Printer Setting Tool
Advanced Printing Adjustments Dialog Box
1 Printing Reference Point Adjustment
Adjust the position of the reference point (point of origin for printing). This corrects printing misalignments
resulting from differences in printer models or from the fixed margins of some applications.
2 Tear Adjust
Adjust the cutting position when the paper is cut using the tear bar.
Available settings: -10.0 to 10.0 mm
3 Energy Rank
Select a setting when it is necessary to adjust the amount of heat (energy) from the print head, for
example, with special paper.
Note
There may be contrast variations in the print result due to the operating environment and media used.
Change the setting if necessary.
