BASIC OPERATION
Power On/Off
Press any button on the front panel to turn the unit on. Press the power button (1)
to turn the unit on/off.
Volume Control
To increase the volume, press the VOL+ UP button (2a). To decrease the volume,
press the DOWN VOL- button (2b).
Mute
Press the MUTE button (17) on the control panel to mute the audio output. Press
MUTE again to restore the audio output to the previous level.
Mode
Press the MODE button (4) on the control panel to select a different mode of
operation, as indicated on the display panel. Available modes include Tuner, iPod,
USB, AUX In (optional Auxiliary Input) and BT Audio.
Reset
The reset button should be activated for the following reasons:
•
initial installation of the unit when all wiring is completed
•
function buttons do not operate
•
error symbol on the display
Use a ball point pen or similar object to press the RESET button (19). This may be
necessary should the unit display an error code.
You can recover factory default settings using the RESET function located on the
system menu. With "RESET" flashing, press the ENTER button (18) to activate.
Audio Menu
Press the AUDIO/MENU button (3) on the control panel to access the audio menu.
You can navigate through the audio menu items by pressing the AUDIO/MENU
button repeatedly. Once the desired menu item appears on the display, adjust that
option by pressing the VOL+ UP or DOWN VOL- buttons (2) within 5 seconds.
The unit will automatically exit the audio menu after five seconds of inactivity. The
following menu items can be adjusted.
Bass Level
Use the VOL buttons to adjust the Bass level range from "-6" to "+6".
Treble Level
Use the VOL buttons to adjust the Treble level range from "-6" to "+6".
Balance
Use the VOL buttons to adjust the Balance between the left and right speakers
from "L12" (full left) to "R12" (full right).
Fader
Use the VOL buttons to adjust the Fader between the rear and front speakers
from "R12" (full rear) to "F12" (full front).
System Menu
1.
Press and hold the AUDIO/MENU button (3) for more than 3 seconds to
enter the system menu. "MENU" will appear on the display, followed by the
first menu item, "CONTRAST."
Press the ►►| SEEK/TUNE/TRK or |◄◄ SEEK/TUNE/TRK button (14, 13)
2.
or press the AUDIO/MENU button repeatedly to navigate the system menu
and select the desired item.
3.
Press the VOL+ UP or DOWN VOL- buttons (2) to adjust the selected menu
item.
4.
Press the AS/PS
button (15) to return to the previous operation.
The following items can be adjusted:
•
CONTRAST (00 – 10): Set LCD contrast.
•
LOW BATT (ON/OFF): Monitor voltage on ACC line.
•
DISTANT/LOC: "Local" mode favors access to local stations whose signals
are much stronger, thereby improving reception. Select "Distant" to terminate
local receive mode and resume normal mode.
•
AREA (USA/Latin/Europe): Set frequency spacing for various regions.
•
VOL PGM (00 – 46): Select an automatic turn-on volume.
•
BEEP TONE (ON/OFF): Turn the audible beep ON/OFF (heard when
functions/buttons are selected). NOTE: Beep tone off will not affect LOW
6
MS2A
