Printing a Test Label
Once the printer has been loaded with RFID media, we recommend
that you print an RFID test label to verify that everything is working
correctly. When the command is issued, the printer will attempt to access
the next tag on the media roll, and if successful, it will print the tag type
name on the label.
There are two ways to produce an RFID test label:
On the printer console, press the Setup button. Navigate your way to
1
Print Defs > Testprint > RFID Test Label. Press Enter.
Acquire the printer's internal IP number (Setup > Network > IP
2
Address), open your web browser and enter the number into the
address field. This brings up the printer's "home page". Click Printer
> Web shell and select RFID Test label from the drop-down menu.

RFID Setup

Once installed, the printer automatically recognizes the RFID module
and adds RFID options to the setup tree. The setup tree as viewed from
the console is shown in the illustration below.
SETUP:
These menus will only be displayed when an RFID module is installed.
RFID
RFID:
MODE
MODE: MODE:
ENABLE DISABLE
RFID,MODE,ENABLE|DISABLE
Must be set to ENABLE to use RFID commands. This is the default
setting when an RFID module is installed.
RFID,RETRIES
Specifies the number of labels the printer will retry to access after a failed
read or write operation. The default is 1, and allowed values range from 0
to 10. Before moving the label roll to try accessing the next tag, the text
string specified by RFID,VOIDTEXT will be printed on the failed label.
If all retries fail, the printer will position the current label below the
antenna with STOPADJUST and signal error 1321.
RFID,VOIDTEXT
Specifies the text to print on labels with faulty tags. The length of the
RFID Kit (Gen 2, 869/915 MHz) User's Guide
RFID:
RFID:
RETRIES
VOIDTEXT
RETRIES:
VOIDTEXT:
[1]:
[VOID]:
Read-Only
RFID:
RFID:
TAGADJUST
FIELDSTRENGTH
TAGADJUST: FIELDSTRENGTH:
[0]: [100]:
