We advise you to read this manual carefully, which contains all the instructions for
maintaining the appliance's aesthetic and functional qualities.
For further information on the product: www.smeg.com
Contents
4
4
7
8
8
8
8
9
9
10
10
11
11
13
13
14
15
16
18
20
21
23
23
23
24
25
25
27
29
29
29
32
36
42
43
3
Advertisement
Table of Contents
Related Manuals for Smeg CS95GMBNA
Summary of Contents for Smeg CS95GMBNA
-
Page 1: Table Of Contents
5.3 Adaptation to different types of gas 5.4 Positioning 5.5 Electrical connection 5.6 For the installer We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com... -
