Hex Data Commands in Example
Data
27 90 A8 D5 90 22
26 84 96 22
22
26 8C 84 22
24 82
25 88 22
21 93 43 C2
25 43 C2
28

Designing Pages

Intermec Printer Language (IPL) Developer's Guide
Command Description
0x27 Raw bitmap data follows, starts at Y0
90 90 - 80 (LO) = 0x10 -> 1 dot at Y4
A8 A8 - 80 (LO) = 0x28 -> 2 dots at Y10 and Y12
D5 D5 - 80 (LO) = 0x45 -> 3 dots at Y14, Y17, and Y20
90 90 - 80 (LO) = 0x10 -> 1 dot at Y25
0x22 End of line
0x26 Transition white
84 84 - 80 (LO) = 4 white
96 96 - 80 (LO) = 22 black
0x22 End of line
0x22 End of line
0x26 Transition white
8D 8D - 80 (LO) = 13 white
84 84 - 80 (LO) = 4 black
0x22 End of line
0x24 Repeat last line
82 82 - 80 (LO) = 2 times
0x25 Transition black
88 89 - 80 (LO) = 9 black
0x22 End of line
0x21 Change origin
93 93 - 80 (LO) = 0x13 -> X19
43 C2 43 - 40 (HI) = 0x03
C2 - 80 (LO) = 0x42
(0x03 ∗ 0x80) + 0x42 = 1C2 -> Y450
0x25 Transition black
43 C2 43 - 40 (HI) = 0x03
C2 - 80 (LO) = 0x42
(0x03 ∗ 0x80) + 0x42 = 1C2 -> Y450
0x28 End of bitmap
A page is a collection of one or more formats that you combine to print at
the same time. This feature is helpful when you need to print several
different labels for an application at once. For example, you may need to
attach one type of label to a product and a different type of label to its
container. With the page printing capability, you can print both labels at
the same time. Because you can print pages of several formats at once, you
can also print labels on media rolls that have different sizes and shapes of
labels already precut.
When you group label formats into a page, you assign the formats to
positions designated by the letters a through z. You can print the formats
used in pages independent of each other.
