Page 1 User's Manual Safety Light Curtain AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr Cat. No. SCHG-710C...
Page 2 Introduction Thank you for purchasing the F3SJ Series Safety Light Curtain (hereinafter referred to as the "F3SJ" ). This is the instruction Manual describing the use of F3SJ. Always heed the following points when using the F3SJ: Be sure to have F3SJ be handled by a "Responsible Person" who is well aware of and familiar with the machine to be installed. The term "Responsible Person"...
Page 3 •EC Type-Examination in accordance with the EU Machinery Directive, Type 4 ESPE (EN61496-1), Type 4 AOPD (prEN61496-2) •EMC Competent Body Certificate (Power supply for test: OMRON S82K) •TÜV-PS Type Approval, Type 4 ESPE (EN61496-1), Type 4 AOPD (prEN61496-2), SIL1, 2, 3 (EN61508-1 through -7), Application: EN954-1 Category B,1,2,3,4 5.
Page 4: Read And Understand This Document
PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. In no event shall responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted.
Page 5 Performance data given in this document is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of OMRON’s test conditions, and the users must correlate it to actual application requirements.
Page 6: Precautions On Safety
Introduction Precautions on Safety Precautions on Safety Regarding the alert symbols and meanings used for the safe uses In order for our customers to use the F3SJ-A in safety, precautions are indicated in this manual with the alert symbols and statements such as the followings. Those safety precautions relate to the important descriptions that must be obeyed for the safe uses and operations.
Page 7 Introduction For installation Make sure to test the operation of the F3SJ after installation to verify that the F3SJ operates as intended. Make sure to stop the machine until the test is complete. Unintended function settings may cause a person to go undetected, resulting in serious injury.
Page 8 Introduction Do not use the sensor system with mirrors in a retro-reflective configuration as shown below.Doing so may hinder detection. It is possible to use mirrors to "bend" the detection zone to a 90-degree angle. Reflector Reflector Position with retro-reflection Position with detection zone bent at 90 When using series connections, perform inspection for all connected F3SJ as described in "Chapter 5 Checklists".
Page 9 Introduction Extension of the cable must be within a specified length. If it isn't, safety function may not work properly, resulting in danger. Other To use the F3SJ in PSDI mode (Reinitiation of cyclic operation by the protective equipment), you must configure an appropriate circuit between the F3SJ and the machine.
Page 10: Precautions For Safe Use
Introduction Precautions for Safe Use Precautions for Safe Use Make sure to observe the following precautions that are necessary for ensuring safe use of the product. • Thoroughly read this manual and understand the installation procedures, operation check procedures, and maintenance procedures before using the product.
Page 11 Introduction Cleaning Do not use thinner, benzene, or acetone for cleaning, because they affect the product's resin parts and paint on the case. Object detection The F3SJ cannot detect transparent and/or translucent objects. AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 12: Checking The Contents
Introduction Checking the Contents Before use, confirm that the items below were shipped with the product. If you find that an item is missing, please contact your local branch office or distributor. Product Quantity F3SJ-A main unit Emitter x 1, Receiver x 1 Top/bottom mounting brackets 4 sets Intermediate mounting brackets...
Page 13: How To Read This Manual (Explanation Of Symbols)
Introduction How to Read This Manual (Explanation of Symbols) Indicates the description of an essential point regarding a function, such as an important point regarding operation or advice on how to use it. Indicates the page number for related content. Indicates a reference for when there is trouble, or an explanation of difficult words.
Page 14 Introduction AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 15: Table Of Contents
Introduction Contents Legislation and Standards READ AND UNDERSTAND THIS DOCUMENT Precautions on Safety Precautions for Safe Use viii Precautions for Correct Use viii Checking the Contents How to Read This Manual (Explanation of Symbols) Chapter1 Overview and Specifications Basic Configuration and Names Application Examples Detect the approach to a hazardous area Using multiple sets in combination...
Page 16 Introduction Wiring Diagrams Installation standard for muting sensors Installation Example of 2 Muting Sensors Installation Example of 4 Muting Sensors Override Function External Test Function Self-Test Function Auxiliary Output (Non-Safety Output) Resetting Lockout External Device Monitoring Function (EDM) Chapter3 Wiring/Installation Installation Conditions Detection Zone and Approach Safety Distance...
Page 17 Introduction Connecting to an F3SP-B1P Using only F3SJ Connecting a muting sensor Connecting to an F3SX-E-L2R Connecting to a G9SA-301 Connecting to a G9SA-300-SC Connecting to a G9SB-301-D Connecting to a G9SX-AD322-T15 Chapter5 Checklists Pre-Operation Checklists Checklists Maintenance Checklists Daily Maintenance 6-Month Inspection Chapter6 Appendix...
Page 18 Introduction AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 19: Chapter1 Overview And Specifications
Chapter1 Overview and Specifications Basic Configuration and Names Application Examples Features Indicator Display Patterns Ratings Ratings/Specifications Model Name List/Response Times AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 20: Basic Configuration And Names
Overview and Specifications Basic Configuration and Names F3SJ Beam center-line mark Beam Emitter To attach or detach the cap and power cable, remove 4 screws shown above. Indicator Receiver Connection cable (Grey) Connection cable (Black) Extension cable Component Model name Description Emitter, receiver F3SJ-A...
Page 21 Overview and Specifications Component Model name Description Extension Cable with connector on one F39-JC A This extension cable is used to connect the F3SJ to a cable controller with discrete terminals (e.g. F3SX, G9SA, G9SB, G9SX) or to a safety processing system (e.g. DeviceNet safety).
