Bosch Climate 5000 Series Installation Instructions Manual

Wired wall thermostat
Hide thumbs Also See for Climate 5000 Series:
Table of Contents

Advertisement

Quick Links

Installation Instructions
Wired Wall Thermostat
Climate 5000 Series

Advertisement

Table of Contents
loading

Related Manuals for Bosch Climate 5000 Series

Summary of Contents for Bosch Climate 5000 Series

  • Page 1 Installation Instructions Wired Wall Thermostat Climate 5000 Series...
  • Page 2 Installation Instructions Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 3: Table Of Contents

    6.7.2 For 2x2 (9-18K) and 3x3 7.12 Delete Saved Schedule (24-48K) Cassette Units 7.13 Set Timer On or Off Function 6.7.3 For Ducted Units 7.14 Set Timer On and Off Function Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 4: Key To Symbols And Safety Instructions

    NOTICE is used to address practices not related to personal injury.  Important information   T his symbol indicates important information where there is no risk to people or property. Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 5: Remote Controller Specifi Cations

     This product can expose you to chemicals including Lead and Lead components, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 6: Thermostat Accessories

    Use the magnetic ring to hitch the connective 10 Magnetic ring cable of the wire controller Adapter Board and Connection Comes with 120X1, Used for Wall Mounted Cables Table 2 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 7: Operation Of Buttons

    2. MODE: Change mode of operation. 3. DAY OFF/DEL: Used to skip day during 7-Day scheduling or delete saved set up. 4. ADJUST: Used to adjust setting. 5. CONFIRM: Used to save setting change. Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 8 8. BACK: To go back to previous page 9. SWING: Adjust louver angle (Wall Mounted and Cassette type indoors only). 10. FUNCTION BUTTON: To activate Turbo function or Follow Me function 11. COPY: Copy the setting Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 9: Indicators On Lcd

    Fan speed indication Follow Me function indication Temperature display Left-right swing indication (some models) Lock indication Clock display °C / °F indication On/Off timer Turbo function indication Timer display Table 3 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 10: Installation

    Installation Instructions 6 Installation 6.1 Dimensions Figure 4 1 0 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 11: Wiring

    CN41/CN42) The connection cable A CN43 Main board CN18 X Y E 5V CN32 White Yellow Brown 4-core shielding wire on the controller The connection cable D Figure 5 | 11 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 12 Connection Cable C The 3+4 core wire between CN18 and CN40 and CN1 120X1 Connection Cable D The 2-core wire between CN32 and CN43 120X1 Connection Cable E The 4-core wire between Cable A and CN40 120X2 Table 4 1 2 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 13: Remove

    2. Remove the back cover.       T he PCB is mounted in the upper part of the wired controller. Be careful not to damage the board with the screwdriver. | 13 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 14: Mount Back Plate

    Switch box Back plate Screw (M3.9x25) Screws (M4×25) Figure 9 NOTICE:  Place on a flat surface. Over-tightening screws may damage back plate of the wired wall thermostat. 1 4 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 15: Battery Installation

    2. Set the correct time before operating. Batteries in the wired controller can maintain the correct time during a power failure. When the power is restored and the displayed time is not correct, replace the battery. | 15 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 16: Connect To Indoor Unit

    Installation Instructions 6.6 Connect to Indoor Unit There are two methods: Method 1: from back Figure 11 Method 2: from bottom 1 6 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 17 Installation Instructions Figure 12 | 17 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 18  DO NOT allow water to enter the wired wall thermostat. Use the trap and putty to seal the wires. Putty Trap Putty Putty Trap Trap Figure 13 1 8 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 19: Connection Guide To Indoor Units

    1. Open the front panel of the Wall Mounted Unit and locate the display board bracket shown below. Figure 14 2. Remove the bracket from the units front panel. Figure 15 | 19 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 20 3. Disconnect the wire from CN1 port on the display board. Figure 16 4. Disconnect the wire from CN18 port on the unit’s main control board shown below. Figure 17 2 0 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 21 Installation Instructions 5. Identify the components. From top to bottom, connecting wires and adapter board. Figure 18 | 21 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 22 CN40 shown below. Figure 19 7. Take the 4 core end from cable C and plug it into CN18 on the Main Board. Figure 20 2 2 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 23 8. Plug the white end of the 2 core wire (cable D) into the CN43 port on the adapter board. Figure 21 9. Place the adapter board in the location shown below. Figure 22 | 23 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 24 4 core wire (cable B) from CN41 and CN42 on the adapter board into the 20 ft connection wire (Cable B, red circle). Figure 23 2 4 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 25 11. Connect the black end of the 2 core wire to the CN32 port on the units main control board shown below. Figure 24 12. Place display & adapter board on the back of the front panel and close the cover of IDU control box. | 25 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 26 Installation Instructions 13. Reattach the Cover of the Wired Wall Thermostat       A void clamping during installation. Figure 25 2 6 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 27: For 2X2 (9-18K) And 3X3

