Canon imagePROGRAF W2200S Setup Manual

Graphic color printer
Hide thumbs Also See for imagePROGRAF W2200S:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Graphic Color Printer

Advertisement

Table of Contents
loading

Related Manuals for Canon imagePROGRAF W2200S

Summary of Contents for Canon imagePROGRAF W2200S

  • Page 1 Graphic Color Printer...
  • Page 2 • Every effort has been made to ensure that the information contained in this guide is correct. If any error or omission is found, contact us directly or an authorized Canon representative. • Canon is not responsible for any damages, direct or indirect, arising from or related to the use of this printer. Trademarks •...
  • Page 3 Notations About Text Conventions To ensure the safe and most efficient use of this printer, important information is provided under the headings listed below. Before you use this guide, make sure that you understand what these headings mean and remember the important information described under these headings. Warning z Failure to follow these instructions could result in fatal or serious injury.

  • Page 4: Abbreviations

    Abbreviations Throughout this document the following abbreviations are used in text. • Microsoft Me” • Microsoft • Microsoft • Microsoft • Microsoft • Microsoft • Microsoft • The term “GARO”, used in the name of this printer driver, is an acronym for “Graphic Arts Language with Raster Operations”, a printer language of creating raster images.

  • Page 5: Regulations For This Product

    Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or modifications should be made, you could be required to stop operation of the equipment. Canon U.S.A. Inc. One Canon Plaza, Lake Success, NY 11042, U.S.A. Tel No. 516-328-5600...

  • Page 6: Canadian Radio Interference Regulations

    Their standards and logos are uniform among participating nations. ® Program TAR ® Partner, Canon Inc. has NERGY NERGY TAR ® Office Equipment Program is a global ®...

  • Page 7: Safety Warnings And Precautions

    Safety Warnings and Precautions Read and follow all the warnings and guidelines described below to prevent the hazards of fire or electrical shock and ensure safe use of this printer. Warning TLocation z The electrical contacts inside the printer become extremely hot during normal operation.
  • Page 8 TIn an Emergency ... z To avoid a fire or serious electrical shock, if the printer emits smoke or a strange odor, immediately press the Power button to switch the printer off and unplug the power cord from the power supply. Discontinue using the printer and call for service.
  • Page 9 z To ensure normal operation of the printer and avoid possible damage, never install the printer near large office equipment or any other type of electrical device that emits a strong magnetic field. TMoving the Printer z To avoid dropping and damaging the printer or the paper feed unit or causing personal injury when moving it, always grip the printer or the paper feed unit by the lift handles provided on the left and right side of the printer or the paper feed unit.
  • Page 10 z The electrical contacts of the printhead become extremely hot during normal operation. To avoid minor burns, never touch the electrical contacts after removing the printhead from the printer. TGeneral Caution z There are high voltage points inside the printer. To avoid a fire or electrical shock, never attempt to disassemble the printer or attempt repairs.

  • Page 11: Table Of Contents

    Contents Notations About Text ........i Conventions .
  • Page 12 Chapter 3 Installing the Software Installing a Windows TCP/IP Network Connection ... . 3-2 TCP/IP Network Connection Software ......3-2 Preparing the Windows TCP/IP Function .

  • Page 13: Chapter 1 Setting Up The Printer

    Setting Up the Printer This chapter describes how to set up the printer, starting with unpacking the box.

  • Page 14: Setup Flow

    Setup Flow The printer is set up in the following order. Follow the procedures suited for your computer, the method of connection, and the options that you want to install. Unpack and Make Sure You Have Everything Setting Up the Printer Select a Location for the Printer Connect the Power Cord Install the Printhead...

  • Page 15: Unpack And Make Sure You Have Everything

    1 Unpack and Make Sure You Have Everything The items below are provided with the printer. Check each item against the list below to make sure that you have everything. If any item is missing or damaged, contact the store where you purchased the printer. Printer Paper cassette Power cord...
  • Page 16 the CD-ROM, click the language folder of your choice, and browse. Even if you have been provided with other language copies of the guides, please remember that the guides are also available in other languages on the CD-ROM. z Two user software CD-ROMs may be provided. The type of software stored on each CD-ROM is the same, but the languages are different.

  • Page 17: Select A Location For The Printer

    2 Select a Location for the Printer Select a safe, convenient location for the printer and set it up correctly. Space Requirements Make sure that there is sufficient space around printer at the location you select for the printer. THeight TWidth and Depth 1241 mm (48.8 in.) 2 Select a Location for the Printer...