Page 22 Overview and Specifications Components to be selected if necessary Component Model name Description Optional bracket Use this bracket (sold separately) for dedicated applications. Series connection cable for F39-JJR15L Required for connecting multiple sets of F3SJ in a series. It is used close contact when you wish to perform series connection with minimum length.
Page 23: Application Examples
Overview and Specifications Application Examples Detect the approach to a hazardous area The F3SJ should be installed where workers require frequent access in order to perform tasks such as maintenance, and where physical barriers are difficult to install. Detect the approach of a person Detect a person's limbs AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...
Page 24: Using Multiple Sets In Combination
Overview and Specifications Using multiple sets in combination By installing sensors on both sides of a machine as well as in front, you can move workpieces in and out more efficiently than when a physical barrier is installed. If the sensors are aligned in a U-shape, series-connection cables can be used between sets (up to 4 sets), so that only one control device is used, drastically reducing the amount of wiring in the panel.
Page 25: Features
Overview and Specifications Features Protective height available in incremental sizes Protective height Detection Series Protective height capability F3SJ-A 245mm to 2117mm (in 9mm Dia. 14mm increments) F3SJ-A 245mm to 2,495mm (in 15mm Dia. 20mm increments) F3SJ-A 245mm to 2,495mm (in 25mm Dia.
Page 26: Indicator Display Patterns
Overview and Specifications Indicator Display Patterns Emitter Receiver LEVEL LEVEL LEVEL-5 (Green) LEVEL-5 (Green) LEVEL-4 (Green) LEVEL-4 (Green) 1. Incident light level LEVEL-3 (Orange) LEVEL-3 (Orange) 1. Incident light indicator level indicator LEVEL-2 (Orange) LEVEL-2 (Orange) LEVEL-1 (Orange) LEVEL-1 (Orange) ERROR-C (Red) ERROR- C (Red) 2.
Page 27 Overview and Specifications Description Indicators For basic system For muting system ON-state indicator (ON) Turns ON when safety outputs are ON. Muting error indicator Not used Turns ON when a muting error occurs. (MUTING ERR) Blinking Not used Not used Test indicator (TEST) Not used Not used...
Page 28 Overview and Specifications Cause of error Power supply voltage of F3SJ is out of rated range. Insufficient current capacity of power supply. AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 29: Ratings
Overview and Specifications Ratings Ratings/Specifications In the model names in this table, the contain the 4 digits indicating the protective height (mm). F3SJ-A F3SJ-A F3SJ-A Detection capability Opaque objects Opaque objects Opaque objects Diameter 14mm Diameter 20mm Diameter 30mm Beam gap 15mm 25mm Number of beams...
Page 30 Overview and Specifications F3SJ-A F3SJ-A F3SJ-A Indicators Emitter Incident light level indicators (green LED x 2, orange LED x 3): ON based on the amount of incident light Error mode indicators (red LED x 3): Blink to indicate error details Power indicator (green LED x 1): ON while power is ON Interlock indicator (yellow LED x 1): ON when in interlock/Blinks when in lockout External device monitoring indicator (muting input 1 indicator), Test indicator (muting input 2...
Page 31 Overview and Specifications F3SJ-A F3SJ-A F3SJ-A Weight (packaged) - F3SJ-A Weight (g)=(protective height) x 1.7+ α - F3SJ-A P20/F3SJ-A Weight (g)=(protective height) x 1.5+ α The values for α are as follows: When protective height is between 245 and 596mm, α=1100 When protective height is between 605 and 1130mm, α=1500 When protective height is between 1136 and 1658mm, α=2000 When protective height is between 1667 and 2180mm, α=2400...
Page 32: Model Name List/Response Times
Overview and Specifications Model Name List/Response Times Number of Response time Response time F3SJ-A F3SJ-A F3SJ-A (ON to OFF) (OFF to ON) beams F3SJ-A0245P30 10 beams 10ms 40ms F3SJ-A0270P30 11 beams 10ms 40ms F3SJ-A0295P30 12 beams 10ms 40ms F3SJ-A0320P30 13 beams 10ms 40ms F3SJ-A0345P30 14 beams 10ms...
Page 33 Overview and Specifications Number of Response time Response time F3SJ-A F3SJ-A F3SJ-A (ON to OFF) (OFF to ON) beams F3SJ-A0497P14 F3SJ-A0815P20 F3SJ-A1345P30 54 beams 13ms 52ms F3SJ-A0506P14 F3SJ-A0830P20 F3SJ-A1370P30 55 beams 13ms 52ms F3SJ-A0515P14 F3SJ-A0845P20 F3SJ-A1395P30 56 beams 14ms 56ms F3SJ-A0524P14 F3SJ-A0860P20 F3SJ-A1420P30...
Page 34 Overview and Specifications Number of Response time Response time F3SJ-A F3SJ-A F3SJ-A (ON to OFF) (OFF to ON) beams F3SJ-A0920P14 F3SJ-A1520P20 101 beams 17.5ms 70ms F3SJ-A0929P14 F3SJ-A1535P20 102 beams 17.5ms 70ms F3SJ-A0938P14 F3SJ-A1550P20 103 beams 17.5ms 70ms F3SJ-A0947P14 F3SJ-A1565P20 104 beams 17.5ms 70ms F3SJ-A0956P14 F3SJ-A1580P20...
