- Page 1 M018/M019 PE-MF2b/PE-MF2c Service Training M018/M019 Product Overview PE-MF2b/PE-MF2c Version 1.0 Slide 1 This training course explains the differences between the PE-MF2 series and the older PE-MF1 series.
- Page 2 M018/M019 PE-MF2b/PE-MF2c What Models are there in the Series? PE-MF2b (M018) 20 ppm (color and b/w) No optional memory DDST (GDI) Duplex built-in Fax built-in Optional 500-sheet paper tray PE-MF2c (M019) 20 ppm (color and b/w) Optional 256MB memory available...
- Page 3 M018/M019 PE-MF2b/PE-MF2c Appearance Slide 3 These machines have a built-in ADF.
-
Page 4: Product Positioning
M018/M019 PE-MF2b/PE-MF2c Product Positioning 2006 2007 2008 4-in-one PL-MF1 PE-MF1c 4-in-one 4-in-one PE-MF2c 31/8ppm 21/21ppm 21/21ppm PCL/PS PCL/PS PE-MF1b PE-MF2b 4-in-one 4-in-one 21/21ppm 21/21ppm PE-MF1a 3-in-one 16.5/16.5ppm PE-MF2 is the successor model to PE-MF1. Model PE-MF1 b and c were enhanced and will be launched as PE-MF2b and PE-MF2c. -
Page 5: Operation Panel
M018/M019 PE-MF2b/PE-MF2c Operation Panel There is a User Tools button to make initial setup easier. Slide 5 Service mode is the same as the PE-MF1. It is not necessary to use a PC, like it was for the PE-P1. - Page 6 M018/M019 PE-MF2b/PE-MF2c Uses an AIO Cartridge The OPC, charge roller, and development unit are all in an AIO cartridge. AIO: All-in-one The cartridge can be removed with one hand. The AIO cartridge for the PE-MF2 is different from the AIO cartridge for the PE-MF1.
- Page 7 M018/M019 PE-MF2b/PE-MF2c Two Types of AIO (Print) Cartridge Starter 1 k prints per cartridge Short Yield 2.5 k prints per cartridge Long (High Yield) 6.5 k prints per cartridge (BK) 6.0 k prints per cartridge (CMY) » Method was changed: From 5% chart & 50% color to ISO19798 »...
-
Page 8: Standard Equipment
M018/M019 PE-MF2b/PE-MF2c Standard Equipment This equipment is built-in for both models. 35-sheet automatic document feeder 250-sheet paper feed unit 1-sheet bypass feed Duplex (for printing and copying) » PE-MF1: Duplex is for printing only Ethernet: 10Base-T/100base-TX USB 2.0 Memory RAM: 128 MB (Main board: PE-MF2b & PE-MF2c) »... -
Page 9: Optional Equipment
M018/M019 PE-MF2b/PE-MF2c Optional Equipment Memory Unit Type F 256MB, G891 (PE-MF2c only) TK1010 Paper Feed Unit, G849 (PE-MF2b and PE- MF2c) Both of these are also used in the PE-MF1. Slide 9 No additional notes... - Page 10 M018/M019 PE-MF2b/PE-MF2c Improvements to Basic Features Faster warm-up time Improved from 51 s to 48 s Higher yield for the AIO Cartridge Improved from 2k to 6.5k (black) and 6k (CMY) Improved copying functions “Duplex Copy”, for example. In the PE-MF1, duplex printing is available but not duplex copying.
- Page 11 M018/M019 PE-MF2b/PE-MF2c Main Specifications - 1/2 Warm-up time: 48 seconds First copy speed: 30 seconds First print speed: Less than 14 seconds Paper Input Capacity: 250 sheets (standard tray) 1 sheet (bypass tray) 500 sheets (optional paper tray unit) Paper Output Capacity: 150 sheets...
- Page 12 M018/M019 PE-MF2b/PE-MF2c Main Specifications - 2/2 Memory (RAM) 128 MB (Main board: PE-MF2b & PE-MF2c) PE-MF2c also has 128MB on its PDL board (built-in), with an empty slot which can be upgraded with an optional 256MB board, for a maximum of 384MB on the PDL board (in addition to the main board's 128MB) »...
-
Page 13: Fax Specifications
M018/M019 PE-MF2b/PE-MF2c Fax Specifications Resolution: 8 x 3.85, 8 x 7.7 dots/mm Modem rate (max): 33.6 kbps Transmission time: 3 seconds Data compression method: MH, MR, MMR Memory capacity: More than 100 sheets (8 x 3.85) Speed dial: 50 (total for Fax and Scan to E-mail) - Page 14 M018/M019 PE-MF2b/PE-MF2c Comparison with PE-MF1 - 1/2 Slide 14 The red areas show improvements.
- Page 15 M018/M019 PE-MF2b/PE-MF2c Comparison with PE-MF1 - 2/2 Slide 15 New Functions ID Copy Use for printing 2-sided originals, such as an ID card, on one sheet. One side of the original is printed on the upper half of the paper and the other side is printed on the lower half.
- Page 16 M018/M019 PE-MF2b/PE-MF2c Supplies Starter 1 k prints per cartridge Short Yield 2.5 k prints per cartridge Long (High Yield) 6.5 k prints per cartridge (BK) 6.0 k prints per cartridge (CMY) » Method was changed: From 5% chart & 50% color to ISO19798 »...
- Page 17 M018/M019 PE-MF2b/PE-MF2c Targets Average Monthly Print Volume 0.75K prints (PE-MF2b) 0.9K prints (PE-MF2c) Color ratio: 60% Maximum Monthly Print Volume: 1.5K prints Estimated Unit Life: 5 years or 90K prints Slide 17 No additional notes...
-
Page 18: Service Training
M018/M019 PE-MF2b/PE-MF2c Service Training M018/M019 Changes to the Engine Slide 18 No additional notes... -
Page 19: Replacement Procedures
M018/M019 PE-MF2b/PE-MF2c Replacement Procedures ITB Unit, Laser Optics Housing Unit The changes were also applied to the PE-MF1, as stated in earlier technical bulletins. Slide 19 No additional notes... -
Page 20: Firmware Update Procedures
M018/M019 PE-MF2b/PE-MF2c Firmware Update Procedures Controller Firmware Update The procedure has changed. If the update procedure failed, note the following points: » The machine must be connected to a computer by USB. » When using a computer running on a Windows operating system, you must have an account that has Manage Printers permission. -
Page 21: Image Problem Troubleshooting
M018/M019 PE-MF2b/PE-MF2c Image Problem Troubleshooting This section has been changed, and there is a new procedure for printing a test page to check the cause of the problem. Service Manual: Troubleshooting, Image Problems Slide 21 No additional notes... - Page 22 M018/M019 PE-MF2b/PE-MF2c End of Course Slide 22 No additional notes...
