EasyCoder 501/601 – Installation Instructions
INDUSTRIAL INTERFACE KIT, cont'd.
Connector Configuration
Pin "uart3:" Remarks
DB25 female
1 GNDC Cable shield
2 TXDB Transmitted data from printer
3 RXDB Received data to printer
4 RTSB RTS from printer
5 CTSB CTS to printer
6 DRSB DSR to printer
7 GNDI Signal ground
8 – not used
9 – not used
10 – not used
11 – not used
12 – not used
13 – not used
14 – not used
15 – not used
16 +5VEXT + 5V max 200 mA*
17 – not used
18 – not used
19 – not used
20 DTRB DTR pemanently high
21 – not used
22 – not used
23 – not used
24 – not used
25 – not used
*/. If strap fitted on P-1
"uart3:" is a DB25 female connector.
The In/Out connector is a DB15 female connector.
The mounting holes are connected to chassis ground.
Pin In/Out connector Remarks
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
signals are controlled by means of
OUT
PORTOUT (<nexp>) ON|OFF
and
IN
PORTIN (<nexp>)
Also see Intermec Fingerprint 6.13 Programmer's
Manual.
DB15 female
OUT 201 See example on next page
OUT 201
OUT 202
OUT 202
OUT 203
OUT 203
OUT 204
OUT 204
IN 101 See example on next page
IN 101
IN 102
IN 102
IN 103
IN 104
IN 103/104
signals are read by means of
OUT
functions.
statements.