Page 35 Overview and Specifications Number of Response time Response time F3SJ-A F3SJ-A F3SJ-A (ON to OFF) (OFF to ON) beams F3SJ-A1343P14 F3SJ-A2225P20 148 beams 22.5ms 90ms F3SJ-A1352P14 F3SJ-A2240P20 149 beams 22.5ms 90ms F3SJ-A1361P14 F3SJ-A2255P20 150 beams 22.5ms 90ms F3SJ-A1370P14 F3SJ-A2270P20 151 beams 22.5ms 90ms F3SJ-A1379P14 F3SJ-A2285P20...
Page 36: For Series Connections, Use The Calculations Below
Overview and Specifications Number of Response time Response time F3SJ-A F3SJ-A F3SJ-A (ON to OFF) (OFF to ON) beams F3SJ-A1766P14 195 beams 25.0ms 100ms F3SJ-A1775P14 196 beams 25.0ms 100ms F3SJ-A1784P14 197 beams 25.0ms 100ms F3SJ-A1793P14 198 beams 25.0ms 100ms F3SJ-A1802P14 199 beams 25.0ms 100ms F3SJ-A1811P14...
Page 37 Overview and Specifications Response time (ON to OFF) :Response time of 1st unit + Response time of 2nd unit + Response time of 3rd unit 5 (ms) Response time (OFF to ON) :Response time (ON to OFF) x 5 (ms) When 4 sets are series-connected: Response time (ON to OFF) :Response time of 1st unit + Response time of 2nd unit + Response time of 3rd unit + Response time of 4th unit...
Page 38 Overview and Specifications AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 39: Chapter2 System Configuration And Functions
Chapter2 System Configuration and Functions How to Select a System System Selection Function List Basic System Wiring Diagrams Interlock Function External Test Function Self-Test Function Auxiliary Output (Non-Safety Output) Resetting Lockout External Device Monitoring Function (EDM) Muting System Upgrading F3SJ for Muting System Muting Timing Diagram Wiring Diagrams Installation Example of 2 Muting Sensors...
Page 40: How To Select A System
System Configuration and Functions How to Select a System System Selection The required system configuration depends on the functions to be used. Decide the system to use based on the following: When not using the muting function ... Basic system When using the muting function ...
Page 41: Basic System
System Configuration and Functions Basic System Basic system indicates the F3SJ with its default factory settings. The basic system provides basic safety light curtain functions. Most functions can be used without performing additional configuration. Wiring Diagrams Wiring using manual reset mode, external device monitoring +24V DC (White) Interlock selection input (Brown) 24V...
Page 42 System Configuration and Functions Wiring for auto reset mode Wiring the emitter’s circuit as shown below provides auto reset mode. +24V DC (WHITE) Interlock selection input Open Emitter side (YELLOW) Reset input S3 : Lockout reset switch (connect to 24V if a switch is not required) Wiring when external device monitoring function is not used Disable the external device monitoring function by connecting auxiliary output 1 and the external device monitoring input as shown in the diagram below.
Page 43: Interlock Function
System Configuration and Functions Ref.: Minimum wiring required to check the operation of the F3SJ (Wiring for auto reset mode and deactivated external device monitoring) +24V DC (White) Interlock selection input Open (Brown) 24V (Green) Test input Open (Yellow) Reset Input (Grey) Communication line (+) (Pink)Communication line (-) (Blue) 0V...
Page 44 System Configuration and Functions Manual reset When a reset input is given while no interrupting object exists in a detection zone, the safety outputs turn ON. This allows the machine to be manually reset using a reset switch after ensuring safety, preventing unexpected startup (EN1037).
Page 45: External Test Function
System Configuration and Functions External Test Function This function forcibly stops the emission using an external signal. It can be used to verify that a safety system should properly stop when F3SJ is interrupted. To stop the emission, apply 9 to 24V to the emitter's test input line. The voltage must be applied for a period 4 times that of Toff or longer.
Page 46: Auxiliary Output (Non-Safety Output)
System Configuration and Functions Waveform of safety outputs When the F3SJ is receiving light, the safety outputs cyclically turn OFF as shown below to test the output circuit. When this OFF signal is fed back, the output circuit is diagnosed as normal. If the output signal does not include an OFF pulse signal, the receiver diagnoses a failure in the output circuit or wiring, and it enters lockout state.
Page 47: Resetting Lockout
System Configuration and Functions Unblocked Unblocked /Blocked Blocked Toff Safety output Toff x2 or less Toff x2 or less Auxiliary output 1 Ton: Response time of safety output's OFF to ON, Toff: Response time of safety output's ON to OFF See p.14 for response time Resetting Lockout When the cause of the lockout is removed, the lockout condition can be released by using either of the...
Page 48: External Device Monitoring Function (Edm)
System Configuration and Functions External Device Monitoring Function (EDM) This function detects malfunctions, such as welding, in external relays (or contactors) that control the hazardous area of a machine. This function constantly monitors that a specified voltage is applied to the receiver's external device monitoring input line, and enters lockout state when an error occurs.
Page 49: Muting System
System Configuration and Functions Muting System The muting function temporarily disables the safety function of the F3SJ, keeping the safety outputs ON even if beams are blocked. This makes it possible to install safety light curtains for AGV passage, enabling both safety and productivity.
Page 50: Upgrading F3Sj For Muting System
The muting sensor is the sensor that is the trigger for temporarily disabling the F3SJ's safety functions. Through-beam or retro-reflective photoelectric sensors, proximity sensors, or limit switches can be used as muting sensors. (recommendation: OMRON E3Z series, E2E series, D4N series)Use those with PNP outputs or N.O. type contacts.
