This equipment has been tested and found to comply with the limits of a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. There is no guarantee that interference
will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents here and
specially disclaims any implied warranties of merchantability or fitness for any purpose. Further
the vendor reserves the right to revise this publication and to make changes to the contents here
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first obtaining the
vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and we will not be
responsible for any mistakes found in this user's manual. All the brand and product names are
trademarks of their respective companies.
FCC Information and Copyright
Dichiarazione di conformità sintetica
Ai sensi dell'art. 2 comma 3 del D.M. 275 del
30/10/2002
Si dichiara che questo prodotto è conforme
alle normative vigenti e soddisfa i requisiti
essenziali richiesti dalle direttive
2004/108/CE, 2006/95/CE e 1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying with the
laws in force and meeting all the essential
requirements as specified by the directives
2004/108/CE, 2006/95/CE and 1999/05/CE
whenever these laws may be applied
Advertisement
Table of Contents
Related Manuals for Biostar BIH11-IHP
Summary of Contents for Biostar BIH11-IHP
-
Page 1: Fcc Information And Copyright
FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 2: Table Of Contents
BIH11-IHP User’s Manual Table Of Contents FCC Information and Copyright ������������������������������������������������������������������������������� 1 Chapter 1: Introduction ������������������������������������������������������������������������������������������� 3 1.1 Before You Start ........................3 1.2 Specifications ........................4 1.3 Rear Panel Connectors ......................6 1.4 Motherboard Layout ......................7 Chapter 2: Hardware installation ����������������������������������������������������������������������������� 8 2.1 Central Processing Unit (CPU) ..................... -
Page 3: Chapter 1: Introduction
BIH11-IHP User’s Manual Chapter 1: Introduction 1�1 Before You Start Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: • Prepare a dry and stable working environment with sufficient lighting. -
Page 4: Specifications
BIH11-IHP User’s Manual 1.2 Specifications Specifications Socket 1151 for 6th & 7th Gen Intel® Core™ i7/i5/i3 / Pentium / Celeron processor Maximum CPU TDP (Thermal Design Power): 65Watt Chipset Intel® H110 LAN Controller: 2x RTL8111H Audio Codec: ALC662 Audio Amplifier: ALC105... - Page 5 BIH11-IHP User’s Manual Specifications Fan: 2x 1* 4pins(2.54) header for CPU/System fan (Smart Fan) Others: On Board Connectors 1x 2* 7pins header for TPM module & Headers 1x 2* 5pins (2.0) DIO header (by BIOS setting) 1x 1* 3pins(2.0) header clear CMOS...
-
Page 6: Rear Panel Connectors
BIH11-IHP User’s Manual 1�3 Rear Panel Connectors COM1: Serial port Connectors (RS-232/RS422/RS485) RS-232 (Default) RS-422* RS-485* Pin Assignment Carrier detect (DCD) 422 TXD- 485 DATA- Received data (RXD) 422 TXD+ 485 DATA+ Transmitted data (TXD) 422 RXD+ Data terminal ready (DTR) 422 RXD-... -
Page 7: Motherboard Layout
BIH11-IHP User’s Manual 1.4 Motherboard Layout Note » » represents the 1st pin. Chapter 1: Introduction | 7... -
Page 8: Chapter 2: Hardware Installation
BIH11-IHP User’s Manual Chapter 2: Hardware installation 2.1 Central Processing Unit (CPU) Step 1: Locate the CPU socket on the motherboard Note » » Remove Pin Cap before installation, and make good preservation for future use. When the CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged. » » The motherboard might equip with two different types of pin cap. Please refer below instruction to remove the pin cap. Step 2: Pull the socket locking lever out from the socket and then raise the lever up. - Page 9 BIH11-IHP User’s Manual Step 4: Hold processor with your thumb and index fingers, oriented as shown. Align the notches with the socket. Lower the processor straight down without tilting or sliding the processor in the socket. Note » » Ensure that you install the correct CPU designed for LGA1151 socket.
-
Page 10: Install A Heatsink
BIH11-IHP User’s Manual 2.2 Install a Heatsink Step 1: Place the CPU fan assembly on top of the installed CPU and make sure that the four fasteners match the motherboard holes. Orient the assembly and make the fan cable is closest to the CPU fan connector. -
Page 11: Connect Cooling Fans
BIH11-IHP User’s Manual 2.3 Connect Cooling Fans These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1. - Page 12 BIH11-IHP User’s Manual Step 1: Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. Step 2: Insert the DIMM vertically and firmly into the slot until the retaining clips snap back in place and the DIMM is properly seated.
