CONNECTION AND MAINTENANCE
n Supplied Accessories
Microphone
DC power cable
Socket terminals
Fuses*
1
Separation
cable
Key caps
17
Microphone hanger
and screw set
Black and red cables
with fuse holders
Crimp terminals
Binding bands
Function name
2
stickers*
KEY-STICKER
Housing
*
1
Fuses should be installed in the fuse holder of the black and red cables, respectively.
See p. 20 for details.
*
2
Used for labelling the programmable function keys according to their assinged functions.
Mounting bracket
for main unit
Mounting bracket
for controller
Flat washers
Mounting screws
(M5)
(M5×12)
Spring washers
Self-tapping screws
(M5×16)
(M5)
Nuts (M5)
Bracket bolts
Flat washers
Mounting screws
(M5)
(M5×12)
Spring washers
Self-tapping screws
(M5)
(M5×16)
Nuts (M5)
Bracket screws