Page 51 System Configuration and Functions F3SJ's indicators •Muting input 1 indicator turns ON when an input is applied to muting input 1. •Muting input 2 indicator turns ON when an input is applied to muting input 2. •Muting error indicator turns ON when a muting error occurs. Wiring Diagrams p.35 When muting settings are made, align the indicator labels (included with F39-CN6) with the indicator and attach them, as indicated by the shaded areas in the diagram below.
Page 52: Muting Timing Diagram
System Configuration and Functions Muting Timing Diagram Start conditions If both of the following 2 conditions are present for the F3SJ, muting is activated. 1. No interrupting object is found in the F3SJ's detection zone, and safety outputs are ON. 2.
Page 53: Wiring Diagrams
System Configuration and Functions Wiring Diagrams Wiring when using muting and external device monitoring functions +24V DC (White) Muting input 1 (Brown) 24V (Green) Test input (Yellow) Reset input (Grey) Communication line (+) (Pink) Communication line (-) (Blue) 0V Emitte (Red) Muting input 2 M1 *2 Shield...
Page 54: Installation Standard For Muting Sensors
System Configuration and Functions Ref.: Minimum wiring required to check the operation of the F3SJ when using the muting function (Wiring that does not use the external device monitoring function) +24V DC (White) Muting input 1 (Brown) 24V (Green) Test input Open (Yellow) Reset input (Gey) Communication line (+)
Page 55: Installation Example Of 2 Muting Sensors
System Configuration and Functions Installation Example of 2 Muting Sensors This is an example of 2 retro-reflective type photoelectric sensors used as muting sensors installed in a cross pattern. Use 2 sensors when the length L of the workpieces are not constant or are insufficient. Before a workpiece passes through Hazardous area Reflector...
Page 56 System Configuration and Functions The muting sensor outputs are turned ON (muting inputs are HIGH) and the safety function of the F3SJ is disabled. Hazardous area F3SJ Reflector Workpiece Reflector F3SJ The F3SJ is blocked but the safety function is disabled by the muting function, and safety outputs 1 and 2 are turned ON.
Page 57 System Configuration and Functions To enable the muting function, D1 and d1 must satisfy formulas (1) and (2), respectively. This distance must prevent the muting function from being enabled by a person passing through the muting sensors. Also, install the F3SJ and muting sensors so that a workpiece passes through all muting sensors before the next workpiece arrives at the muting sensors.
Page 58: Installation Example Of 4 Muting Sensors
System Configuration and Functions Installation Example of 4 Muting Sensors This installation example uses 4 through-beam type photoelectric sensors as muting sensors. The use of 4 muting sensors is useful when the length of the workpieces (L) is constant or longer. Before a workpiece passes through Hazardous area F3SJ...
Page 59 System Configuration and Functions The muting sensors are blocked and the safety function of the F3SJ is disabled Hazardous area F3SJ Workpiece Muting sensors A1 and B1 are turned OFF but A2 and B2 are ON, so the muting function is still working.
Page 60 System Configuration and Functions This distance must prevent the muting function from being enabled by a person passing through the muting sensors. Also, install the F3SJ and muting sensors so that a workpiece passes through all muting sensors before the next workpiece arrives at the first muting sensor. Workpiece Workpiece Workpiece...
Page 61: Override Function
System Configuration and Functions Override Function The override function forcibly turns the safety outputs ON when the muting start condition is not satisfied. If a workpiece stops while passing through the detection zone of the F3SJ, as shown below, causing a muting error, the normal state cannot be recovered unless the workpiece is removed from the muting sensors and the detection zone of the F3SJ.
Page 62 System Configuration and Functions Override end conditions When either of the following conditions is satisfied, the function is released. •When 60 seconds has elapsed under the override status •All muting sensors are turned OFF •When the reset input is turns from OFF to ON and/or the test input turns from ON to OFF Override state can be released if a sensor transitions to lockout as well.
Page 63: External Test Function
System Configuration and Functions External Test Function This function forcibly stops the emission using an external signal. It can be used to verify that the safety system should stop properly when the F3SJ is interrupted. To stop the emission, apply 9~24V to the emitter's test input line. The voltage must be applied for a period 0.3s plus 4 times of Toff or longer.
Page 64: Resetting Lockout
System Configuration and Functions Resetting Lockout When the cause of the lockout is removed, the lockout condition can be released by using either of the following methods. •Cycle the power back ON •Set the reset input line open or to 0 to 1.5V for 300ms or longer, and then apply 9 to 24V again (except for lockout due to a communication error or a wiring error).
Page 65: Chapter3 Wiring/Installation
Chapter3 Wiring/Installation Installation Conditions Detection Zone and Approach Safety Distance Distance from Reflective Surfaces Mutual Interference Prevention Series Connection Connection Procedure Attaching External Indicators Connection Procedure Output Operation Dimensions When Using Standard Mounting Brackets When Using Optional Mounting Brackets When Using Spatter Protection Covers Mounting Top/Bottom Mounting Brackets Intermediate Mounting Brackets...
Page 66: Installation Conditions
Wiring/Installation Installation Conditions Detection Zone and Approach Install a protective structure so that the hazardous part of a machine can only be reached by passing through the sensor's detection zone. Install the sensors so that part of the person is always present in the detection zone when working in a machine's hazardous areas.
Page 67: Safety Distance
Wiring/Installation Safety Distance The safety distance is the distance that must be set between the F3SJ and a machine's hazardous part to stop the hazardous part before a person or object reaches it. The safety distance varies according to the standards of each country and the individual specifications of each machine. In addition, the calculation of the safety distance differs if the direction of approach is not vertical to the detection zone of the F3SJ.
