GA-686LX3
TABLE OF CONTENTS
1.
INTRODUCTION.................................................................................. 1-1
1.1. PREFACE.............................................................................................................1-1
1.2. KEY FEATURES ..................................................................................................1-1
1.3. PERFORMANCE LIST.........................................................................................1-2
1.4. BLOCK DIAGRAM ...............................................................................................1-3
1.5. INTRODUCE THE Pentium ® II Processor ..........................................................1-4
1.6. What is AGP? .......................................................................................................1-6
2.
SPECIFICATION ................................................................................. 2-1
2.1. HARDWARE ........................................................................................................2-1
2.2. SOFTWARE.........................................................................................................2-2
2.3. ENVIRONMENT...................................................................................................2-2
3.
HARDWARE INSTALLATION.............................................................. 3-1
3.1. UNPACKING ........................................................................................................3-1
3.2. MAINBOARD LAYOUT ........................................................................................3-2
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS ................................3-3
3.4. DRAM INSTALLATION........................................................................................3-5
3.5. CPU SPEED SETUP ...........................................................................................3-5
3.6. CMOS RTC & ISA CFG CMOS SRAM................................................................3-6
3.7. SPEAKER CONNECTOR INSTALLATION ........................................................3-6
3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION.......................3-6
3.9. POWER LED CONNECTOR INSTALLATION ...................................................3-6
1
Advertisement
Table of Contents
Related Manuals for Gigabyte GA-686LX3
Summary of Contents for Gigabyte GA-686LX3
-
Page 1: Table Of Contents
GA-686LX3 TABLE OF CONTENTS INTRODUCTION.................. 1-1 1.1. PREFACE......................1-1 1.2. KEY FEATURES ....................1-1 1.3. PERFORMANCE LIST..................1-2 1.4. BLOCK DIAGRAM ....................1-3 1.5. INTRODUCE THE Pentium ® II Processor ............1-4 1.6. What is AGP? .......................1-6 SPECIFICATION ................. 2-1 2.1. HARDWARE ......................2-1 2.2. SOFTWARE......................2-2 2.3. - Page 2 Table of Contents 3.10. IDE & ATAPI DEVICE INSTALLATION.............3-7 3.11. PERIPHERAL DEVICE INSTALLATION............3-7 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION..........3-7 BIOS CONFIGURATION ..............4-1 4.1. ENTERING SETUP .....................4-1 4.2. CONTROL KEYS ....................4-1 4.3. GETTING HELP....................4-2 4.3.1. Main Menu....................4-2 4.3.2. Status Page Setup Menu / Option Page Setup Menu.......4-2 4.4.
-
Page 3: Introduction
GA-686LX3 INTRODUCTION 1.1. PREFACE Welcome to use the GA–686LX3 motherboard. It is a Pentium ® II Processor based PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want. -
Page 4: Performance List
Introduction 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) •... -
Page 5: Block Diagram
GA-686LX3 1.4. BLOCK DIAGRAM 66MHz 14.318MHz 3.3V EDO/SDRAM SLOT DIMM Sockets Host Bus 82432LX 66MHZ AGP Bus CHIPSET DRAM Bus 66MHz 33MHz 52C64-25 33MHz Ultra DMA/33 24MHz IDE Ports 52C64-06 PCI Bus 33MHz PIIX4 48MHz USB Ports 82371AB 14.318MHz IDE Bus... -
Page 6: Introduce The Pentium ® Ii Processor
Introduction 1.5. INTRODUCE THE Pentium ® II Processor & AGP Figure 1:Retention Mechanism & attach Mount Figure 2:OEM Pentium ® II Processor... - Page 7 GA-686LX3 Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium ® II Processor Figure 4:Boxed Pentium ® II Processor & Heat sink support...
-
Page 8: What Is Agp
Introduction 1.6 What is AGP? The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32- bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing. -
Page 9: Specification
GA-686LX3 SPECIFICATION 2.1. HARDWARE • Pentium ® II processor 200 – 633 MHz. − − 242 pins 66MHz slot1 on board. • − 66 MHz system speed. SPEED − 66 MHz AGP bus speed. (133MHz 2*mode) − 33 MHz PCI-Bus speed. -
Page 10: Software
Specification − • Suspend mode support. GREEN FUNCTION − Green switch & ACPI LED support. − IDE & Display power down support. − Monitor all IRQ / DMA / Display / I/O events. − • 1M bits FLASH RAM. BIOS −... -
Page 11: Hardware Installation
GA-686LX3 HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: • The GA – 686LX3 mainboard. • The Retention Mechanism & Attach Mount • USER'S MANUAL for mainboard. • Cable set for IDE, Floppy & I/O devices. •... -
Page 12: Mainboard Layout
Hardware Installation 3.2. MAINBOARD LAYOUT0 COMA COMB MOUSE BATT1 BIOS KB Power On Slot 1 Fan Power INTEL 440LX DIMM1 PIIX4 DIMM2 GA-686LX3 DIMM3 IDE2 ATX Power 4 3 2 1 IDE1 FLOPPY PW Led Soft Power ×Figure 3.1Ø... -
Page 13: Quick Reference For Jumpers & Connectors
GA-686LX3 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port. For Primary IDE port. For Secondary IDE port. For PS/2 Keyboard port. For PS/2 Mouse port. For Floppy port For Serial port2 (COM B). For Serial port1 (COM A). - Page 14 Hardware Installation JP1 : Keyboard Power On Selection Pin No. Function Enabled Keyboard power on. Disabled Keyboard power on. RST : RESET Switch Pin No. Function RESET Input PWR : POWER ON LED ( PW-LED) Pin No. Function LED POWER (+) Slot 1 For Pentium ®...
-
