BIPV8M-IAE Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading

Related Manuals for Biostar BIPV8M-IAE

Summary of Contents for Biostar BIPV8M-IAE

  • Page 1 BIPV8M-IAE Setup Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ........3 Before You Start ................3 Package Checklist ................3 Mainboard Specification..............4 Rear Panel..................5 Mainboard Layout ................6 Chapter 2: Installation .......... 7 CPU...................... 7 Fan Header..................7 System Memory.................. 8 Power Supply ..................

  • Page 3: Chapter 1: Introduction

    BIPV8M-IAE CHAPTER 1: INTRODUCTION EFORE TART Thank you for choosing our product. Before you start installing the mainboard, please make sure you follow the instructions below: Prepare a dry and stable working environment with sufficient lighting. Always disconnect the system from power outlet before operation.

  • Page 4: Mainboard Specification

    Mini-ITX Mainboard Manual AINBOARD PECIFICATION Specification Intel CPU On-board Intel Atom D510 @1.67GHz dual core Pineview-D Processor Supports up 667 MHz Chipset Southbridge: ICH8M Max Shared Video Memory is 384 MB Supports dual displays (Extended mode) as below: Graphic Intel Pineview-D integrated graphics engine —LVDS (Single channel, support up to WXGA) —RGB (Support up to SXGA+...

  • Page 5: Rear Panel

    LAN port USB Port Audio Jack Board Size 170 mm (W) x 170 mm (L) Mini-ITX Biostar reserves the right to add or remove Windows XP/XPE, Linux Support support for any OS with or without notice. ANEL P S / 2...

  • Page 6: Mainboard Layout

    Mini-ITX Mainboard Manual AINBOARD AYOUT JK B MS 1 JATXPWR1 DIMMA 1 JS FA N1 JHDD1 JCOM6 Intel JP 3 LV DS -CONN1 Atom JCOM5 D510 SATA1SATA2 JLV 2 CPU1 JS EL1 JS E L2 JCOM4 JLV 1 JB L2 JB L1 ICH8M JP 2...

  • Page 7: Chapter 2: Installation

    BIPV8M-IAE CHAPTER 2: INSTALLATION The mainboard includes an embedded Intel Atom D510 processor, and a heatsink has been installed to provide sufficient cooling. EADER The fan header supports cooling-fans built in the system. The fan cable and connector may be different due to the fan manufacturer.

  • Page 8: System Memory

    Mini-ITX Mainboard Manual YSTEM EMORY DIMMA1: Memory Module (200pin SO-DIMM) Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. Insert the DIMM firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.

  • Page 9: Power Supply

    BIPV8M-IAE OWER UPPLY JATXPWR1: ATX Power Source Connector This connector provides +12V to system power circuit. Assignment +12V +12V Ground Ground JHDD1: SATA Power Connector This connector provides power connection of SATA devices. Assignment +12V +3.3V...

