CC-10
attractive center channel speaker with black ash cabinet
High gloss black baffle, floating grille add to dramatic appearance
convergent Source Module
Tweeter and woofer in proximity act as single source to increase
dispersion
crisp 1-inch hyperbolic aluminum dome tweeter
Clear, accurate highs add detail to your listening
two powerful 5.5-inch woofers with Ribbed elliptical Surround
Deliver tight, distortion-free low-frequency response
Gold-plated 5-way binding posts
Ensure reliable connection for high-quality sound
proven bass reflex design with rear firing port
Provides outstanding bass extension; deep-reaching performance
all energy brand components were developed with these sonic
principles in mind:
•
flat on-axis frequency Response with Wide Bandwidth
Speakers should reproduce the entire audio range in a uniform
manner. By ensuring that no one frequency dominates any other,
Energy ensures that every note is the way it was intended to be—and
the sound is as natural as possible.
•
Wide and constant Dispersion
Sound at all frequencies radiating from the speaker should be in an
even pattern, in all directions throughout the room.
Low Distortion and Resonance
•
No speaker system is totally distortion- or resonance-free, but Energy
has achieved a significantly lower distortion level—a clearly audible
improvement.
S p e c i f i c at i o n S
2.5-way center, magnetically shielded bass reflex
Speaker System
with rear-firing port
frequency Response (+/- 3dB)
60Hz - 20kHz
tweeter
1-inch (25.4mm) hyperbolic aluminum-dome
2 x 5.5-inch (140mm) w/Ribbed Elliptical
Woofers
Surrounds
crossover point(s)
2.6kHz, 1.8kHz
efficiency (Room)
92dB
impedance
4 Ohms min./8 Ohms nominal
Recommended amp. power
20-200 W /channel
7.1 x 19.7 x 9.9 inches
Dimensions H x W x D
18 x 50 x 25.2cm
Units/carton
1
product Weight (Single)
17.4 lbs / 7.9 kg
packed Weight
20.5 lbs / 9.3 kg
inputs
Gold plated 5-way binding posts
finish
High gloss black baffle with black ash cabinet
included accessories
Manual, port plugs, rubber bumpers
All specifications are subject to change without notice. ©2008
c c -1 0
www.energy-speakers.com