  • Page 18: Remove The Packing Material And Position The Printer

    Remove the Packing Material and Position the Printer Tape, spacers, and other packing materials are attached to the printer to protect it during shipping. All of these packing materials must be removed before you use the printer. Important z Save the printer box and all packing materials. You will need these items again if you need to move or ship the printer.
  • Page 19 Remove the front upper cover and the back upper cover. Remove the stopper and tape from inside the printer where you removed the back upper cover. 2 Select a Location for the Printer...
  • Page 20 To remove the feed roller stopper, remove the tape (a), lift the stopper up (b), slide it down and to the side (c), then remove it (d). Attach the front upper cover and back upper cover. Remove all of the tape from the paper cassette, then remove the tray from the cassette.
  • Page 21 Grip the printer firmly by the lifting points provided on the lower left and lower right sides of the printer and move it to where you want to set it up. If you intend to install the optional paper feed unit and paper cassette, position the paper feed unit first.

  • Page 22: Connect The Power Cord

    3 Connect the Power Cord After positioning the printer, follow this procedure to connect the power cord. Connect the power cord provided with the printer to the power connector on the left side of the printer. Plug the other end of the connector into the power source. Important z When this printer is connected to the network, verify the status of its connection by the lit LNK and 100 lamps, after turning the power on.
  • Page 23 z If the LNK lamp does not light or if it is flashing, check the following: • Is the HUB switched on? Æ If the HUB is switched off, switch it on. • Is the LAN cable connected securely? Æ Confirm that the LAN cable connectors are clicked and locked in place securely. •...

  • Page 24: Install The Printhead

    4 Install the Printhead Install the printhead with the printer switched on. Read the messages in the printer display and follow the procedure below. Press the Power button to switch the printer on. After a few seconds “Install P.head Press Online Key” is displayed. Press the Online button.
  • Page 25 Pull the printhead lock lever out and lower it completely. Remove the tape on the printhead lock cover. Raise the printhead lock cover completely. 1-13 4 Install the Printhead...
  • Page 26 Hold the new printhead by its grips (a) and remove it from its case, then remove the first orange protective cap (b). While pressing inward on the tabs (d) of the second protective cap (c) as shown in the illustration, pull down to remove. Important z The nozzles under protective cap 2 (c) are covered with ink for their protection.
  • Page 27 With the nozzles facing down and the electrical contacts facing in, insert the printhead gently into the carriage below. Make sure that the nozzles are not touching the carriage and the printhead is inserted completely. Pull the printhead lock cover toward you and lower it completely until it locks.
  • Page 28 Re-attach the back upper cover. The right cover lock releases automatically. On the operation panel “Ins. Ink Tank OK” is displayed and the right cover lock is released. Go on to the next step to install the ink tanks. 1-16 Setting Up the Printer...

  • Page 29: Install The Ink Tanks

    5 Install the Ink Tanks After installing the printhead, install the 6 ink tanks: Y (Yellow) M (Magenta) PM (Photo Magenta) C (Cyan) PC (Photo Cyan) Bk (Black) Important z Before you use the printer the first time, you must install the ink tanks immediately after installing the printhead.
  • Page 30 Important z Always unlock the right cover before you try to open it. To prevent damaging the printer, never force the right cover open. Push up the ink tank lever for the color to set, then open the ink tank cover.
  • Page 31 With the ink ports facing down and the label facing in the direction as shown in the illustration below, insert the ink tank into the holder. Important z Always match the color of the ink with the correct holder before inserting it. The ink tank cannot be installed if you try to install it in the wrong holder or position it incorrectly.
  • Page 32 After all ink tanks have been installed, close the right cover. Press down the right cover gently until you hear it click and lock. After successful installation of the printhead and the ink tanks, “Ink Filling…” is displayed on the operation panel and the ink automatically starts flowing.

  • Page 33: Selecting The Display Language

    6 Selecting the Display Language The display language is set for English when the printer is shipped. Follow the procedure below to select another language. Note z If you want to continue with the English display, go to “7 Load the Paper Cassette”.
  • Page 34 Press E x t . F e a t u r e s L a n g u a g e Press L a n g u a g e = U s An equals sign (=) to the left of a setting indicates your language. Press the Online button to light the Online lamp.

