CF-50
Mid-size floorstanding speaker with black ash cabinet
High gloss black baffle, floating grille add to dramatic appearance
Convergent Source Module
Tweeter and woofer in proximity act as single source to increase
dispersion
Crisp 1-inch hyperbolic aluminum dome tweeter
Clear, accurate highs add detail to your listening
Three 5.5-inch woofers with Ribbed Elliptical Surround, tapered
crossover
Deliver tight and powerful distortion-free low-frequency response
Dual gold-plated 5-way binding posts
Ensure reliable connection for high-quality sound; bi-wire, bi-amp
enabled
Bass reflex design with front firing port
Provides outstanding bass extension
All Energy brand components were developed with these sonic
principles in mind:
•
Flat On-Axis Frequency Response with Wide Bandwidth
Speakers should reproduce the entire audio range in a uniform
manner. By ensuring that no one frequency dominates any other,
Energy ensures that every note is the way it was intended to be—and
the sound is as natural as possible.
•
Wide and Constant Dispersion
Sound at all frequencies radiating from the speaker should be in an
even pattern, in all directions throughout the room.
Low Distortion and Resonance
•
No speaker system is totally distortion- or resonance-free, but Energy
has achieved a significantly lower distortion level—a clearly audible
improvement.
S p E C i F i C AT i O n S
2.5-way floorstanding, magnetically shielded bass
Speaker System
reflex with front-firing port
Frequency Response (+/- 3dB)
39Hz - 20kHz
Tweeter
1-inch (25.4mm) hyperbolic aluminum-dome
Woofers
3 x 5.5-inch (140mm) w/Ribbed Elliptical Surrounds
Crossover point(s)
2kHz, 1.2kHz
Efficiency (Room)
96dB
impedance
4 Ohms min./8 Ohms nominal
Recommended Amp. power
20-250 W /channel
Dimensions H x W x D
38.6 x 7.1 x 14.6 inches
including feet
98.1 x 18 x 37cm
Units/Carton
1
product Weight (Single)
39.3 lbs / 17.8 kg
packed Weight
45.3 lbs / 20.5 kg
inputs
Dual gold plated 5-way binding posts
Finish
High gloss black baffle with black ash cabinet
included Accessories
Manual, port plugs
All specifications are subject to change without notice. ©2008
C F - 5 0
www.energy-speakers.com
