6. Attach the T-Handle (10) to the Upright (3) with two
M6 x 16mm Button Head Bolts (54) and two M6 Black
Nylon Locknuts (55).
7. The Console (6) requires two "AA" batteries (not
included). Alkaline batteries are recommended.
To install batteries, first locate the battery clip under
the Console (6). Insert two batteries into the battery
clip as shown. Make sure that the batteries are
turned so the negative ends of the batteries
(marked "–") are touching the springs in the
battery clip.
8. Make sure that all parts are properly tightened before you use the elliptical exerciser. Note: There may
be some hardware left over after assembly is complete. Place a mat under the elliptical exerciser to protect the
floor or carpet from damage.
All manuals and user guides at all-guides.com
8
6
3
7
Battery
Clip
54
10
55
6
Batteries