  • Page 35: Load The Paper Cassette

    7 Load the Paper Cassette Follow the procedures below to load the paper cassette. • Loading the paper or other print media in the cassette. • Selecting the media size and type on the operation panel. Loading the Media Follow the procedures below to load the paper cassette provided with the printer.
  • Page 36 Hold the lever on the cassette length guide so it moves freely and move the guide to the holes for the size of the paper. Marks for standard paper sizes are provided on the length guide. Move the guide to the desired mark. Hold the lever on the width guide so it moves freely and move the guide to the paper size mark.
  • Page 37 Pick up a stack of media and fan it to remove static cling. Tap the edges of the stack against a flat surface to align the edges. With the print side (b) facing down, load the stack (c) in the cassette with the length guide against the bottom of the stack.
  • Page 38 z To avoid paper jams, make sure that the trailing edge length guide, and make sure that the edges at (d) are straight and not slanted. z Wait for all of the paper in the cassette to be used up before loading more paper. z Never mix different types of paper or other print media in the same stack.
  • Page 39 Set the paper cassette in the printer. Push the paper cassette completely into the printer. Important z You must set the slide lever to the center position to enable paper feed from the cassette. Note z The output tray extension should be used to prevent large size media from falling off the tray after it is ejected from the printer.

  • Page 40: Media Size And Media Type Settings

    Media Size and Media Type Settings After loading paper or other print media in the paper cassette, you must use the operation panel menus to select the type and size of the paper or other print media loaded in the cassette. Paper size settings are required only when using B5-JIS.
  • Page 41 Note z The printer is shipped from the factory with the “Media Size” set for “B5-JIS” and the “Media Type” set for “Plain Paper”. z It is recommended that the special settings (1 to 5) be used when smudges and blots appear on the print density is too light while printing on one of the media types listed above.
  • Page 42 Select the cassette. If A4, B4, A3, A3+,13x22 in, Letter, Legal, or Ledger size paper is loaded in the paper cassette, the size is selected automatically. So you can go to Step 6. z If the optional cassette is not installed.  Confirm that “Cassette 1”...
  • Page 43 Press to display the media type loaded and press M e d i a T y p e → = P l a i n P a p e r An equals sign (=) displayed to the left of the setting indicates the current Media Type selection.

  • Page 44: Select The Interface

    8 Select the Interface If the printer is connected to the computer through the USB or parallel port, you must use the printer operation panel to select the appropriate interface setting. If the correct interface setting is not selected, the printer will not be able to communicate with the computer.
  • Page 45 Press to display “Interface Type” and press S e t I n t e r f a c e I n t e r f a c e T y p e → Press to display the setting for the interface connection and press I n t e r f a c e T y p e →...

  • Page 46: Confirm The Print Status Of The Printer

    9 Confirm the Print Status of the Printer After the printer and computer have been prepared, print a Nozzle Check pattern to confirm that ink is supplied correctly from each nozzle. Before printing, load A4 or Letter size paper in Cassette 1. Important z Always load A4 or Letter sized paper in Cassette 1.
  • Page 47 Press the Cancel Job/Utility button. The Utility Menu opens on the operation panel. Press to display “Nozzle Check” then press U t i l i t y M e n u → N o z z l e C h e c k The nozzle check pattern prints.

  • Page 48: Adjust The Printhead Position

    10 Adjust the Printhead Position After confirming that the nozzles are operating normally, print the printhead alignment pattern and set each adjustment value. Before printing, load A4 or Letter size paper in Cassette 1 Important z Always load A4 or Letter size paper in Cassette 1. If a smaller size is loaded, it may smear ink inside the printer and onto other media.
  • Page 49 Press the Setup button. The Setup Menu opens. Press to select “Adjust Printer” then press S e t u p M e n u A d j u s t P r i n t e r → Press to select “Adj. Printhead” then press A d j u s t P r i n t e r A d j .
  • Page 50 Press P o s i t i o n A d j u s t A d j . S e t t i n g A → Look at “A” on the printhead alignment pattern and determine the number of the vertical line that is least conspicuous. Press display that number then press A d j .

  • Page 51: Adjusting The Amount Of Line Feed

    11 Adjusting the Amount of Line Feed After adjusting the printhead position, print the LF setting pattern and adjust the amount of media feed. Before printing the LF setting pattern, load LF adjust paper provided with the printer into Cassette 1. Important z Always load A4 or Letter size media in Cassette 1.
  • Page 52 Press the Setup button. The Setup Menu opens. Press S e t u p M e n u A d j u s t P r i n t e r → Press A d j u s t P r i n t e r A d j .
  • Page 53 Press to select “Adj. Setting” then press L F A d j u s t A d j . S e t t i n g Look the LF setting pattern and determine the number of the horizontal line that is least conspicuous. Press number then press A d j .
  • Page 54 1-42 Setting Up the Printer...

