Omron F3SG-RE Series Quick Installation Manual
Safety light curtain
Hide thumbs
Also See for F3SG-RE Series:
- User manual (270 pages) ,
- User manual (268 pages) ,
- Quick installation manual (44 pages)
Advertisement
Available languages
Available languages
Quick Links
Safety Light Curtain
□
F3SG-
RE Series
http://www.ia.omron.com/f3sg-r
Quick Installation Manual
Document Title
Cat. No.
Safty Light Curtain F3SG-R Series User's Manual
Z352-E1
© OMRON Corporation 2015-2021 All Rights Reserved.
8900153-0C
Original instructions
Advertisement
Related Manuals for Omron F3SG-RE Series
Summary of Contents for Omron F3SG-RE Series
- Page 1 Safety Light Curtain □ F3SG- RE Series http://www.ia.omron.com/f3sg-r Quick Installation Manual Document Title Cat. No. Safty Light Curtain F3SG-R Series User's Manual Z352-E1 © OMRON Corporation 2015-2021 All Rights Reserved. 8900153-0C Original instructions...
- Page 4 Safety Light Curtain F3SG-R Series User's Manual. <Emitter> <Receiver> Beam center-line mark 1. Top-beam-state indicator (Blue) Beam Emitter Indicator Receiver 2. Operating range indicator (Green) 3. Power indicator (Green) 9. Internal error indicator (Red) 4. Lockout indicator (Red) 10. Lockout indicator (Red) Power Cable 11.
- Page 5 <Emitter> <Receiver> 1. Top-beam-state indicator (Blue) 2. Operating range indicator (Green) 3. Power indicator (Green) 9. Internal error indicator (Red) 4. Lockout indicator (Red) 10. Lockout indicator (Red) 11. Stable-state indicator (Green) 12. ON/OFF indicator (Green/Red) 13. Communication indicator (Green) 14.
- Page 6 F3SG-R Series User's Manual...
- Page 7 F3SG-R Series User's Manual F3SG-R Series User's Manual. µ...
- Page 8 4. LED Indicators Ω F3SG-R Series User's Manual...
- Page 9 F3SG-R Series User's Manual. F3SG-R Series User's Manual.
-
Page 10: Operation Check
Setup Wiring Mounting/Beam Alignment Operation check Done Indicator +24 V Brown Operating Range Operating Range White Select Input Select Input circuit Emitter Black Not used Main Circuit Blue Brown Receiver White OSSD 2 Main Circuit 2 Load Black OSSD 1 Receiver Main Circuit 1 Load... - Page 11 Indicator +24 V Brown Operating Range White Select Input Operating Range Select Input circuit Emitter Black Not used Main Circuit Blue Brown Load Receiver White OSSD 2 Main Circuit 2 Load Black OSSD 1 Receiver Main Circuit 1 Indicator Blue...
- Page 12 Wiring Mounting/Beam Alignment Operation check Safety Light Curtain F3SG-R Series User's Manual +24 V Power Supply F3SG-R Series User's Manual Safety Controller *1 *2 +24 V Power Supply F3SG-R Series User's Manual Safety Controller *1 *2...
- Page 13 Safety distance (S) Hazard...
- Page 14 Detection Zone Orthogonal to Direction of Approach Safety distance (S) Hazard 300 mm max. Reference plane...
- Page 15 Detection Zone Orthogonal to Direction of Approach 9-1. Safety Distance Formulas according to ISO 13855/EN ISO 13855 Safety distance (S) Hazard Safety distance (S) Hazard Detection Warning F3SG-R Series User's Manual zone zone Distance L from casing end to detection zone...
- Page 17 Wiring Mounting/Beam Alignment Operation check Step1 Check position Step2 Mount 2-M5 or M6 Standard Fixed Bracket (F39-LGF) Standard Fixed Bracket (F39-LGF) 2-M5 or M6 24.85 24.85 Safety Light Curtain F3SG-R Series User's Manual...
- Page 18 Wiring Mounting/Beam Alignment Operation check Step1 Hexagon socket head Check Fixed Bracket position cap screw (M3 x 15) Step2 hook Mount <Backside mounting> <Side mounting> Optical surface Optical surface of F3SG-RE of F3SG-RE Slide the hook in the groove Fixed Bracket Fixed Bracket Slide the hook in the groove...
- Page 19 Wiring Mounting/Beam Alignment Operation check Step1 Check position 48.6 Step2 Mount 2-M5 or M6 Step3 Standard Adjustable Bracket Align (F39-LGA) beams Standard Adjustable Bracket (F39-LGA) 2-M5 or M6 24.85 24.85 Safety Light Curtain F3SG-R Series User's Manual...
- Page 20 Wiring Mounting/Beam Alignment Operation check Step1 hexagon socket head Check position cap screw (M3 x 15) hexagon socket head hook Step2 cap screw (M3 x 15) Mount Step3 Align <Backside mounting> <Side mounting> beams Optical surface Optical surface of F3SG-RE of F3SG-RE Slide the hook in the groove...
- Page 21 Wiring Mounting/Beam Alignment Operation check <Emitter> <Receiver> <Receiver> <Receiver> Step1 TOP(Blue) TOP(Blue) Check position Step2 Mount STB(Green) STB(Green) Step3 BTM(Blue) BTM(Blue) Align beams <Backside mounting> <Side mounting> Tightening torque: 2.0 N•m (recommended) <Enlarged view> Hexagon socket head cap screw (M3x15)
-
Page 22: Suitability For Use