  • Page 10: Onboard Slot/Connector/Header/Jumper

    Mini-ITX Mainboard Manual NBOARD ONNECTOR EADER UMPER PCI1: Peripheral Component Interconnect Slot This mainboard is equipped with 1 standard PCI slot. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards. This PCI slot is designated as 32 bits. PCI1 PE1: Mini PCI-E Slot This mainboard is equipped with 1 Mini PCI-E Slot.
  • Page 11 BIPV8M-IAE IDE1: ATA Device Connector The mainboard has an integrated IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/66/100 functionality. It has one IDE connector which can connect a master and a slave drive, so you can connect up to two ATA devices.
  • Page 12 Mini-ITX Mainboard Manual JPANEL1: Front Panel Header This 10-pin header includes Power-on, Reset, HDD LED, and Power LED connection. It allows user to connect the system case’s front panel switch functions. Assignment Function Assignment Function Power LED+ Power LED HD LED+ Power LED+ HDD LED HD LED-...
  • Page 13 BIPV8M-IAE JCOM1 / JCOM2 / JCOM3: Serial port Connectors The motherboard has Serial Port Connectors for connecting RS-232 Port. JCOM1 supports RS-232/422/485 (Optional); JCOM2 and JCOM3 only supports RS-232. RS-232 J C O M 3 Assignment Carrier detect (DCD) Received data (RXD)
  • Page 14 Mini-ITX Mainboard Manual JP2: Voltage Switch Header for JCOM2 This header is for controlling the Pin9 of JCOM2 to switch Ring or 5V. Pin 1-2 Close: Pin9=5V Pin 2-3 Close: Pin9=Ring (Default) JP3: Voltage Switch Header for JCOM3 This header is for controlling the Pin9 of JCOM3 to switch Ring or 5V. Pin 1-2 Close: Pin9=5V Pin 2-3 Close:...
  • Page 15 BIPV8M-IAE JCOM4 ~ JCOM6: Serial Port Connectors The motherboard has 3 Serial Port Connectors for connecting RS-232 Port. J CO M 6 J CO M 5 Assignment J CO M 4 -PDCD PSIN PSOUT data -PDTR -PDSR -PRTS -PCTS -PRI...
  • Page 16 Mini-ITX Mainboard Manual JCMOS1: Clear CMOS Header * Placing the jumper on pin2-3 allows user to restore the BIOS safe setting and the CMOS data. Please carefully follow the procedures to avoid damaging the mainboard. Pin 1-2 Close: (Default) Normal Operation. Pin 2-3 Close: Clear CMOS data.
  • Page 17 BIPV8M-IAE JPRNT1: Printer Port Connector This header allows you to connect printer port on the PC. Assignment Assignment -Strobe Ground -ALF Data 6 Data 0 Ground -Error Data 7 Data 1 Ground -Init -ACK Data 2 Ground -Scltin Busy Data 3...
  • Page 18 Mini-ITX Mainboard Manual LVDS-CONN1: LVDS Connector This connector is for devices requiring display interface such as LVDS. This connector supports only 18-bit single-channel panels up to WXGA (1366 x 768) It is strongly recommended to use the matching JOY DAY INDUSTRIAL - A1252WV-SF-2X20PD01 connector.
  • Page 19 BIPV8M-IAE JLV2: LCD Power Select Header * This header allows you to select LCD Power. Pin 1-2 Close: PVDD=3.3V (Default) Pin 2-3 Close: PVDD=5V JLV1: LCD Backlight Inverter Power Select Header * This header is for selecting LCD Backlight Inverter Power.
  • Page 20 Mini-ITX Mainboard Manual JBL2: LCD Backlight Brightness Adjust Header * This header is for adjusting LCD backlight brightness. Short Pin 1-2: Increase Brightness Short Pin 3-4: Decrease Brightness JC1: LCD Backlight Inverter Connector This connector is for connecting to LCD for providing backlight control function. It is strongly recommended to use the matching JOY DAY INDUSTRIAL －...

  • Page 21: Chapter 3: Bios Setup

    BIPV8M-IAE CHAPTER 3: BIOS SETUP Introduction The purpose of this chapter is to describe the settings in the AMI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM. The power of CMOS RAM is supplied by a battery so that it retains the Setup information when the power is turned off.
  • Page 22 Mini-ITX Mainboard Manual PCI Bus Support This AMI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component Interconnect) local bus specification. DRAM Support DDR2 SDRAM (Double Data Rate II Synchronous DRAM) is supported. Supported CPUs This AMI BIOS supports the Intel CPU. Using Setup When starting up the computer, press <Del>...

  • Page 23: Main Menu

    BIPV8M-IAE Once you enter AMI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system information. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Chipset Exit System Overview Use [ENTER], [TAB] or [SHIFT-TAB] to AMI BIOS select a field.
  • Page 24 Mini-ITX Mainboard Manual IDE Configuration The BIOS will automatically detect the presence of IDE/SATA devices. There is a sub-menu for each IDE/SATA device. Select a device and press <Enter> to enter the sub-menu of detailed options. BIOS SETUP UTILITY Main IDE Confuguration Options Disabled...
  • Page 25 BIPV8M-IAE AHCI Configuration BIOS SETUP UTILITY Main AHCI Settings Enables for supporting AHCI BIOS Support [Enabled] > AHCI Port0 > AHCI Port1 Select Screen Select Item Change Option General Help Save and Exit Exit vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
  • Page 26 Mini-ITX Mainboard Manual SATA 1/2 & IDE Master/Slave Devices BIOS SETUP UTILITY Main SATA 1 Device Select the type of device connected Device to the system. Type [Auto] LBA/Large Mode [Auto] Block (Multi-Sector Transfer)[Auto] PIO Mode [Auto] DMA Mode [Auto] S.M.A.R.T [Auto] 32Bit Data Transfer...
  • Page 27 BIPV8M-IAE S.M.A.R.T Set the Smart Monitoring, Analysis, and Reporting Technology. Options: Auto (Default) / Disabled / Enabled 32Bit Data Transfer Enable or disable 32-bit data transfer. Options: Enabled (Default) / Disabled Hard Disk Write Protect Disable or enable device write protection. This will be effective only if the device is accessed through BIOS.

