I Gateway server connections

D D Connecting to the ID-RP1 system
to Internet
Modem
Router
D D Connecting to the ID-RP2 system
to Internet
Modem
Router
Gateway server
LAN card: eth0
LAN card: eth1
to eth0
to eth1
Gateway server
to eth0
to eth1

SYSTEM SETUP

Coupler
LAN card: eth0
LAN card: eth1
3
ID-RP1D (Zone repeater)
ID-RP2 (Zone repeater)
to [10BASE-T]
2