-
Page 13: Expansion Slots
BIH11-IHP User’s Manual 2.5 Expansion Slots PEX16_1: PCI-Express x16 Slot (x16 speed) • PCI-Express 3.0 compliant. • Theoretical maximum bandwidth using two slots simultaneously is 16GB/s for each slot, a total of 32GB/s. 2.6 Jumper & Switch Setting Jumper Setting The illustration shows how to set up jumpers. -
Page 14: Headers & Connectors
BIH11-IHP User’s Manual 2.7 Headers & Connectors JATXPWR1: ATX Power Source Connector For better compatibility, we recommend to use a standard ATX 20-pin power supply for this connector. Make sure to find the correct orientation before plugging the connector. Assignment Assignment 3.3V... - Page 15 BIH11-IHP User’s Manual JPANEL1: Front Panel Header This connector includes Power-on, Reset, HDD LED and Power LED connections. It allows user to connect the PC case’s front panel switch functions. Pin Assignment Function Pin Assignment Function Power LED (+) Power...
- Page 16 BIH11-IHP User’s Manual TPM1: Trusted Platform Module Header (SLB9665) This header allows you to store cryptographic keys that protect information. Assignment Pin Assignment LAD0 VCC3_3 LAD1 VCC3_3 LAD2 PCLK_TPM LAD3 Ground L_FRAME_N 10 NA SER_IRQ 12 TPM_RST CLK_RUN# 14 +3V3_DUAL SATA1/2/3: Serial ATA 3.0 Gb/s Connectors (1*7 Pin)
- Page 17 BIH11-IHP User’s Manual F_USB1: Header for USB 2.0 Header The mainboard provides USB 2.0 pin header. Each header allows you to connect 2 additional USB 2.0 ports. Pin Assignment Pin Assignment Power Power USB1 - USB2 - USB1 + USB2 +...
- Page 18 BIH11-IHP User’s Manual JSEL1/JSEL2: RS-232/422/485 Switch Headers for COM1 The headers determine that COM1 belongs to RS-232 (Default), 422, or 485. JSEL1(JCOM1) 1-2 (Default) RS-232 RS-422 RS-485 JSEL2(JCOM1) RS-232 RS-422 RS-485 1-3 (Default) 2-4 (Default) 7-9 (Default) 9-11 9-11 8-10 (Default)
- Page 19 BIH11-IHP User’s Manual JC1: LCD Backlight Inverter Connector This connector is for connecting to LCD for providing backlight control function. Pin Assignment BL_POWER BL_POWER BL_EN BL_CTL Ground Ground JLV1: LCD Panel Power Select Jumper This jumper is for selecting LCD Power.
- Page 20 BIH11-IHP User’s Manual LVDS-OUT1: LVDS Connector This connector supports 18/24 bit single-channel panels. Assignment Assignment PVDD2, 3.3V*/5V (selected LVDSB_DATA0_N by JLV1) PVDD2, 3.3V*/5V (selected LVDSB_DATA0_P by JLV1) Ground Ground Ground LVDSB_DATA1_N LVDSA_DATA0_N LVDSB_DATA1_P LVDSA_DATA0_P Ground Ground LVDSB_DATA2_N LVDSA_DATA1_N LVDSB_DATA2_P LVDSA_DATA1_P...
- Page 21 BIH11-IHP User’s Manual PE2: mSATA Slot Chapter 2: Hardware installation | 21...
- Page 22 BIH11-IHP User’s Manual Chapter 3: BIOS Setup Introduction The purpose of this manual is to describe the settings in the AMI UEFI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to NVRAM.
- Page 23 BIH11-IHP User’s Manual 3�1 Main Menu Once you enter AMI UEFI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system information. BIOS Information Shows system information including UEFI BIOS version, model name, marketing name, built date, etc.
- Page 24 BIH11-IHP User’s Manual 3.2 Advanced Menu The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power Management, and other system devices. Note » » Beware of that setting inappropriate values in items of this menu may cause system to malfunction. » » The options and default settings might be different by RAM or CPU models. ACPI Settings Enable ACPI Auto Configuration This item enables or disables BIOS ACPI Auto Configuration.
- Page 25 BIH11-IHP User’s Manual ACPI Sleep State This item allows you to select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. Options: S3 (Suspend to RAM) (Default) / Suspend Disabled Lock Legacy Resources The item enables or disables Lock of Legacy Resources.
- Page 26 BIH11-IHP User’s Manual Serial Port 1/ 2/ 3/ 4/ 5/ 6 Configuration Serial Port This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item allows you to select an optimal setting for Super IO device.
- Page 27 BIH11-IHP User’s Manual H/W Monitor CPU Configuration Active Processor Cores This item enableds or disableds number of cores to enable in each processor package. Options: All (Default) / 1 Limit CPUID Maximum This item enableds or disableds Windows XP. Options: Disabled (Default) / Enabled...
- Page 28 BIH11-IHP User’s Manual Adjacent Cache Line Prefetch This item enableds or disableds the Mid Level Cache (L2) streamer prefetcher. Options: Enabled (Default) / Disabled Intel Virtualization Technology This item enableds or disableds Intel Virtualization Technology. When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology.
- Page 29 BIH11-IHP User’s Manual Realtek PCIe GBE Family Controller Realtek PCIe GBE Family Controller Chapter 2: Hardware installation | 29...