  • Page 55: Setting The Printer Network Information

    Setting the Printer Network Information This chapter describes the printer network settings required when the printer is connected to a TCP/IP network or used as a Remote UI. These settings should be done by the network administrator or the printer manager.

  • Page 56: Software For Network Settings

    Software for Network Settings When this printer is connected to a TCP/IP network, the IP address, subnet mask, and other network information settings are required for the printer. We recommend that you set the IP address with the GARO Device Setup Utility first, and then use the Remote UI to set the subnet mask, default gateway, and other network information settings.

  • Page 57: Setting With The Garo Device Setup Utility

    Setting with the GARO Device Setup Utility If you are using Windows, you can use the GARO Device Setup Utility to set the network information. Checking the Printer MAC Address For the network settings you need the printer MAC address (the number used to identify the built-in network interface board).
  • Page 58 Press the Cancel Job/Utility button. The Utility Menu opens. Press U t i l i t y M e n u E x t . I / F P r i n t → The information for the extended interface prints. The MAC address is printed at the location shown below.

  • Page 59: Installing The Garo Device Setup Utility

    Installing the GARO Device Setup Utility Important z If you are using Windows XP, Windows 2000, or Windows NT 4.0, you must log in as a member of the Administrators group. Mount the provided User Software CD-ROM in the CD-ROM drive. First, the language selection screen opens.

  • Page 60: Setting The Network Information

    Setting the Network Information On the desktop, click the Start button, point to Programs, then click “GARO Device Setup Utility”. Click the Settings button. Setting the Printer Network Information...
  • Page 61 In the MAC Address box, enter the MAC address, then click the Next button. Note z Enter the MAC address number for “Status Print” (without the colon). In the IP Address box under TCP/IP, enter the IP address assigned to the printer, then click the Next button.
  • Page 62 Check the settings, then click the Finish button. The settings are enabled. Read and confirm the displayed message, then click the OK button. Setting the Printer Network Information...
  • Page 63 Click the End button. Now you should perform the settings for the subnet mask and the default gateway. Use Internet Explorer or another browser to specify the IP address that you set here, and by starting the Remote UI you can easily perform the detailed network settings on the computer screen.

  • Page 64: Doing The Settings On The Printer Operation Panel

    Doing the Settings on the Printer Operation Panel The network information settings can be performed on the printer operation panel. The Frame type, DHCP, IP address, subnet mask, and default gateway settings can all be performed on the operation panel. Press the Online button to switch the Online lamp off.
  • Page 65 Press to select “Set TCP/IP” then press E x t . N e t w o r k S e t T C P / I P Press to select “Frame Type” then press S e t T C P / I P F r a m e T y p e Press to select “Ethernet II”...
  • Page 66 Press S e t T C P / I P I P S e t t i n g Press I P S e t t i n g I P A d d r e s s Press I P A d d r e s s = 1 9 2 .
  • Page 67 Press select the subnet mask digit to change then press S u b n e t M a s k = 0 . 0 . 0 . 0 The underscore (_) indicates the digit selected to change. Press to enter the subnet mask in use then press : Press to increase the number one by one.
  • Page 68 Press D e f a u l t G / W = 1 9 2 . 0 . 0 . 0 : Press to increase the number one by one. : Press to decrease the number one by one. The number after 0 is 255. D e f a u l t G / W = 1 9 2 .

  • Page 69: Installing The Software

    Installing the Software This chapter describes computer software and settings required to use the computer. Do the installation procedure on all the computers.

  • Page 70: Installing A Windows Tcp/Ip Network Connection

    Installing a Windows TCP/IP Network Connection This chapter describes the software and settings needed to connect the printer to a TCP/IP network with a Windows computer. Do the installation procedure on all Windows computers that use this printer. TCP/IP Network Connection Software To connect the printer to a TCP/IP network, the printer driver and an operating system with a TCP/IP print function are required.

