- Page 2 This manual will help you to get started with setting up your notebook. The final product configuration depends on the model at the point of your purchase. GIGABYTE reserves the right to amend without prior notice. For more detailed information, please visit our website at www.gigabyte.com...
-
Page 3: Top View
Your GIGABYTE Notebook Tour Top View Webcam Status LED Indicator Webcam Microphone Power Button TouchPad LED Indicators Battery Indicator Button Bluetooth Status LED Wireless Lan Status LED HDD Status LED Battery Status LED Power Status LED Press the right button of touchpad to ... -
Page 4: Right View
Speakers Warning: DO NOT remove the built-in lithium battery. For any service needs, please contact your local GIGABYTE Authorized Service Center. • Do not install the Notebook PC on a slant or a place prone to vibrations, or avoid using the Notebook PC in that location for a long time.This increases the risk that a malfunction or damage to the product will occur. - Page 5 Hotkeys The computer employs hotkeys or key combinations to access most of the computer’s controls like screen brightness and volume output. To activate hotkeys, press and hold the <Fn> key before pressing the other key in the hotkey combination. Hotkey Function Description Fn+ESC...
- Page 6 Swappable bay Application Unlock swappable bay locker. Draw the swappable bay out. 9.5mm/7mm HDD/SSD only Connect the HDD or SSD pin by sliding it into the connecter.
- Page 7 Gently push the plastic frame outwards. Slide in the HDD or SSD until it locks into place. There will be a slight click. Pull swappable bay back to slot. Lock swappable bay locker.
- Page 8 GIGABYTE Smart Manager „ You can activate GIGABYTE Smart Manager by double clicking on the shortcut icon on the desktop if the machine you purchased has the operation system built-in. GIGABYTE Smart Manager is an icon-based control interface, enabling users to intuitionally access common system setup as well as GIGABYTE exclusive utilities.
- Page 9 • Insert the driver disk to your optical drive and run the install of “Smart USB Backup” (for none-ODD model, please use USB ODD device or download from http://www.gigabyte.com • Run the “Smart USB Backup” after finishing the install. • Select your USB disk from the drop- down list and start to create the recovery USB disk.
- Page 10 Recovery Guide System Recovery (Restore your laptop operating system) When something is going wrong with the laptop operating system, the storage of the laptop has a hidden partition containing a full back up image of the operating system that can be used to restore the system to factory default settings.
- Page 11 You can choose to keep or remove your files and then reinstalls Windows without losing your files. ˙ GIGABYTE Smart Recovery Your PC settings will be restored to factory default settings. Caution: All personal data and files will be lost.
- Page 12 > [Click on “Reset” to execute recovery function.] Here are what will happen ˙ All of your personal files and apps will be removed. ˙ Your PC settings will be restored to pure O/S (without GIGABYTE app) . ▓ ▓ ▓ ▓ G IGABYTE Smart Recovery ▓...
- Page 13 Startup Settings Change Windows Startup behavior. Appendix Warranty & Service: „ Warranty and service and related information please refer to the warranty card or GIGABYTE service website as the below link: http://www.gigabyte.com/support-downloads/technical-support.aspx FAQ: „ FAQ (Frequent Asked Questions) please refer to the below link:...
