Twin-tub Washing Machine
Features
High head , unique shape
Full plastic shell
Spraying spin
Separating water and electricity , wide voltage range design
Enclosed base frame , mute design
Bubble wash
With castor
Serial
Number:SMHWM80-27S-01
SERVICE MANUAL
Models
HWM80-27S
Version:00.00
Edition: 2005-8-26
Advertisement
Table of Contents
Related Manuals for Haier HWM80-27S
Summary of Contents for Haier HWM80-27S
-
Page 1: Service Manual
Twin-tub Washing Machine SERVICE MANUAL Features High head , unique shape Full plastic shell Spraying spin Separating water and electricity , wide voltage range design Enclosed base frame , mute design Bubble wash With castor Serial Number:SMHWM80-27S-01 Models HWM80-27S Edition: 2005-8-26 Version:00.00... -
Page 2: Table Of Contents
CONTENTS 1.Contents Product code illumination and series introduction Features 4. Specifications Safety precautions Warning and cautions 7. Net dimension Installation and accessory parts 9. Parts and functions 10. Maintenance service and trouble shooting 11. Wiring diagram 12. Exploded view Model:HWM80-27S... -
Page 3: Features
Twin-tub Washing Machine Model:HWM80-27S FEATURES High head, unique shape Spraying spin Separating water and electricity, wide voltage range design Enclosed base frame, mute design Unique bubble design, remove all dirty Full plastic shell, stainless for ever Wide range voltage design, not be afraid of voltage fluctuating... -
Page 4: Specifications
Dimension s packed ( measurem ents packed) Height W idth Depth Net weight Gross weig ht 20'Container load 40’ Container load 40H’ Container load Twin-tub Washing Machine × Model:HWM80-27S HWM80-27S × 55/46/36 × <115 × × × × × 1350 ×... -
Page 5: Safety Precautions
Earth Do not use water hotter than 50 C . Ventilation hole at the bottom of the washing machine Do not wash water-proof laundries such as the raincoat, bicycle shelter etc. To avoid abnormal vibration during spinning. Model:HWM80-27S 50 C... -
Page 6: Warning And Cautions
( such as the kettle with hot water ) on the washing machine. Handicapped or children without care shall not use the machine. Model:HWM80-27S Do not decompose, repair or alter the machine by yourself. Do not wash laundries with volatile materials (such as thinner, petrol etc.). -
Page 7: Net Dimension
<10cm 4.If extra drain hose is needed , the inner diameter of the extra hose shall not less than 30mm, and the length shall not exceed 1.5m. Model:HWM80-27S Unit mm Figure 1 > 30mm <1.5m... - Page 8 (See to Figure 6). Twin-tub Washing Machine Rotate the fixing you can hook for 90 Take off the fixing hook downwards Model:HWM80-27S Drain hose fixing hook Side sectional view Fixing hook Drain hose installation hole fixing hook...
- Page 9 The spin tub then can be taken out. In installation, be sure to inlay the bulge of the inner lining of the brake wheel into the groove of the spin tub shaft. (Figure 10) Model:HWM80-27S Dismantle Installation Spin tub frame...
- Page 10 Please use suitable tools and add even pressure around the tub. After inlay the bearing seat, check if the claw is installed to proper position from the outside of the twin-tub (Figure 12). Right Model:HWM80-27S Screw Wrong Figure 12 Figure 11...
-
Page 11: Parts And Functions
Drain hose hanging hole Lint filter Valve cover Pulsator Wash tub Drain hose Base frame Twin-tub Washing Machine Model:HWM80-27S Figure 13 Outer cover of the spin tub Inner cover of the spin tub Spin timer Spin tub frame Spin tub Cabinet... -
Page 12: Maintenance Service And Trouble Shooting
Check if the fuse is good? Poor contact or inferior inside of the wash timer Replace the wash timer Model:HWM80-27S Open the wash timer. Switch on the power. Replace the plug or receptacle. Replace with new power supply cord. - Page 13 Check if the micro-switch is closed? Check if the motor is good Check if the brake system is detached? Repair the brake system. Model:HWM80-27S Open the spin timer. Switch on the power. Replace the plug or receptacle. Replace with new power supply cord.
- Page 14 ? Is the belt too loose or too tight? Is the wiring of the wash timer proper? Model:HWM80-27S Add the brake or replace the brake arm. Replace the motor. Fasten the motor tightly. Adjust the tension of the belt.
-
Page 15: Wiring Diagram
Twin-tub Washing Machine spin timer safety switch orange wash timer blue spin timer orange orange brown brown grey brown purple yellow yellow capacitor Model:HWM80-27S purple purple spin grey motor grey blue buzzer blue wash motor yellow Figure 15 microswitch buzzer... -
Page 16: Exploded View
Twin-tub Washing Machine Model:HWM80-27S EXPLODED VIEW Manual... - Page 17 Twin-tub Washing Machine Model:HWM80-27S EXPLODED VIEW...
- Page 18 Sincere Forever Haier Group Haier Industrial Park, No.1, Haier Road 266101, Qingdao, China http://www.haier.com...