  • Page 71: Preparing The Windows Tcp/Ip Function

    Preparing the Windows TCP/IP Function Before installing the printer driver, confirm that the functions required by the operating system have been installed. If they have not been installed, install the required functions from the operating system CD-ROM. Windows XP, Windows 2000 The operating system software required to connect to a TCP/IP network has already been installed.
  • Page 72 Windows 95 The operating system software required to connect to a TCP/IP network may not be included with the standard installation. To confirm whether the required software has been installed, on the desktop click the Start button, click Control Panel, open Network, then check the list on the Configuration sheet.

  • Page 73: Installing The Printer Driver To Windows

    Installing the Printer Driver to Windows Important z If your are using Windows XP, Windows 2000, or Windows NT 4.0, you must log in as a member of the Administrators group. Mount the provided User Software CD-ROM in the CD-ROM drive. Note z If the AutoPlay function is switched off, double-click the My Computer icon on the desktop, click the CD-ROM drive icon, and then from the File menu select...
  • Page 74 Read the message on the “Welcome to the InstallShield Wizard for GARO Printer Driver” screen, then click the Next button. Note z If an older version of a USB or IEEE1394 driver is installed, a message will inform you that an older version of a USB or IEEE1394 driver is installed in your system. If you see this message, click the OK button to return to the Setup Menu, then select “Uninstall Old USB/IEEE 1394 Driver”...
  • Page 75 Press on the lever to remove the connector cover on the back of the printer. Note z Store the connector cover in a safe place. The connector cover must be re-attached after the LAN cable is disconnected or before moving the printer. Connect the LAN cable to the LAN port of the printer then connect it to the HUB port.
  • Page 76 Select “Search for Network Port to Install” then click the Next button. If you click the checkbox on for “After printer installation, install GARO Status Monitor”, the installation will continue with the installation of the GARO Status Monitor. Clicking this checkbox on to install the GARO Status Monitor is recommended.
  • Page 77 Click the Add/Delete button. A list displays the names of the printers that can be used on the network. Important z If the printer to install is not listed, click the Cancel button at once. Check the LAN cable connection and make sure that the printer is switched on, then click the Add/ Delete button again.
  • Page 78 Installing the Software click the Settings button. Windows 2000 or select “Canon LPR Port” for Windows Me, Windows 98, Windows 95 or select “LPR Port” for Windows NT 4.0, then click the OK button and follow the instructions on the screen.
  • Page 79 From the Printer List, select the printer that you want to install, then click the “Add to the Printer List for Driver Installation” button. Confirm the name of the printer in the “Printer List for Driver Installation” list, then click the OK button. 3-11 Installing a Windows TCP/IP Network Connection...
  • Page 80 Confirm the printer name and IP address in the list, then click the Next button. Confirm the content of the Printer List for Driver Installation, then click the Start button. When the next message asks you to confirm that you want to start the setup, click the Yes button.
  • Page 81 When the next message asks you to confirm that you want to read the README file, click the Yes or No button. If you click the Yes button, the README file opens. At Step 7 if you clicked the “After printer installation, install GARO Status Monitor”...

  • Page 82: Installing A Windows Usb Or Ieee1394 Connection

    Installing a Windows USB or IEEE1394 Connection If you are using the printer with a USB or IEEE1394 connection to a computer running Windows XP, Windows 2000, Windows Me, or Windows 98, install the software for the connection and do the required settings. Do the installation on the Windows computer where the printer is connected.