Page 68 Wiring/Installation = 120mm . . . Formula (2) < If the result 100mm, use S = 100mm. If the result exceeds 500mm, use the following expression where K = 1,600mm/s. S=1,600mm/s x (Tm + Ts) + 8 x (d - 14mm) . . . Formula (3) <...
Page 69: Distance From Reflective Surfaces
Wiring/Installation Distance from Reflective Surfaces Install the sensor system so that it is not affected by reflective surfaces. Failure to do so may hinder detection, resulting in serious injury. Install the sensor system at distance D or further from highly reflective surfaces such as metallic walls, floors, ceilings, or workpieces, as shown below.
Page 70: Mutual Interference Prevention
Wiring/Installation Mutual Interference Prevention Do not use the sensor system with mirrors in a retro-reflective configuration. Doing so may hinder detection. It is possible to use mirrors to "bend" the detection zone to a 90-degree angle. When using more than 1 set of F3SJ, install them so that mutual interference does not occur, such as by configuring series connections or using physical barriers between adjacent sets.
Page 71 Wiring/Installation No connection Mutual interference is prevented in up to 3 sets, using interference light avoidance algorithm. If 4 or more sets of F3SJ are installed and are not connected to each other, arrange them so that mutual interference does not occur. If 2 sets are installed near each other, reflection from the surface of the F3SJ may cause mutual interference.
Page 72 Wiring/Installation Distance between emitter and Allowable installation distance D receiver (operating range L) For 0.2 to 3m 0.26m For 3m or more L x tan5 ° = L x 0.088 (m) When using 4 or more sets that are not series-connected, the installations shown below may cause mutual interference.
Page 73: Series Connection
Wiring/Installation Series Connection From 2 to 4 sets of F3SJ can be series-connected. Series connection allows them to be used as a a safety light curtain, requiring only 1 set to be wired to a controller and preventing mutual interference. If any 1 set of series-connected F3SJ is blocked, both of the safety outputs turn OFF.
Page 74: Connection Procedure
Wiring/Installation Connection Procedure When using the F39-JJR15L series connection cable for close contact (sold separately) Remove the connection cable of the F3SJ. (driver comes with F39-JJR15L) Remove the cap from the other F3SJ. Use the F39-JJR15L series connection cable for close contact to connect them. 1.
Page 75 Wiring/Installation The terms used in this document to describe each F3SJ in a series connection are shown below. Secondary sensor 3 Secondary sensor 2 Secondary sensor 1 Primary sensor When attaching a cable or cap, tightly fasten the screws (M2, in 4 places, recommended torque: 0.15N m). Failure to do so may cause the cable/cap to come loose, leading to deterioration of the protective functions.
Page 76 Wiring/Installation When using the F39-JJR3W series connection cable for extension (sold separately) Remove the caps from the primary sensor. (driver comes with key cap for muting) Use the F39-JJR3W series connection cable for extension to connect them. When changing the connection distance between the F3SJ, connect a F39-JC B Cable with connectors on both ends (sold separately).
Page 77: Attaching External Indicators
Wiring/Installation Attaching External Indicators An external indicator can be connected and turned ON based on the operation of the F3SJ. Indicators can be attached to emitters and/or receivers. Example: • Indicate that the F3SJ is in lockout • Indicate that a machine is stopped (safety output is OFF) •...
Page 78: Output Operation
Wiring/Installation Output Operation The external indicator output 1 (on the receiver side) is configured as "safety output reverse output (ON when blocked)", while the external indicator output 2 (on the emitter side) is configured as "lockout output (ON during lockout)". When the muting function is used, both the emitter and receiver are configured as muting/override output (ON during muting and during override).
Page 79: Dimensions
Wiring/Installation Dimensions When Using Standard Mounting Brackets Backside mounting Top/bottom mounting bracket Intermediate mounting bracket 2-Top/bottom mounting brackets 2-Mounting holes (Unit: mm) 4-M5 Intermediate mounting 2-M5 bracket 2-Mounting holes Beam 4-Mounting holes 2-Mounting holes M12 Waterproof connector Bracket mounting procedure (Mounting) p.75 AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A...
Page 80 Wiring/Installation Side mounting Top/bottom mounting bracket Intermediate mounting bracket 2-Top/bottom (Unit: mm) mounting brackets 2-Mounting holes Beam 4-Mounting holes 2-Mounting holes M12 Waterproof connector Bracket mounting procedure (Mounting) p.75 AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 81 Wiring/Installation Dimensions A to E C + 74 C + 46.5 4-digit number of the model name (protective height) C - 20 Depends on the protective height. See the table below. Dimension E Number of intermediate Protective height mounting brackets 0245 to 0596 0605 to 1130 1136 to 1658...
Page 82: When Using Optional Mounting Brackets
Wiring/Installation When Using Optional Mounting Brackets F39-LJ2 side-mounting optional bracket F39-LJ2 37.6 (Unit: mm) 4-M5 Material: Stainless steel Dimensions A to C C + 74 AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles C + 39.5 Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr 4-digit number of the model name (protective height) F3SJ-A...
Page 83 Wiring/Installation F39-LJ3 free-location mounting bracket Backside mounting (Unit: mm) 6-M5 AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 84 Wiring/Installation Backside mounting (Unit: mm) 6-M5 Material: Zinc die-cast/stainless steel AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 85 Wiring/Installation Dimensions B, C, and F C - 90 4-digit number of the model name (protective height) Depends on the protective height. See the table below. Dimension F Number of intermediate Protective height mounting brackets 245 to 440 443 to 785 794 to 1136 1145 to 1490 1495 to 1838...