    1. Remove the grille (refer to Cassette Installation Manual) and fi nd the Electronic Control Box. 2. Remove the cover of PCB and locate CN40 port. Figure 26 Location of CN40 Port for 2x2 (9-18K) Units | 27 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 28 Installation Instructions Figure 27 Location of CN40 Port for 3x3 (24-48K) Units 2 8 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 29 3. Connect the red end of the connection cable E to CN40 on the Main Board Figure 28 The Connection Cable E 4. Connect the black end of the connection cable E to the connection cable A (20ft) | 29 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 30: For Ducted Units

    Installation Instructions 6.7.3 For Ducted Units 1. Remove the cover of the Electronic Control Box. Figure 29 Remove the cover of the Electronic Control Box 3 0 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 31 3. Connect the red end of the connection cable E (see Figure 30 above) to CN40 on the Main Board. 4. 4. Connect the black end of the connection cable E to the connection cable A (20ft). | 31 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 32: Operation Guideline

    Press repeatedly to adjust the current time in 1 minute increments. example: Monday 11:20 Figure 32 5. The setting is complete after pressing TIMER or the CONFIRM button. 3 2 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 33: Time Scale Selection

    Ensure the unit is plugged in and power is available. 1. Press the power button. 2. Press Mode to change / select desired operation mode. Figure 33 3. Press to set desired temperature. | 33 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 34: Change Fan Speed

    1. Press Fan Speed to select desired fan speed or auto speed mode. Auto HIGH Figure 34       F an speed cannot be changed in Dry and Auto mode. 3 4 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 35: Follow Me Function

    Indoor Unit Figure 35       B y default, Follow me function in the wired thermostat will be turned on with 4-Way Cassette and Ducted Indoor models. | 35 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 36: Child Lock

    3 seconds to change between °F and °C. 7.8 Turbo Mode (HEAT/COOL modes only) 1. Press the FUNC. button to activate the TURBO function. Press the button again to deactivate the turbo function. 3 6 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 37: Swing Function

    (-0 corresponds to all four louvers). Figure 36 3. Press the SWING button to adjust the airfl ow direction of the selected louver. | 37 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 38: Scheduling

    7.10.1 Programming 7-day Schedule 1. Press Timer to select the Week and press CONFIRM 2. Press to select the day of the week and then press CONFIRM Figure 37 3 8 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 39 WEEKLY TIMER is set according to the user’s life style. 4. Press to set the time then press CONFIRM 5. Press to set the operation mode then press CONFIRM Figure 39 | 39 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 40 Figure 40   T his setting is unavailable in the AUTO, DRY or OFF modes. 8. Diff erent schedules can be programmed by repeating steps 3 through 7. 4 0 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 41: Starting Saved 7-Day Schedule

    Figure 41 To Cancel: 1. Press Power to cancel the timer mode. 2. The timer mode can also be canceled by changing the timer mode using Timer | 41 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 42: Set Day Off (Holiday)

    6. To cancel, follow the same procedures used for setup.   T he DAY OFF (holiday) setting is cancelled automatically after the set day has passed. 4 2 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 43: Copy Existing Schedule

    6. Other days can be copied by repeating steps 4 and 5. 7. Press CONFIRM to save the settings. 8. Press BACK to revert to the 7-Day schedule. | 43 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 44: Delete Saved Schedule

    CONFIRM 3. After selecting the day to be deleted, press Day off /Del to delete the saved setting. ex. Delete the time scale 1 in saturday Figure 44 4 4 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 45: Set Timer On Or Off Function

    After the time is set, the timer starts or stops automatically. 4. Press CONFIRM again to fi nish the settings. ex.Off timer set at 18:00 Figure 46 | 45 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)

  • Page 46: Set Timer On And Off Function

    Clock display fl ashes. 3. Press to set the On timer and then press CONFIRM 4. Press to set the Off timer. 5. press CONFIRM again to fi nish the setting. 4 6 | Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 47 Installation Instructions | 47 Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
  • Page 48 United States and Canada Bosch Thermotechnology Corp. 65 Grove Street Watertown, MA 02472 Tel: 866-642-3198 Fax: 603-965-7581 www.bosch-thermotechnology.us BTC 769103309 A / 02.2022 Bosch Thermotechnology Corp. reserves the right to make changes without notice due to continuing engineering and technological advances.
