allows selecting the type of data, see the previous Fig. 4.9.

4.10 FISH FINDER

The chart plotter combined with the sonar performance of the Fish Finder is one
of the most advanced marine navigation system available.
To select the Fish Finder menu, first select one of the pages related to the Fish
Finder:
[PAGE] + move the cursor up/down + [ENTER]
Once the Fish Finder page is selected, access the Fish Finder menu by pressing:
[MENU]
For more information see the specific User Manual.
NOTE The Fish Finder display page is available only if the Fish Finder is connected
and powered On.
4.11 RADAR
The Radar consists of a scanner unit which illuminates targets with microwave
energy and then collects the echoes from those targets. The scanner unit includes
the Radar antenna, transmitter, receiver and necessary electronics. The scanner
User Manual
: default usage of the cursor key is the normal panning function.
: zoom in/out functions are allowed as usual by using [ZOOM IN]/[ZOOM OUT].
] to modify date and time values.
ATE
: [L ] to cycle of the weather layers.
AYER
: [E ] or [CLEAR] to close the weather prediction page.
XIT
: the data is shown (the area of the download) at the current date and time
(received from the GPS).
: the Weather data is not displayed.
FOR CM 169CS/169CSI/11CV+/CM 11CVS+
] to close the window.
XIT
]
TOP