Page 86 Wiring/Installation F39-LJ4 top/bottom mounting bracket B Backside mounting F39-LJ4 Use standard brackets (Unit: mm) 4-M5 19(*1) *1 A mounting width of 18 to 20 can be supported when mounting with M5 screws. AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 87 Wiring/Installation Side mounting F39-LJ4 Use standard brackets (Unit: mm) 4-M5 19(*1) Material: Stainless steel *1 A mounting width of 18 to 20 can be supported when mounting with M5 screws. Dimensions A to C C + 109 C + 66 AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr 4-digit number of the model name (protective height)
Page 88 Wiring/Installation F39-LJ5 replacement bracket for F3SN Use these replacement brackets for an F3SN with a small protective height. (These brackets are designed for use with the F3SN's mounting holes.) Inward-facing mounting Use standard brackets F39-LJ5 (Unit: mm) 4-M5 19.9 Material: Stainless steel Dimensions A to C C + 23 C - 10...
Page 89 Wiring/Installation Outward-facing mounting Use standard F39-LJ5 brackets (Unit: mm) 4-M5 19.9 Material: Stainless steel Dimensions A to C C + 65 C + 34 4-digit number of the model name (protective height) AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 90 Wiring/Installation Inward + outward-facing mounting Use standard F39-LJ5 brackets (Unit: mm) 4-M5 19.9 Material: Stainless steel Dimensions A to C C + 44 C + 12 4-digit number of the model name (protective height) AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 91 Wiring/Installation F3SN replacement correspondence table (F3SN mounting holes can be used without modification) •When replacing F3SN- P14 with F3SJ-A F3SN Replacement F3SJ Replacement method using F39-LJ5 Model name Protective height Model name Protective height F3SN- 0153P14 F3SN- 0180P14 F3SJ-A0245P14 Inward-facing mounting F3SN- 0189P14 F3SJ-A0245P14 Inward-facing mounting...
Page 92: F39-A01Po-Pac External Indicator Set
Wiring/Installation F39-A01P -PAC External Indicator Set •F39-A01P -PAC (Unit: mm) Material: Stainless steel When Using Spatter Protection Covers Dimensions of the spatter protection cover F39-HJ , F39-HJ -20, F39- (Unit: mm) -10 mm Material: PC (protective cover) Assembly dimensions (Unit: mm) AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A...
Page 93: Mounting
Wiring/Installation Mounting The procedures for using standard mounting brackets (included) are explained in this section. Top/Bottom Mounting Brackets Mounting screws (M5x18) x 4 Top/bottom mounting bracket (2) x 4 Top/bottom mounting bracket (1) x 4 Top/bottom mounting bracket (3) x 4 *1 The quantities shown here are the number of Mounting screws (M3x8) x 8 parts included in 1 top/bottom mounting bracket set...
Page 94: Mounting Procedure
Wiring/Installation Mounting Procedure Attach the top/bottom mounting bracket (1) to a wall or pillar. Place the top/bottom mounting bracket (2) in the screw hole at the top or bottom of the F3SJ, and tighten it with an included screw (M5x18). Use the top/bottom mounting bracket (3) and (1) to hold the top of the F3SJ, and fasten them lightly with the included screws (M3x8).
Page 95 Wiring/Installation For backside mounting, attach the intermediate mounting bracket (1) to a wall or pillar. Using the included mounting screws (M3x10), lightly fasten the intermediate mounting brackets (2) and (3) so that they are able to slide on the casing. Using the included mounting screws (M4x25), lightly fasten the intermediate mounting bracket so that the F3SJ can slide right and left.
Page 96 Wiring/Installation For side mounting, attach the side-mounting intermediate bracket to a wall or pillar, and then use the included mounting screws (M5x10) to fasten the intermediate mounting bracket (1). AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 97: Wiring
Wiring/Installation Wiring Wiring Precautions Double or reinforced insulation from hazardous voltage must be applied to all input and output lines. Failure to do so may result in electric shock. Connect the load between the output and 0V line. (PNP output) Connecting between the output and +24V line is dangerous because the operation mode is reversed to "ON when blocked".
Page 98: Power Supply Unit
"circuit protection such as a fuse is used to limit the current, which has a rating of 4.2A max." (24VDC power supply). Recommended power supply: OMRON S82K (15 W, 30 W, 50 W, 90 W type), S8VS (60 W type), S82J (10 W, 25 W, 50 W type) These products are approved by UL listing (UL508, class 2 power supply), CE marking compatible (EMC/Low Voltage Directive).
Page 99: Wiring Procedure
Wiring/Installation Wiring Procedure Connect an emitter cable (F39-JC -L, grey, sold separately) to the emitter's connection cable (grey). Connect a receiver cable (F39-JC -D, black, sold separately) to the receiver's connection cable (black). Connect the 0V line of the power supply directly to the protective earth (PE). To ensure proper wiring, check that the color of the cable matches the color of the connector's resin cover (emitter: grey, receiver: black).
Page 100 Wiring/Installation Series connection cable for close contact(F39-JJR15L, sold separately) (Unit: mm) 33.4 33.4 Set model name For emitter For receiver L (mm) F39-JJR15L F39-JJR15L-L Grey cable F39-JJR15L-D Black cable Series connection cable for extension (F39-JJR3W, sold separately) (Unit: mm) 33.4 Ferrite shield 39.5 21.4...
