ECCELLENZA TOUCH
This procedure demonstrates how to properly clean
and sanitize the Eccellenza Touch
This procedure should take approximately 60 minutes
Tools Needed
®

Keurig
Bean to Cup Deep Cleaning kit (if available)

Large bucket or container

Available sink

Slotted screwdriver

Key to main door

Small paint brush
™
CLEANING & STARTUP PROCEDURE
1
™
brewer

Advertisement

Table of Contents
loading

Related Manuals for Keurig ECCELLENZA TOUCH

Summary of Contents for Keurig ECCELLENZA TOUCH

  • Page 1 ™ ECCELLENZA TOUCH CLEANING & STARTUP PROCEDURE This procedure demonstrates how to properly clean ™ and sanitize the Eccellenza Touch brewer This procedure should take approximately 60 minutes Tools Needed ®  Keurig Bean to Cup Deep Cleaning kit (if available) ...

  • Page 2: Table Of Contents

    Table of Contents   Disconnecting & Draining ………………………………………………. Pg. 3 Removing the Brewer Assembly ………………………………………. Pg. 4 Removing the Coffee Hopper ………………………………………….. Pg. 5 Removing the Powder System ………………………………………… Pg. 6 - 9 Cleaning & Sanitizing Procedure ……………………………………… Pg. 10 Cleaning Interior &...

  • Page 3: Disconnecting & Draining

    Disconnecting & Draining     Turn power switch to O position and unplug Turn machine around to access back cover and from grounded outlet. remove 4 screws and lift back cover up and away from machine. Note: Water supply may need to be disconnected to achieve above step.

  • Page 4: Removing The Brewer Assembly

    Removing the Brewer Assembly     Turn machine back around to front. Insert key and turn counterclockwise then open Remove waste container, empty & clean. main door.       Carefully remove wiper and Remove brewer assembly by Remove coffee spout from thoroughly clean exterior of pressing red button and turning front of brewer assembly.

  • Page 5: Removing The Coffee Hopper

    Removing the Coffee Hopper   LOOSEN ONLY the two screws beneath the coffee hopper.   Lift coffee hopper from unit and remove. If necessary, discard coffee beans and wipe down or thoroughly clean. NOTE: See cleaning instructions on page 11. 5 ...

  • Page 6: Removing The Powder System

    Removing the Powder System     Disconnect hoses to mixing chambers. Unlock and remove mixing chambers.     Remove mixing disks by sliding forward from Remove locking rings.   the whipper motor shaft. 6 ...
  • Page 7 Removing the Powder System cont.     Lift powder lid. Grab and pull towards you to remove powder drawer.     Remove powder hopper caps. Carefully remove powder hopper liner.   7 ...
  • Page 8 Cleaning & Sanitizing procedure on page 11. ® NOTE: We recommend cleaning and sanitizing all parts with Urnex products from ® the Keurig Bean to Cup Deep Cleaning Kit, but comparable agents may also be used 8 ...
  • Page 9 Removing the Powder System cont.   Remove and empty powder hoppers.   NOTE: If needed, hoppers can be disassembled (shown below) then cleaned and sanitized following instructions on page 11. Otherwise they can just be refilled following instructions on page 21. 9 ...
  • Page 10 Cleaning Interior & Exterior Components     Wipe interior area around the brewer motor Remove and wipe down or clean cup stand & and powder system with a clean cloth dipped grill using cleaning instructions on page 11. ® in Urnex Complete Café...

  • Page 11: Cleaning & Sanitizing Procedure

    Cleaning & Sanitizing Procedure Cleaning Solution ® 1. Prepare solution by adding 8 oz ( ) of Urnex Rinza concentrate to 1 gallon ( ) of warm tap water ( 240 ml 3.5 L or equiva- lent dilution 2. Mix well and use immediately. 3.

  • Page 12: Reinstalling The Powder System

    Reinstalling the Powder System NOTE: Prior to reinstalling powder components, please make sure all components are completely dry Reinstall powder hoppers. Carefully reinstall powder hopper Insert powder drawer.           liner and caps. NOTE: Start from one side and move across  ...

  • Page 13: Reinstalling The Brewer Assembly

    Reinstalling the Brewer Assembly     With wiper reinstalled, place brewer assembly Press red button and turn counterclockwise with red button slightly turned to 7:00 position. until a “click” sound is heard. Reattach spout. NOTE: Ensure that spout is inserted fully past both O-rings to prevent leakage and firmly against brewer assembly body.

  • Page 14: Reinstalling The Coffee Hopper

    Reinstalling the Coffee Hopper NOTE: ® If available, prior to reinstalling the coffee hopper, the grinder can be cleaned using Urnex SuperGrindz     ® If available, add 1 cap full ( ) of Urnex Carefully lower coffee hopper onto grinder. 26 grams SuperGrindz on top of grinder.

  • Page 15: Restarting & Refilling

    Restarting & Refilling     Close and lock main door. Reinsert waste container.     Carefully plug GFCI power cord into a If disconnected, re-connect water line to grounded outlet.   Machine and turn power switch to — position. NOTE: Allow for the machine fill & heat completely.

  • Page 16: How To Perform Both Cleanings & Rinses

    How to Perform Both Cleanings & Rinses     Press top left of screen, a faint square will light Enter code: 345678 up under your finger, hold for 3 sec.     Press 3 lines at top left of screen. Select Maintenance.
  • Page 17 Performing a Grinder Cleaning NOTE: Please reference page 14 prior to performing the following steps. Place a 16 cup on drip tray and press Grinder cleaning. Carefully follow the screen instructions. 17 ...
  • Page 18 Performing a Brewer Cleaning NOTE: If a "Brewer Assembly Cleaning Procedure" was done skip following step. 1. Remove waste container. 2. Unlock and open main door. ® 3. Add 1 Urnex Tabz Z61 cleaning tablet to the top of the brewer assembly. 4.
  • Page 19 Performing a Brewer Cleaning cont. Carefully follow the screen instructions. Carefully discard hot liquid. 19 ...
  • Page 20 Performing a Mixers Rinse Place a 16 cup on drip tray and press Mixers Rinse NOTE: Check powder components for any leaks This option runs a rinse cycle (to clean all three of the powder whipper systems) by sending hot water through each of the whipper units, while at the same time activating each of the whipper motors.

  • Page 21: Performing Test Brews

    NOTE: Do NOT overfill or pack powder hoppers. 3. Place a 16oz cup on cup stand and perform a test brew by brewing both a coffee and cappuccino. Procedure Complete! ® If you have any questions, please contact Keurig Commercial Technical Support: 888-287-2739 option 5 21 ...