  • Page 83: Installing The Printer Driver To Windows

    Installing the Printer Driver to Windows A USB port can be connected with Windows XP, Windows 2000, Windows Me, or Windows 98. An IEEE1394 port can be connected with Windows XP, Windows 2000, or Windows Me. Important z The USB port and IEEE1394 port cannot be used at the same time. z If you intend to use the USB connection on a printer that is presently set up with a parallel connection, you must do the procedure on the printer operation panel to switch the printer interface setting to “USB”.
  • Page 84 On the Setup Menu, click “Install GARO Printer Driver”. Read the message on the “Welcome to the InstallShield Wizard for GARO Printer Driver” screen, then click the Next button. Note z If an older version of a USB or IEEE1394 driver is installed, a message will inform you that an older version of a USB or IEEE1394 driver is installed in your system.
  • Page 85 Read the terms of the end user license agreement, then select “I accept the terms in the license agreement” then click the Next button. Select “Manually Set Port to Install”, then click the Next button. If you click the checkbox on for “After printer installation, install GARO Status Monitor”, the installation will continue with the installation of the GARO Status Monitor.
  • Page 86 Connect either “USB Port Connection” or “IEEE1394 Port Connection” then click the Next button. If a USB connection and IEEE1394 connection have already been installed, this screen is not displayed. The “Select Process” screen opens. (Æ P.3-19) 3-18 Installing the Software...
  • Page 87 Note z If you are using Windows Me or Windows 98, a message may instruct you to restart your computer. If this message is displayed, click the OK button, click the installer’s Finish button to finish the installation, then click the Finish button on the Setup Menu.
  • Page 88 When the next message asks you to confirm that you want to start the setup, click the Yes button. When the next screen opens, switch on the printer, then connect the cable to the printer and the computer. TUSB Connection Connect the USB cable B connector (square) to the USB port on the back of the printer, then connect the A connector (flat) to a USB port on the computer.
  • Page 89 Note z The printer is equipped with a floating internal structure, so when you connect the printer cable if the connector moves slightly this does not indicate anything abnormal. TIEEE1394 Connection Connect the IEEE1394 cable to the IEEE1394 port on the back of the printer then to the IEEE1394 port on the computer.
  • Page 90 At Step 5 if you clicked the “After printer installation, install GARO Status Monitor” checkbox on and then clicked the Exit button, the installation continues with the installation of the GARO Status Monitor. To continue, do the procedure from Step 3 for “Installing the GARO Status Monitor”.

  • Page 91: Installing A Windows Parallel Connection

    Installing a Windows Parallel Connection Describes the software and settings required on the computer for a parallel (Centronics) connection to a computer running Windows XP, Windows 2000, Windows NT 4.0, Windows Me, Windows 98, or Windows 95 (Service Pack 6 or later). Do this installation procedure on the Windows computer that will be connected to the printer.

  • Page 92: Connect The Printer Cable

    Connect the Printer Cable Important z If you intend to use a parallel port connection for a printer already set for a USB connection, use the printer operation panel to change the interface setting to Centronics. ( z The printer cannot be connected via the parallel port and USB port or IEEE1394 port at the same time.
  • Page 93 Connect the other end of the cable to the parallel printer port on the computer, then tighten the screws on both sides of the connector. On the printer operation panel, press the Power button. et Media Cancel Job/ Utility etup Reset/Enter Power Online...

  • Page 94: Installing The Printer Driver

    Installing the Printer Driver Important z If your are using Windows XP, Windows 2000, or Windows NT 4.0, you must log in as a member of the Administrators group. Mount the provided User Software CD-ROM in the CD-ROM drive. Note z If the AutoPlay function is switched off, double-click the My Computer icon on the desktop, click the CD-ROM drive icon, and then from the File menu select AutoPlay.
  • Page 95 Read the message on the “Welcome to the InstallShield Wizard for GARO Printer Driver” screen, then click the Next button. Note z If an older version of a USB or IEEE1394 driver is installed, a message will inform you that an older version of a USB or IEEE1394 driver is installed in your system. If you see this message, click the OK button to return to the Setup Menu, then select “Uninstall Old USB/IEEE 1394 Driver”...
  • Page 96 Select “Manually Set Port to Install”, then click the Next button. If you click the checkbox on for “After printer installation, install GARO Status Monitor.”, the installation will continue with the installation of the GARO Status Monitor. Clicking this checkbox on to install the GARO Status Monitor is recommended.
  • Page 97 Note z The following message is displayed if an older version of a printer driver for the W2200 is installed. • When installing a new printer driver on the same printer, select “Update Drivers”, click the Next button, then go to Step 14. ( •...
  • Page 98 From the Printer List, select the printer that you want to install, then click the Add to the Printer List for Driver Installation button. Confirm the name of the printer in the Printer List for Driver Installation, then click the OK button. 3-30 Installing the Software...
  • Page 99 Confirm the printer name in the list, then click the Next button. For Port Settings select “Standard Port”, then click the Settings button. From the Set the port on the network drop-down list, select the port where the printer is connected (LPT1:, LPT2:, etc.), then click the OK button.
  • Page 100 Confirm that the port name selected for “Port Set” is displayed, then click the Next button. Perform the printer name and printer sharing features as needed. Confirm the content of the Printer List for Driver Installation, then click the Start button. When the next message asks you to confirm that you want to start the setup, click the Yes button.
  • Page 101 When the next message asks you to confirm that you want to read the README file, click the Yes or No button. If you click the Yes button, the README file opens. At Step 5 if you clicked the “After Printer Installation, install GARO Status Monitor”...