Page 101 Wiring/Installation Connection cable (F39-JJR3K, sold separately) The connection cable is a standard included product. Purchase a replacement when damaged or lost. (Unit: mm) 33.4 Connector 21.4 Body color: Black M12 Waterproof connector (plug) Vinyl-insulated round cable: Diameter 6 8-wire (Cross section of conductor: 0.15mm / Insulator diameter: 1mm) Set model name For emitter...
Page 102 Wiring/Installation Internal wiring diagram (F39-JC B-L, F39-JC B-D) Connected to connection cable and Connected to single-end connector cable, Cable Cable with connectors on both ends with connectors on both ends, Controller F3SP-B1P White White Brown Brown Green Green Yellow Yellow Grey Grey Pink...
Page 103 Wiring/Installation *1. Use only 1 set of F39-JC C. If the cable length is insufficient, use F39-JC B for extension. Internal wiring diagram (F39-JC C-L) Connected to emitter's connection cable Connected to controller G9SA-300-SC and Cable with connectors on both ends Blue Brown Brown...
Page 104: Adjustment Procedure
Wiring/Installation Adjustment Procedure Check the following points: - The optical surface of the emitter and receiver should be clean. - There should be no interrupting object in the detection zone of the F3SJ. Adjust the emitter's beams. Adjust the angle of the emitter while checking the incident light level indicator, and align the emitter so that it faces the center position where the incident light level indicator turns ON.
Page 105: Chapter4 Input/Output Circuit And Applications
Chapter4 Input/Output Circuit and Applications Input/Output Circuit Wiring Examples Connecting to an F3SP-B1P Using only F3SJ Connecting a muting sensor Connecting to an F3SX-E-L2R Connecting to a G9SA-301 Connecting to a G9SA-300-SC Connecting to a G9SB-301-D AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 106: Input/Output Circuit
Input/Output Circuit and Applications Input/Output Circuit The numbers in white circles indicate the connector's pin numbers. The black circles indicate connectors for series connection. The words in brackets [ ] indicate the signal name for muting system. Indication External indicator output 2 +24V DC Brown Brown...
Page 107: Audin - 8, Avenue De La Malle - 51370 Saint Brice Courcelles
Input/Output Circuit and Applications Wiring Examples Some examples of a motor control system using F3SJ are shown. The category of these systems defined by EN954-1 is 4. Connecting to an F3SP-B1P •Reduced wiring due to connector connection •Safety relay included Emitter Receiver - Manual reset mode...
Page 108: Using Only F3Sj
Input/Output Circuit and Applications Using only F3SJ •Use of relay contact welding detection and interlock is possible without a controller or relay unit - Manual reset mode - Using external device monitoring function Emitter Receiver F39-JC F39-JC Communication line (+) (Grey) Communication line (-) (Pink) KM1 KM2...
Page 109: Connecting A Muting Sensor
Input/Output Circuit and Applications Connecting a muting sensor • Attaching a key cap for muting (F39-CN6) enables the muting function to be used Attaching the key cap for muting (F39-CN6) p.32 Muting lamp (external indicator) - Auto reset mode - Using external device monitoring function Emitter Receiver F39-JC A-L...
Page 110: Connecting To An F3Sx-E-L2R
Input/Output Circuit and Applications Connecting to an F3SX-E-L2R •Emergency stop switch can be connected •Door switch, two hand control, single beam, or relay unit can be used in combination with F3SX •Various settings can be changed and input/output terminals can be monitored using the setting support software for F3SX L2 Module - F3SJ settings...
Page 111 Input/Output Circuit and Applications •Using a branch connector Connector connection is possible using a cable with connectors on both ends and branch connector for safety light curtains. F3SJ F3SJ Receiver Emitter Branch connector for safety light curtains F39-CN5 Grey Black Cable with connectors on both ends: Cable with connectors on both ends F39-JC...
Page 112: Connecting To A G9Sa-301
Input/Output Circuit and Applications Connecting to a G9SA-301 Emitter Receiver - F3SJ settings - Auto reset mode - Does not use external device monitoring function - G9SA-301 settings - Manual reset mode - Using feedback loop - Using emergency stop switch Model F39-JC Model F39-JC Communication...
Page 113: Connecting To A G9Sa-300-Sc
Input/Output Circuit and Applications Connecting to a G9SA-300-SC •Reduced wiring due to connector connection - F3SJ settings - Auto reset mode - Not using external device monitoring Emitter Receiver - G9SA-300-SC settings - Manual reset mode - Using feedback loop Model F39-JC Model F39-JC +DC24V...
Page 114: Connecting To A G9Sb-301-D
Input/Output Circuit and Applications Connecting to a G9SB-301-D •Thin (22.5mm thick) Emitter Receiver - F3SJ settings - Auto reset mode - Does not use external device monitoring function - G9SB-301-D settings - Manual reset mode - Using feedback loop F39-JC A-L F39-JC A-D Communication line (+) (Grey)
Page 115: Connecting To A G9Sx-Ad322-T15
Input/Output Circuit and Applications Connecting to a G9SX-AD322-T15 •Can be configured for partial control and total control •Can be extended to connect a door switch or a relay unit Receiver Emitter - F3SJ settings - Auto reset mode - Not using external device monitoring - G9SX-AD322-T15 settings - Auto reset mode - Using feedback loop...
Page 116 Input/Output Circuit and Applications AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 117: Chapter5 Checklists
Chapter5 Checklists Pre-Operation Checklists Maintenance Checklists Daily Maintenance 6-Month Inspection AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 118: Pre-Operation Checklists
Checklists Pre-Operation Checklists Make sure to test the operation of the F3SJ after installation to verify that the F3SJ operates as intended. Make sure to stop the machine until the test is complete. Unintended function settings may cause a person to go undetected, resulting in serious injury.
