Loading Rolls On The Roll Holder - Canon imagePROGRAF iPF6300S Basic Guide No.1 Basic Manual

When printing on rolls, attach the Roll Holder to the roll.
Rolls have a two- or three-inch paper core. Use the correct attachment for the paper core. The printer comes
equipped with the 2-Inch Paper Core Attachment installed.
For borderless printing on A1 (594 mm) or A2 (420 mm) rolls, attach the included Spacer for Borderless Printing
to the Roll Holder .
Items to Prepare
• Set the roll on a table or other fl at surface so that it does not roll or fall. Rolls are heavy, and dropping a roll may
cause injury.
• When handling the roll, be careful not to soil the printing surface. This may affect the printing quality. We recommend
wearing clean cloth gloves when handling rolls to protect the printing surface.
• Use scissors or a cutting tool to cut the edge of the roll paper if it is uneven, dirty, or has tape residue. Otherwise, it
may cause feeding problems and affect the printing quality. Be careful not to cut through any barcodes printed on
the roll.
• Align the edges of the paper on both ends of the roll. Misalignment
may cause feeding problems.
• For details on supported sizes and types of rolls, see " Paper Sizes " or the Paper Reference Guide .
(→"Paper Sizes," User's Guide) , (→"Types of Paper," User's Guide)
• To view instructions as you attach the Roll Holder , press the Navigate button.
1
Remove the Holder Stopper from the Roll Holder .

Loading Rolls on the Roll Holder

Attach rolls to the Roll Holder as follows.
• Using rolls with a 2-inch paper core
Holder Stopper for 2-inch paper cores (a)
• Using rolls with a 3-inch paper core
Holder Stopper for 3-inch paper cores (b)
3-Inch Paper Core Attachment (c)
• Borderless printing on A1 or A2 rolls
Spacer for Borderless Printing (d)
14
a b
d
c