  • Page 102: Installing A Macintosh Connection

    Installing a Macintosh Connection This chapter describes the computer software and settings required to use the printer with a Macintosh computer. Do these procedures on all the Macintosh computers. Macintosh Software The following software is provided for using the printer with a Macintosh computer.

  • Page 103: Connecting The Interface Cable

    Connecting the Interface Cable Before starting the printer driver installation, connect the Macintosh and the printer with the interface cable. Do the connection for a USB connection, IEEE1394 connection, or network connection, whichever is suited for your Macintosh. To set up an IEEE1394 port connection, you need a Macintosh equipped with an IEEE1394 (FireWire) port and running Mac OS 9.04 or later.
  • Page 104 Connect the USB cable B connector (square) to the USB port on the back of the printer, then connect the USB cable A connector (flat) to a USB port on the Macintosh. Ensure that the connector is inserted completely. TIEEE1394 Connection If the Macintosh is switched on, switch it off.
  • Page 105 Connect the IEEE1394 cable to the IEEE1394 port on the back of the printer then to the IEEE1394 port on the Macintosh. With a connector aligned correctly, push it all the way in to connect it securely. Printer back TNetwork Connection Use a LAN cable to connect the LAN port of the printer to the HUB port.

  • Page 106: Installing The Printer Driver For Mac Os 8.6/9.X

    Mount the provided User Software CD-ROM in the Macintosh CD- ROM drive. Double-click the software CD-ROM icon, open the OS89 folder, then double-click the GARO Installer for 8/9 icon. Read the “CANON SOFTWARE LICENCE AGREEMENT”, then click the Accept button. 3-38 Installing the Software...
  • Page 107 Click the Install button. When the message prompts you to confirm that all other software has been shut down, click the Continue button. The installation begins. When the installation is finished, click the Restart button. The Macintosh restarts. This completes the installation of the printer driver. 3-39 Installing a Macintosh Connection...
  • Page 108 TSelecting the Printer Important z If the computer is connected to a network, open Chooser and make sure that Apple Talk is enabled, then open AppleTalk on the Control Panel and make sure that the Connect via is set for Ethernet. (Æ Network Guide) Press the Power button to switch the printer on.
  • Page 109 Select the “GARO Printer Driver” icon in the list on the left, then in the right list under Destination select the name of the selected printer. If the printer is not displayed in the list, check the printer cable connection and make sure that it is secure.

  • Page 110: Installing The Mac Os X Printer Driver

    Installing the Mac OS X Printer Driver After installing the printer driver for Mac OS X, open the Print Center and add the printer. The procedure below describes the installation for OS X Ver. 10.2. In the installation procedure for Ver. 10.1, the names of the icons and appearance of the screens are slightly different.
  • Page 111 Read the “CANON SOFTWARE LICENCE AGREEMENT”, then click the Accept button. Click the Install button. When the message prompts you to confirm that all other software has been shut down, click the Continue button. The installation begins. 3-43 Installing a Macintosh Connection...
  • Page 112 When the installation is finished, click the Restart button. The Macintosh restarts. This completes the installation of the printer driver. TSelecting the Printer Important z If the computer is connected to a network, open System Preferences and at the Display setting under Network select Built-in Ethernet, then on the AppleTalk sheet make sure that the “Make AppleTalk Active ”checkbox is checked.
  • Page 113 Open the Utilities menu folder and open the Print Center. If the name of the printer is not displayed in the Printer List, click the Add icon. From the connection destination menu, select the printer connection destination, click the name of the printer in the displayed list, then click the Add button.
  • Page 114 If you want to set the printer as the default printer, select the name of the printer from the Printer List, then from the Printers menu select Make Default. This completes the printer selection. 3-46 Installing the Software...

  • Page 115: Installing Windows Utilities

    Installing Windows Utilities Installing the GARO Status Monitor The GARO Status Monitor is a software utility for Windows that allows you to view on the computer screen the details about printer errors. Perform the following procedure to install the GARO Status Monitor. Important z If you are using Windows XP, Windows 2000, or Windows NT 4.0, you must log in as a member of the Administrators group.
  • Page 116 Read the message on the “Welcome to the InstallShield Wizard for GARO Status Monitor” screen, then click the Next button. Read the end user license agreement and if you agree with the terms of the agreement, click the Yes button. 3-48 Installing the Software...
  • Page 117 On the “Choose Destination Location” screen, confirm the name of the folder for the installation destination, then click the Next button. On the “Confirm Installation” screen, check the settings and make sure that they are correct, then click the Next button. The installation begins.
  • Page 118 After the Complete Installation screen is displayed, make sure “Yes, I want to restart my computer now.” is selected, then press the Finish button. When the computer is restarted, installation is complete. If “Refer to Readme File Now” is displayed on the screen, press the Finish button to close the installer.