Page 119 Checklists To check detection, move the test rod as shown in the diagram below. Start Stop When the external test function is used: The OFF-state indicator turns ON when the test input line is short-circuited to 9 to 24V. When the external device monitoring function is used: When the F3SJ is blocked and the external device monitoring input terminal is open, it enters a lockout state.
Page 120: Maintenance Checklists
Checklists Maintenance Checklists Perform daily and 6-month inspection for the F3SJ. Otherwise, the system may fail to work properly, resulting in serious injury. Do not try to disassemble, repair, or modify this product. Doing so may cause the safety functions to stop working properly.
Page 121: 6-Month Inspection
Checklists 6-Month Inspection Items to inspect every 6 months or when machine settings are changed The machine itself does not prevent the operation of safety functions such as stopping. No modifications or connection changes have been made to the machine that may have an adverse effect on the machine's control system.
Page 122 Checklists AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 123: Chapter6 Appendix
Chapter6 Appendix Troubleshooting Lockout State Accessories (Sold Separately) Glossary Related Standards International Standards European Standards U.S. Federal regurations U.S. Standards Canadian Standards Revision History AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr F3SJ-A User’s Manual...
Page 124: Troubleshooting
Appendix Troubleshooting Lockout State When a sensor enters lockout, the error mode indicator for the emitter or receiver in which the error occurs turns ON or blinks to indicate the error details. Solve the problems based on the table below. Blinking Error mode indicator Description...
Page 125 Appendix Error mode indicator Description Cause Solution ± Power supply capacity Power supply voltage is outside the Connect to a 24VDC 20% power error rated range. supply voltage. Voltage fluctuation due to insufficient Replace the power supply with one power supply capacity. that has a larger capacity.
Page 126: Accessories (Sold Separately)
Appendix Accessories (Sold Separately) Cable with connector on one end (2 cables per set, for emitter and receiver) Appearance Model name Cable length Specifications F39-JC3A M12 connector (8-pin) - 8 wires + Shield F39-JC7A F39-JC10A F39-JC15A F39-JC20A Cable with connectors on both ends: For connection with F3SP-B1P or cable extension (2 cables per set, for emitter and receiver) Appearance Model name...
Page 127 Appendix Series connection cable for close contact (2 cables per set, for emitter and receiver) Appearance Model name Cable length Specifications F39-JJR15L 0.15m Cap (10-pin) - Cap (10-pin) Series connection cable for extension (2 cables per set, for emitter and receiver) Appearance Model name Cable length...
Page 128 Appendix Control unit Appearance Model name Output F3SP-B1P Relay, 3a+1b * If the F3SJ is connected to the F3SP-B1P control unit, it cannot be used as a muting system. Key cap for muting Appearance Model name Note F39-CN6 Case color: Orange Can be used for emitter and receiver Branch connector for safety light curtains Appearance...
Page 129 Appendix Spatter protection cover (2 cables per set, common for emitter/receiver) Model name Appearance Note F39-HJ To be applied to sensors with protective height up to 1955; F3SJ-A14 series (beam gap of 9mm) F3SJ-A20 series (beam gap of 15mm) F3SJ-A30 series (beam gap of 25mm) F39-HJ To be applied to sensors with protective height of 1970 or more;...
Page 130 Appendix Top/bottom mounting bracket B Appearance Model name Application Note F39-LJ4 Mounting bracket used when 2 brackets for emitter, 2 replacing existing area sensors brackets for receiver (4 brackets with the F3SJ. Suitable for per set) mounting hole pitch of 18 to (Use in combination with top/ 20mm.
Page 131: Glossary
Appendix Glossary Auto reset Setting status by which the safety output automatically turns ON when the F3SJ receives light after the power is turned ON and after the F3SJ is blocked. Auxiliary output 1 Provides an inverted signal of the safety output. This CANNOT be used for safety applications. Detection capability Minimum size of an object that can be detected in the protective height of the F3SJ.
Page 132: Related Standards
Appendix Related Standards International Standards • IEC61496-1 Safety of machinery - Electro-sensitive protective equipment - Part 1: General requirements and tests • IEC61496-2 Safety of machinery - Electro-sensitive protective equipment - Part 2: Particular requirements for equipment using active opto-electronic protective devices •...
Page 133: Canadian Standards
Appendix • ANSI B11.18 Machines and machinery systems for processing strip, sheet or plate from coiled configuration • ANSI B11.19 Performance criteria for the design, construction, care, and operation of safeguarding when referenced by the other B11 machine tool safety standards •...
Page 134: Revision History
Appendix Revision History The revision symbols of the manual are attached to the catalog number in the lower part of the front cover and back cover. Catalog number SCHG-710 C Revision No. Revision Revision date Revisions symbol January, 2005 First edition January, 2005 Minor correction February, 2005...
Page 135 Tel: (49)7032-811-0 / Fax: (49)7032-811-199 OMRON ELECTRONICS LLC 1 East Commerce Drive, Schaumburg, Illinois 60173-5302 U.S.A. Tel: (1)847-843-7900 / Fax: (1)847-843-7787 OMRON ASIA PACIFIC PTE. LTD. 83 Clemenceau Avenue, #11-01, UE Square, Singapore 239920 SINGAPORE Tel: (65)835-3011 / Fax: (65)835-2711 OMRON (CHINA) CO., LTD.
Page 136 Authorized Distributor: AUDIN - 8, avenue de la malle - 51370 Saint Brice Courcelles Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr Note: Specifications subject to change without notice. SCHG-710C Printed in Japan...
