Summary of Contents for Gigabyte P17F R5
- Page 2 This manual will help you to get started with setting up your notebook. The final product configuration depends on the model at the point of your purchase. GIGABYTE reserves the right to amend without prior notice. For more detailed information, please visit our website at www.gigabyte.com.
-
Page 3: Switching On The Power
IMPORTANT • Ensure that your Notebook PC is connected to a grounded power adapter before turning it on for the first time. • When using your Notebook PC on power adapter mode, the socket outlet must be near to the unit and easily accessible. • Locate the input/output rating label on your Notebook PC and ensure that it matches the input/output rating information on your power adapter. -
Page 4: Left View
Your GIGABYTE Notebook Tour Top View Webcam on/off Indicator Webcam Built-In Mic Power Button LED Indicators Touchpad and buttons LED Indicators Flash Memory Card Reader Number Lock Activated Caps Lock Activated Scroll Lock Activated power on/Suspend Status LED ... -
Page 5: Right View
Right View Microphone input Jack Headphone output Jack USB Port 2.0 USB Port 3.0 Optical Drive Kensington Lock Port Bottom View Battery HDD & Memory Compartment • Do not install the Notebook PC on a slant or a place prone to vibrations, or avoid using the Notebook PC in that location for a long time.This increases the risk that a malfunction or damage to the product will occur. - Page 6 Hotkeys The computer employs hotkeys or key combinations to access most of the computer’s controls like screen brightness and volume output. To activate hotkeys, press and hold the <Fn> key before pressing the other key in the hotkey combination. Hotkey Description Icon Fn+Esc...
- Page 7 P17 Caddy bay instruction • Install the HDD into Caddy bay. • Unplug two screws and open the back cover. • Unplug one screw and take out the ODD bay. • Install the Caddy bay in notebook and lock the screws.
- Page 8 Recovery Guide System Recovery (Restore your laptop operating system) When something is going wrong with the laptop operating system, the storage of the laptop has a hidden partition containing a full back up image of the operating system that can be used to restore the system to factory default settings.
- Page 9 > [Click on “Reset” to execute recovery function.] Here are what will happen ˙ All of your personal files and apps will be removed. ˙ Your PC settings will be restored to pure O/S (without GIGABYTE app) .
- Page 10 ▓ ▓ ▓ ▓ G IGABYTE Smart Recovery ▓ The recovery will be activated and you will see the option buttons on the window. Click on “Yes” to start it. Caution ˙ Once the “Recovery” is selected, your personal data and files will be deleted after the laptop starts restoring, and the operating system will be reset to factory default settings.
-
Page 11: Warranty And Service
Appendix Warranty & Service: ▓ Warranty and service and related information please refer to the warranty card or GIGABYTE service website as the below link: http://www.gigabyte.com/support-downloads/technical-support.aspx FAQ: ▓ FAQ (Frequent Asked Questions) please refer to the below link: http://www.gigabyte.com/support-downloads/faq.aspx...
