Contender C74400 Assembly Instructions

Parts:
(2) Side Panel Top Panel
Bottom 1 Panel 45 15 ⁄ " x 11 21 ⁄ "
1 6 3 2
(2) Rails
Finished Edge
Step 1: Using phillips head screwdriver (not
included) and hardware provided, attach
casters to bottom piece as shown. See in-
structions included with caster set.
Step 3: Insert Large Center Divider
notch of Small Divider
Step 5: Install Side Panel so that
edge of assembled pieces fit firmly into
mortises and back grooves. Insert hex
screws into pre-drilled holes in Side
Panel. Tighten down halfway.
C74400 ASSEMBLY INSTRUCTIONS
Large Center Divider
(2) Small Divider
Small Divider 5/8"
Bottom 2 Panel 45 15 ⁄ " x 11 3 ⁄
1 6
⁄ " into
3
8
5 ⁄ ".
8
3 ⁄ "
Back Panel
8
1 ⁄ "
4
Allen Wrench (24) Hex Screws
"
3 2
Set of (4) Casters
with hardware
Step 2: Insert Small Divider
into mortises of Rails. Insert hex
screws into pre-drilled holes in
Rails. Tighten down halfway.
Step 4: Slide Top Panel into long groove of
Rails. Insert hex screws into pre-drilled holes
in Rails. Tighten down halfway.
For assistance, call: Customer Service
1-800-247-8465
End Shelf
(2) Phillips Bolts (2) Washers
Phillips Head Screwdriver
(Not Included)
⁄ "
5
8
Step 6: Align back grooves
in Bottom 1 Panel with the
back grooves in Side Panel.
Insert hex screws into pre-
drilled holes in Side Panel.
Tighten down halfway.
