Electrical Requirement
Impactor Travel
Overall Dimensions
Blows per minute
Retainer Style
Retainer Capacity
Bit hardness
Bit Dimensions:
Noise Level
Impact Energy
Tool Weight
NOTE: Plug this tool into a 20 Amp. dedicated circuit.
You will need this manual for the safety warnings and precautions,
assembly, operating, inspection, maintenance and cleaning procedures,
parts list and assembly diagram. Keep your invoice with this manual. Write
the invoice number on the inside of the front cover. Keep this manual and
invoice in a safe and dry place for future reference.
Failure to follow all instructions listed below may result in
Keep your work area clean and well lit. Cluttered benches and dark areas invite
1.
accidents.
SKU 94882
PRODUCT SPECIFICATIONS
120 Volt / 60 Hz / 16 Amps (running)
2-3/8"
25" L X 10-7/8" W X 9-3/8" H (hammer only)
1100 - 2100
Spring loaded rotational lock (2 positions only)
3/4" (19mm)
46-56 HRC
Chisel Bit: 3/4" Shank X 14-1/4" L
Bull Point Bit: 3/4" Shank X 1" W X 14-1/4" L
88 DBa @ 3 feet
3.7 to 18.4 Ft/Lbs.
33.75 Lbs.
SAVE THIS MANUAL
GENERAL SAFETY RULES
READ AND UNDERSTAND ALL INSTRUCTIONS
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
WARNING!
PAGE 2
REV 07e, 08b
