CPU Board

P35
Callout Part Number
1 1-971630-90
J10 1-971634-30
J20 1-020040-80
J20 1-020040-20
J21 1-020040-04
J21 1-020040-08
J21 1-020040-16
J30 1-956009-90
EasyCoder PX4i and PX6i Printers Spare Parts Catalog
1-971630-01 PO1
RoHS Number Description
1-971130-900 CPU board assembly
1-971134-001 SDRAM SIMM 16MB
1-020040-800 Flash SIMM 4 MB (Boot)
1-020040-004 Flash SIMM 4 MB (Boot)
1-020040-004 Flash SIMM 4 MB (Boot)
1-020040-008 Flash SIMM 8 MB (Boot)
1-971136-021 Flash SIMM 16 MB
1-936009-010 Real-time clock circuit
Reconfiguration required. Refer to EasyCoder PX4i/PX6i Service
Manual Chapter 15.8 for instructions.
Chapter 2 — Spare Parts
Remarks
Flash and DRAM SIMMs
not included
SDRAM memory expansion
Includes Intermec Fingerprint
v8.xx and Intermec Shell v.8.x
Includes IPL v.2.xx
Flash memory expansion
Flash memory expansion
Flash memory expansion
23