  • Page 28: Advanced Menu

    Mini-ITX Mainboard Manual DVANCED The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power Management, and other system devices. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. BIOS SETUP UTILITY Main Advanced...
  • Page 29 BIPV8M-IAE Max CPUID Value Limit When the computer is booted up, the operating system executes the CPUID instruction to identify the processor and its capabilities. Before it can do so, it must first query the processor to find out the highest input value CPUID recognizes. This determines the kind of basic information CPUID can provide the operating system.
  • Page 30 Mini-ITX Mainboard Manual Serial Port2 Address Select an address and corresponding interrupt for Serial Port 2. Options: 2F8/IRQ3 (Default) / 3E8/IRQ4 / 2E8/IRQ3 / Disabled Parallel Port Address This item allows you to determine access onboard parallel port controller with which I/O Address.
  • Page 31 BIPV8M-IAE Serial Port3 Address This item allows you to select the address of Serial Port3. Options: 3E8 (Default) / 2E8 / 2F0 / 2E0 Serial Port3 IRQ This item allows you to select IRQ of Serial Port3. Options: IRQ5 (Default) / IRQ3 / IRQ4 / IRQ7 / IRQ9 / IRQ10 / IRQ11 / IRQ12 Serial Port4 Address This item allows you to select the address of Serial Port4.
  • Page 32 Mini-ITX Mainboard Manual Watch Dog Degree This item allows you to determine the functional degree of Watch Dog. Options: Second (Default) / Minute Watch Dog Timer Options: 0 for disabled (Default) / Min=1, Max=65536 Hardware Health Configuration This item shows the system temperature, fan speed, and voltage information. BIOS SETUP UTILITY Advanced Hardware Health Configuration...
  • Page 33 BIPV8M-IAE ACPI Configuration BIOS SETUP UTILITY Advanced ACPI Settings Advanced ACPI Configuration settings Power Supply Emulate Mode: > Advanced ACPI Configuration Use this section to > Chipset ACPI Configuration configure additional Resume On RTC Alarm [Disabled] ACPI options. Resume On PME#...
  • Page 34 Mini-ITX Mainboard Manual AMI OEMB table Set this value to allow the ACPI BIOS to add a pointer to an OEMB table in the Root System Description Table (RSDT) table. Options: Enabled (Default) / Disabled Headless mode This is a server-specific feature. A headless server is one that operates without a keyboard, monitor or mouse.
  • Page 35 BIPV8M-IAE Resume On RTC Alarm When “Enabled”, you can set the date and time at which the RTC (real-time clock) alarm awakens the system from Suspend mode. Options: Disabled (Default) / Enabled RTC Alarm Date (Days) You can choose which date the system will boot up.
  • Page 36 Mini-ITX Mainboard Manual USB Configuration This item shows the USB controller and using USB device information. BIOS SETUP UTILITY Advanced USB Configuration Enables support for legacy USB. AUTO Module Version - 2.24.5-13.4 option disables legacy support if USB Devices Enabled: no USB devices are connected.
  • Page 37 BIPV8M-IAE USB Mass Storage Device Configuration BIOS SETUP UTILITY Advanced USB Mass Storage Device Configuration Number of seconds POST waits for the USB Mass Storage Reset Delay [20 Sec] USB mass storage device after start Device # unit command. Emulation Type...

  • Page 38: Pci/Pnp Menu

    Mini-ITX Mainboard Manual PCI/P This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction.
  • Page 39 BIPV8M-IAE Allocate IRQ to PCI VGA This item allows BIOS to choose a IRQ to assign for the PCI VGA card. Options: Yes (Default) / No Palette Snooping Some old graphic controllers need to “snoop” on the VGA palette and then map it to their display as a way to provide boot information and VGA compatibility.
  • Page 40 Mini-ITX Mainboard Manual DMA Channel 0/1/3/5/6/7 These items will allow you to assign each DMA channel a type, depending on the type of device using the channel. The option “Available” means the channel is going to assign automatically. Options: Available (Default) / Reserved Reserved Memory Size This item allows BIOS to reserve certain memory size for specific PCI device.