  • Page 119: Displaying Printer Information With The Garo Status Monitor

    Displaying Printer Information with the GARO Status Monitor The GARO Status Monitor opens automatically when a print job starts or when a printer error occurs. Perform the following procedure when you need to check the status of the printer immediately. On the desktop click the Start button, point to Programs, then select GARO Status Monitor Printer List.
  • Page 120 The status of the printer and status of print jobs in progress are displayed. Note z You can use the Option menu to set when the GARO Status Monitor is to be displayed. Select the items on the menu and click the desired checkboxes on. The default settings include “Only On Printing”...

  • Page 121: Other Important Information

    Other Important Information This chapter provides additional reference material and index for use of the printer.

  • Page 122: Installing Optional Paper Cassettes

    Installing Optional Paper Cassettes An additional paper cassette (designated Cassette 2) can be installed on W2200. Installation of optional cassettes allows automatic switching between these paper supply sources. Two types of cassette are available, a universal cassette that allows manual adjustment for a variety of media sizes and a cassette dedicated for 13x22 in.
  • Page 123 Press the Power button to switch the printer off. Disconnect the power cable and all interface cables. Move the printer from the setup site to another location. Remove all tapes and the stopper from the paper feed unit. et Media Cancel Job/ etup Utility...
  • Page 124 Position the paper feed unit where you want to set up the printer. Mount the printer on top of the paper feed unit. Other Important Information...
  • Page 125 Load paper in the paper cassettes and insert the cassettes in the printer. Note z For details about how to load see Chapter 1, “7 Load the Paper Cassette”. (Æ P.1-23) Re-connect the interface cables and power cord to the printer. Installing Optional Paper Cassettes...

  • Page 126: Other Software For The Printer

    Other Software for the Printer The following software can be used with the printer. This software is on the provided User Software CD-ROM or is available on the Canon Home Page. Software for Server Computer/Administorator TNetSpot Console Server software that allows you to use a Web browser to display the status of the printer from a network computer and perform the settings for the printer or the network interface board.

  • Page 127: Preparing The Printer For Transport

    Preparing the Printer for Transport Follow this procedure before moving the printer to protect its internal parts during moving or shipping. Press the Power button to switch the printer on. After a few seconds “Ready” is displayed in the operation panel and the Online lamp lights.
  • Page 128 Press U t i l i t y M e n u M o v e P r i n t e r The lock on the right cover is released and “Remove Ink Tank” is displayed. Open the right cover. Open the ink tank covers and remove all the ink tanks.
  • Page 129 Close and lock all the ink tank covers, then close the right cover. “Processing…” is displayed while ink is drawn into the ink tubes. When the ink fill processing is finished, switch the printer off. After the printer switches off, disconnect the power cord and the interface cables.
  • Page 130 Attach the paper roller stopper and fasten the tape. Attach the stopper to the carriage and fasten the tape. 4-10 Other Important Information...
  • Page 131 Re-attach the front upper cover and the rear upper cover. Tape the covers of the paper cassettes and the printer to hold them in place. Attach the shipping material to the paper cassettes and to the printer, then place them in the box. This completes preparing the printer for transport.

  • Page 132: Index

    Index Numerics 100 lamp ...1-10 Centronics ...3-23 Default G/W ...2-13 Device Status Extension ...4-6 Ext. I/F Print ...2-4 GARO Device Setup Utility ...2-2, 2-3, 2-5 GARO Printer Driver ...3-23 GARO Status Monitor ...3-47 IEEE1394 cable ...3-21 IEEE1394 port ... 3-21, 3-37 Installing the Printer Driver ...3-5 Windows Parallel connection ...3-26 interface, setting ...1-32...
  • Page 133 paper, loading ...1-23 Parallel ...3-23 Parallel port ...3-24 power connector ...1-10 power cord ...1-10 Print Center ...3-45 print side ...1-25 print status, confirming ...1-34 printer cable ...3-24 printhead ... 1-12, 1-14 printhead alignment pattern ... 1-36, 1-39 printhead position adjustment ...1-36 provided items ...1-3 Remote UI ...2-2 Selecting the Printer...

Table of Contents
