Access the menu for printhead replacement

• When replacing the Printhead immediately after printing, wait a few minutes before replacing it. The metal parts
of the Printhead become hot during printing, and there is a risk of burns from touching these parts.
• Your hands may become dirty during Printhead replacement. Use the gloves provided with the new Printhead for
replacement.
• Prepare a new Ink Tank when ink levels are low.
• When the remaining capacity of Maintenance Cartridge is low, prepare a new Maintenance Cartridge .
1
Remove any paper that has been advanced by selecting
Eject Paper in the Control Panel menu.
• When using a roll, rewind it.
(→ , Removing the Roll from the Printer)
• When using sheets, remove the sheet.
(→ , Removing Sheets)
2
Clean inside the Top Cover . (→
3
On the Tab Selection screen of the Control Panel , press
◄ or ► to select the Settings/Adj. tab (
• If the Tab Selection screen is not displayed, press the Menu button.
4
Press the OK button.
The Set./Adj. Menu is displayed.
5
Press ▲ or ▼ to select Maintenance , and then press the
OK button.
6
Press ▲ or ▼ to select Replace P.head , and then press
the OK button.
7
Press ▲ or ▼ to select the Printhead for replacement.
Select Printhead L when replacing the left printhead and
Printhead R when replacing the right printhead. Make
sure your selection is correct.
8
Press the OK button.
Ink is now fi lled.
After about three minutes, a message is shown on the
Display Screen instructing you to open the Top Cover .
, If Paper is Soiled)
).
37
Replacing the Printhead
Ready
OK:Setting/Adj. Menu
Maint.C Remain.: 80%
Tot.Print Area(m2):
678
