- Page 1 PROPANE CONSTRUCTION HEATER OWNER’S MANUAL Model: BLP35E IMPORTANT Read and understand this manual before assembling, starting, or servicing heater. Improper use of heater can cause serious injury. Keep this manual for future reference.
-
Page 2: Table Of Contents
CONTENTS SECTION PAGE Safety Information ................. 2 Unpacking ..................3 Product Identification ..............4 Theory of Operation ..............4 Propane Supply ................5 Installation ..................5 If Gas Leak Occurs ................ 6 Ventilation ..................6 Operation ..................7 Storage ................... 8 Maintenance .................. -
Page 3: Unpacking
SAFETY WARNINGS Continued INFORMATION • Not for domestic use (inside living areas). Use heater for space heating only. • Intended for temporary heating of buildings under construction, alteration, or repair. Continued • Install and use heater with care. Follow all local ordinances and codes. •... -
Page 4: Product Identification
Hot Air Outlet PRODUCT Shell (Front) IDENTIFICATION Motor Handle Fan Guard Heater Base Piezo Ignitor Button Power Automatic Cord Control Valve Button Inlet Connector Hose /Regulator Assembly Figure 1 - Model BLP35E THEORY OF The Fuel System: The hose/regulator assembly attaches to the propane gas supply. -
Page 5: Propane Supply
User must provide propane gas and propane tank(s). PROPANE Use this heater only with a propane vapor withdrawal supply system. The amount SUPPLY of propane gas ready for use from propane tanks varies. Two factors decide this amount: 1. The amount of propane gas in tank(s) 2. -
Page 6: If Gas Leak Occurs
3. Connect hose to inlet connector. Tighten firmly using a wrench. INSTALLATION IMPORTANT: Use extra hose or piping if needed. Install extra hose or piping Continued between hose/regulator assembly and propane tank. You must use the regula- tor supplied with heater. Inlet Connector Hose Figure 4 - Hose and Inlet Connector... -
Page 7: Operation
OPERATION WARNING Review and understand the warnings in the Safety Informa- tion section, pages 2 and 3. They are needed to safely oper- ate this heater. Follow all local codes when using this heater. To Start Heater 1. Follow all installation, ventilation, and safety information. 2. -
Page 8: Storage
STORAGE CAUTION Disconnect heater from propane supply tank(s). 1. Store propane tank(s) in safe manner. Follow all local codes. Always store propane tanks outdoors. 2. Store in dry, clean, and safe place. Do not store hose/regulator assembly inside heater combustion chamber. 3. -
Page 9: Troubleshooting
TROUBLE- WARNING SHOOTING Never service heater while it is plugged in, connected to propane supply, operating, or hot. Severe burns and electrical shock can occur. OBSERVED FAULT POSSIBLE CAUSE REMEDY Fan does not turn No electrical power to Check current to electrical out- when heater is heater let. -
Page 10: Service Procedures
SERVICE WARNING PROCEDURES Never service heater while it is plugged in, connected to propane supply, operating, or hot. Severe burns and Motor and Fan electrical shock can occur. 1. Remove three screws that attach fan guard to heater shell. 2. Remove motor and fan guard from heater shell (see Figure 7). -
Page 11: Ignitor
Ignitor 1. Remove motor and fan guard from heater (see Motor and Fan, page 10, steps 1 and 2). Piezo Ignitor 2. Remove black ignitor wire Bushing from piezo ignitor. Access Ignitor Wire ignitor wire through underside of heater base (see Figure 11). - Page 12 Thermocouple Thermocouple Nut 1. Make sure unit is unplugged. 2. Remove three screws that attach fan guard to heater shell. 3. Remove motor and fan guard from heater shell (see Figure 14). Be careful Thermocouple not to damage fan. 4. Remove thermocouple nut located inside the combus- Figure 14 - Removing Motor and Figure 15 - Thermocouple Nut Location...
-
Page 13: If Gas Leak Occurs
Thermoswitch 1. Make sure unit is un- plugged. 2. Remove three screws that attach fan guard to heater shell. 3. Remove motor and fan guard from heater shell (see Figure 20). Be careful not to damage fan. 4. Remove two nuts and Figure 20 - Removing Motor and Fan Guard from Heater star washers from thermoswitch (see Figure... -
Page 14: Illustrated Parts Breakdown And Parts List
ILLUSTRATED PARTS BREAKDOWN Rubber Washer Motor Motor Assembly 30 18 102588... -
Page 15: Specifications
PARTS LIST This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the correct model and serial numbers (from the model plate), then the part number and description of the desired part. PART PART NUMBER DESCRIPTION QTY. -
Page 16: Warranty And Repair Service
Date of Purchase 2701 Industrial Drive P.O. Box 90004 Bowling Green, KY 42102-9004 U.S.A. For information, write: DESA International, P.O. Box 90004 Bowling Green, Kentucky 42102-9004 U.S.A. ATTN: Customer Service Department When writing, always include model number and serial number.