  • Page 41: Boot Menu

    BIPV8M-IAE This menu allows you to setup the system boot options. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Chipset Exit Boot Settings Configuration Specifies the Boot Device Priority sequence. > Boot Device Priority > Hard Disk Drives > Removable Drives >...
  • Page 42 Mini-ITX Mainboard Manual Quick Boot Enabling this option will cause an abridged version of the Power On Self-Test (POST) to execute after you power up the computer. Options: Enabled (Default) / Disabled Full Screen LOGO Disaply This item allows you to enable/disable Full Screen LOGO Show function. Options: Disabled (Default) / Enabled AddOn ROM Display Mode This item sets the display mode for option ROM.

  • Page 43: Chipset Menu

    BIPV8M-IAE HIPSET This submenu allows you to configure the specific features of the chipset installed on your system. This chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus.
  • Page 44 Mini-ITX Mainboard Manual DRAM Frequency This item allows you to set the frequency of DRAM.. Options: Auto (Default) / 667MHz Configure DRAM timing by SPD This item allows you .to determine DRAM timing by SPD Options: Enabled (Default) / Disabled DRAM CAS# Latency Options: 5 (Default) / 3 / 4 / 6 DRAM RAS# to CAS# Delay...
  • Page 45 BIPV8M-IAE Video Function Configuration BIOS SETUP UTILITY Chipset Video Function Configuration Options DVMT Mode Select [DVMT Mode] Fixed Mode DVMT/FIXED Memory [256MB] DVMT Mode Boot Display Device [D-SUB] Flat Panel Type [Type 3] Select Screen Select Item Change Option General Help...
  • Page 46 Mini-ITX Mainboard Manual South Bridge Configuration BIOS SETUP UTILITY Chipset South Bridge Chipset Configuration Options USB Functions [10 USB Ports] Disabled USB 2.0 Controller [Enabled] 2 USB Ports HDA Controller [Enabled] 4 USB Ports SMBUS Controller [Enabled] 6 USB Ports 8 USB Ports SLP_S4# Min.
  • Page 47 BIPV8M-IAE Onboard LAN 1/2 This item allows you to enable or disable the Onboard LAN. Options: Enabled (Default) / Disabled Onboard LAN ROM 1/2 This item allows you to select the Onboard LAN Boot ROM. Options: Disabled (Default) / Enabled...

  • Page 48: Exit Menu

    Mini-ITX Mainboard Manual This menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Chipset Exit Exit Options Exit system setup after saving the Save Changes and Exit changes.
  • Page 49 BIPV8M-IAE Security This sub-menu allows you to provide/revise supervisor and user password. BIOS SETUP UTILITY Exit Security Settings Install or Change the password. Supervisor Password :Not Installed User Password :Not Installed Change Supervisor Password User Access Level [Full Access] Change User Password...
  • Page 50 Mini-ITX Mainboard Manual Password Check This item is for setting the timing that checking password. Options: Setup (Default) / Always Boot Sector Virus Protection This option allows you to choose the VIRUS Warning feature that is used to protect the IDE Hard Disk boot sector. If this function is enabled and an attempt is made to write to the boot sector, BIOS will display a warning message on the screen and sound an alarm beep.

  • Page 51: Chapter 4: Useful Help

    BIPV8M-IAE CHAPTER 4: USEFUL HELP RIVER NSTALLATION After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance. You will see the following window after you insert the CD The setup guide will auto detect your mainboard and operating system.

  • Page 52: Ami Bios Beep Code

    Mini-ITX Mainboard Manual AMI BIOS B Boot Block Beep Codes Number of Beeps Description No media present. (Insert diskette in floppy drive A:) “AMIBOOT.ROM” file not found in root directory of diskette in Insert next diskette if multiple diskettes are used for recovery Flash Programming successful File read error No Flash EPROM detected...

  • Page 53: Troubleshooting

    BIPV8M-IAE ROUBLESHOOTING Probable Solution There is no power in the system. Make sure power cable is Power LED does not shine; the securely plugged in. fan of the power supply does not Replace cable. work Contact technical support. Indicator light on keyboard does not shine.
