Network Assistant Features
Network Assistant simplifies the management of communities or clusters by offering a GUI, alternative
modes for configuring network devices, two levels of access, and comprehensive online help.
shows the main features of the GUI.
Figure 2-1
1
2
4
1 Toolbar
2 Feature bar
These sections describe the Network Assistant features:
Front Panel View, page 2-2
•
Topology View, page 2-3
•
OL-6194-07
Network Assistant GUI
3
3 Topology view
4 Front Panel view
2
C H A P T E R
Getting Started with Cisco Network Assistant
Figure 2-1
2-1