- Page 30 BIH11-IHP User’s Manual Trusted Computing TPM Device Selection This item allows you to selects TPM device: PTT or dTPM. PTT - Enables PTT in SkuMgr dTPM 1.2 - Disables PTT in SkuMgr Warning! PTT / dTPM will be disabled and all data saved on it will be lost.
- Page 31 BIH11-IHP User’s Manual TPM2.0 UEFI Spec Version This item select the TCG2 Spec version support. TCG_1_2: the Compatible mode for Win8/ Win10 ; TCG_2: Support new TCG2 protocol and event format for Win10 or later. Options: TCG_2 (Default) / TCG_1_2 Physcal Presence Spec Version This item select to Tell O.S.
- Page 32 BIH11-IHP User’s Manual Fan Ctrl Start Value This item sets CPU FAN Start Speed Value. Options: 42 (Default) Fan Ctrl Sensitive The muneral is bigger, the Fan speed is higher. Options: 80 (Default) Network Stack Configuration Network Stack This item enables or disables UEFI network stack Options: Disabled (Default) / Enabled » ...
- Page 33 BIH11-IHP User’s Manual PXE boot wait time Wait time to press ESC key to abort the PXE boot. Media detect count Number of times pressence of media will be checked. CSM Configuration CSM Support This item enables or disables CSM Support...
- Page 34 BIH11-IHP User’s Manual Other PCI devices For PCI devices other than Network, Mass storage or video defines which OpROM to launch. Options: UEFI (Default) / Do not launch / Legacy USB Configuration Legacy USB Support This item enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected.
- Page 35 BIH11-IHP User’s Manual Device power-up delay in seconds Delay range is 1 ~ 40 seconds, in one second increments. Options: 5 (Default) USB FLASH DRIVE PMAP Mass storage device emulation type. ‘AUTO’ enumerates devices according to their media format. Optical drives are emulated as ‘CDROM‘ , drives with no media will be emulated according to a drive type.
- Page 36 BIH11-IHP User’s Manual 3�3 Chipset Menu This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components.
- Page 37 BIH11-IHP User’s Manual Graphics Configuration Primary Display This item selects which of IGFX/PEG/PCI Graphics device should be Primary Display or select SG for Switchable Gfx. Options: Auto (Default) / IGFX / PEG / PCI / SG Internal Graphics This item keep IGFX enabled based on the setup options.
- Page 38 BIH11-IHP User’s Manual Secondary IGFX Boot Display This item allows you to select Secondary Display device. Options: Disabled (Default) / DVI / HDMI / VGA PCH-IO Configuration HD Audio Configuration HD Audio This item control detection of the HD-Audio device. Disabled = HDA will be unconditionally disabled ;...
- Page 39 BIH11-IHP User’s Manual Onboard Device Onboard LAN1/2 This item enables or disables Onboard LAN1/2. Options: Enabled (Default) / Disabled Onboard LAN1/2 Ootion ROM This item enables or disable Onboard LAN1/2 option ROM. Options: Disabled (Default) / Enabled RTD213x eDP-LVDS IGD Flat Panel This item allows you to set IGD Flat Panel options.
- Page 40 BIH11-IHP User’s Manual 3.4 Security Administrator Password This item sets Administrator Password. User Password This item sets User Password. Secure Boot Secure Boot Secure Boot activated when: Secure Boot is enabled Platform Key (PK) is enrolled, System mode is User/Deployed, and CSM is disabled.
- Page 41 BIH11-IHP User’s Manual Restore Factory Keys Force System to User Mode. Configure NVRAM to contain OEM-defined factory default Secure Boot keys. Restore To Setup Mode Delete NVRAM content of all UEFI Secure Boot key databases. Key Management Factory Key Provision This item Provision factory default keys on next re-boot only when System in Setup Mode.
- Page 42 BIH11-IHP User’s Manual Forbidden Signatures Options: Details / Export / Update / Append / Delete Authorized TimeStamps Options: Details / Export / Update / Append / Delete OsRecovery Signatures Options: Update / Append 42 | Chapter 2: Hardware installation...
- Page 43 BIH11-IHP User’s Manual 3.5 Boot Menu This menu allows you to setup the system boot options. Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. Options: 1 (Default) Bootup NumLock State This item selects the keyboard NumLock state.
- Page 44 BIH11-IHP User’s Manual VGA Support If Auto, only install Legacy OpRom with Legacy OS and logo would NOT be shown during post. EFI driver will still be installed with EFI OS. Options: EFI Driver (Default) / Auto USB Support If Disabled, all USB devices will NOT be available until after OS boot. If Partial Initial, USB Mass Storage and specific USB port/device will NOT be available before OS boot.
- Page 45 BIH11-IHP User’s Manual 3.6 Save & Exit Menu This menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. Discard Changes and Exit Exit system setup without saving any changes. Save Changes and Reset Reset the system after saving the changes.
