Chapter 2 — Spare Parts

Print Unit, EasyCoder PX6i

Callout Part Number
1-040087-90
1 1-040960-90
2 1-995101-54
3 1-975606-20
4 1-040109-10
5 1-040151-01
6 1-040150-11
7 1-040195-00
8 1-040163-00
8 1-040254-90
9 1-040248-02
10 1-040229-13
11 1-010110-90
12 1-040100-02
13 1-040084-90
13 1-040085-90
14 1-995101-24
15 1-040519-90
10
RoHS Number Description
1-040087-900 Print unit assembly
1-040960-900 Stepper motor assembly
1-995101-54 Timing belt
1-974006-020 Reflecting sensor (headlift)
1-040109-02 Label stop assembly
1-040151-01 Upper guide assembly
1-040150-11 Lower assembly
1-040195-00 Pressure arm assembly
1-040163-00 Knob crank shaft assembly
1-040254-90 Head pressure link assembly
1-040248-02 Cam handle
1-040229-13 Tear bar
1-010110-90 Platen roller/liner drive roller/
ribbon assist roller
1-040100-02 Tooth belt wheel
1-040084-900 Thermal printhead assembly
(8 dots/mm)
1-040085-900 Thermal printhead assembly
(11.81 dots/mm)
1-995101-24 Timing belt
1-040519-900 Wheel (toothless) assembly
Remarks
Complete unit
Includes pulley
Includes crank shaft and screw
Includes bearings
203.2 dpi
300 dpi
EasyCoder PX4i and PX6i Printers Spare Parts Catalog
