This section describes the physical layout of the RM57L HDK board and its interfaces.
2.1
Board Layout
The RM57L HDK board is a 4.9 x 4.3 inch (125 x 109 mm) eight layer printed circuit board that is powered
by an external +5 V to approximately +12 V only power supply.
HDK board.
8
Physical Description
Figure 2-1. RM57L HDK Board, Interfaces Top Side
Copyright © 2014, Texas Instruments Incorporated
Physical Description
Figure 2-1
shows the layout of the RM57L
Hercules
RM57L843
Chapter 2
SPNU598 – May 2014
SPNU598 – May 2014
