- Page 1 Synology DiskStation DS3617xs Hardware Installation Guide...
-
Page 2: Table Of Contents
Table of Contents Chapter 1: Before You Start Package Contents Synology DiskStation at a Glance Safety Instructions Chapter 2: Hardware Setup Tools and Parts for Drive Installation Install Drives Start Up Your DiskStation Add a RAM Module Add a Network Interface Card... -
Page 3: Package Contents
Chapter Before You Start Thank you for purchasing this Synology product! Before setting up your new DiskStation, please check the package contents to verify that you have received the items below. Also, make sure to read the safety instructions carefully to avoid harming yourself or damaging your DiskStation. -
Page 4: Synology Diskstation At A Glance
DiskStation to “Not installed” status so that DiskStation Manager (DSM) can be reinstalled. LAN Port Connect network cables here. For more information about Synology Expansion Unit supported by your DiskStation, please visit www.synology.com. 4 Chapter 1: Before You Start... -
Page 5: Safety Instructions
Safety Instructions Keep away from direct sunlight and away from chemicals. Make sure the environment does not experience abrupt changes in temperature or humidity. Place the product right side up at all times. Do not place near any liquids. Before cleaning, unplug the power cord. Wipe with damp paper towels. Do not use chemical or aerosol cleaners. -
Page 6: Chapter 2: Hardware Setup
Tools and Parts for Drive Installation • A screwdriver (only for 2.5” drives) • At least one 3.5” or 2.5” SATA drive (please visit www.synology.com for compatible drive models.) Warning: If you install a drive that contains data, the system will format the drive and erase all existing data. Please back up any important data before installation. - Page 7 3 Load drives into drive trays. • For 3.5” drives: Remove the fastening panels from the sides of the drive tray. Place the drive into the drive tray. Then insert the fastening panels to secure the drive in place. • For 2.5” drives: Remove the fastening panels from the sides of the drive tray and store them in a safe place.
- Page 8 6 Insert the drive tray key into the drive tray lock, turn the key clockwise (to the “-” position) to lock the handle of the drive tray, and then remove the key. 7 Repeat the steps above to assemble the other drives you have prepared. 8 Drives are numbered as shown below.
-
Page 9: Start Up Your Diskstation
Start Up Your DiskStation 1 Use the LAN cable to connect the DiskStation to your switch, router or hub. 2 Connect one end of the AC power cord to the power port of the DiskStation, and the other to the power outlet. 3 Press the power button. -
Page 10: Add A Ram Module
Add a RAM Module Follow the steps below to install, check, or remove a RAM module. To install a RAM module: 1 Shut down your DiskStation. Disconnect all cables from your DiskStation to prevent any possible damage. 2 Remove the 2 screws on the right side of the back panel, and then pull the side cover in the direction as illustrated below. - Page 11 4 Replace the side cover. Replace and tighten the 2 screws you removed in Step 2. 5 Reconnect the cables you removed in Step 1, and then press and hold the power button to turn on your DiskStation. To make sure that your DiskStation recognizes the new memory capacity: 1 Install DiskStation Manager (DSM).
-
Page 12: Add A Network Interface Card
2 Remove the 2 screws on the top of the back panel, and then pull the top cover in the direction as illustrated below. For more information about supported 10GbE or Gigabit network interface cards, please visit www.synology.com. 12 Chapter 2: Hardware Setup... - Page 13 3 Remove the expansion slot shield: a Reposition your DiskStation so that the top will be facing your body, with drive trays on the right side. b Pull the clip above the expansion slot shield in the direction as illustrated below. c Remove the shield.
- Page 14 b Use two fingers with firm, even pressure to push down on the card and the bracket. c Push back the clip to secure the newly inserted card. Note: Make sure the connectors are fully inserted. Otherwise, the network interface card might not be able to function properly.
-
Page 15: Replace System Fan
Replace System Fan Your DiskStation will emit beeping sounds if either of the system fans is not working. Follow the steps below to replace a malfunctioning fan module with a good one. To replace the system fan module: 1 Shut down your DiskStation. Disconnect all cables from your DiskStation to prevent any possible damage. 2 Pull out the 6 push pins that secure the fan module. -
Page 16: Chapter 3: Install Dsm On Diskstation
Chapter Install DSM on DiskStation After hardware setup is finished, please install DiskStation Manager (DSM) – Synology’s browser-based operating system – on your DiskStation. Install DSM with Web Assistant Your DiskStation comes with a built-in tool called Web Assistant that helps you download the latest version of DSM from the Internet and install it on your DiskStation. - Page 17 • Storage Temperature: -5 to 140˚F (-20 to 60˚C) • Relative Humidity: 5% to 95% RH Note: Model specifications are subject to change without notice. Please refer to www.synology.com for the latest information. Support for exFAT can be enabled by purchasing and downloading exFAT Access in Package Center.
-
Page 18: Appendix B: Led Indicator Table
No network Static Drive ready and idle Green Blinking Accessing drive Drive Status Indicator (on tray) Orange Static Drive error No internal drive Note: Model specifications are subject to change without notice. Please refer to www.synology.com for the latest information. - Page 19 IMPORTANT–READ CAREFULLY: THIS END USER LICENSE AGREEMENT ("EULA") IS A LEGAL AGREEMENT BETWEEN YOU (EITHER AN INDIVIDUAL OR A LEGAL ENTITY) AND SYNOLOGY, INC. ("SYNOLOGY") FOR THE SYNOLOGY SOFTWARE INSTALLED ONTO THE SYNOLOGY PRODUCT PUCHASED BY YOU (THE “PRODUCT”), OR LEGALLY DOWNLOADED FROM WWW.SYNOLOGY.COM, OR ANY OTHER CHANNEL PROVIDED BY SYNOLOGY...
- Page 20 Section 15. Termination. Without prejudice to any other or other legal action or proceeding to enforce rights or rights, Synology may terminate this EULA if you do not abide remedies under this EULA, the prevailing party will be by the terms and conditions contained herein. In such event,...
- Page 21 SYNOLOGY, INC. LIMITED PRODUCT WARRANTY THIS LIMITED WARRANTY ("WARRANTY") APPLIES TO THE PRODUCTS (AS DEFINED BELOW) OF SYNOLOGY, INC. AND ITS AFFILIATES, INCLUDING SYNOLOGY AMERICA CORP, (COLLECTIVELY, "SYNOLOGY"). YOU ACCEPT AND AGREE TO BE BOUND BY THE TERMS OF THIS WARRANTY BY OPENING THE PACKAGE CONTAINING AND/OR USING THE PRODUCT.
- Page 22 DAMAGES. the Product specifications; (b) has been repaired, modified or altered by anyone other than Synology or its agent or Limitation of Liability. SYNOLOGY'S AND ITS designee; (c) has been in any way misused, abused, or SUPPLIERS' LIABILITY ARISING OUT OF OR RELATING damaged;...
- Page 23 Nothing in this Section shall be deemed to prohibit or restrict arbitration and will not be conducted on a class-wide or class Synology from seeking injunctive relief or seeking such other action basis. The arbitration shall be held in King County, rights and remedies as it may have at law or equity for any Washington, U.S.A.
