Page 1: Table Of Contents
C ONTE NTS S AFE TY INS TR UC TION C AUTIONS FC C R F INTE R FE R E NC E S TATE ME NT C ONNE C TING WITH E XTE R NAL E QUIP ME NT R E S OLUTION C ONTR OLS AND FUNC TIONS R E MOTE C ONTR OLLE R FUNC TIONS... -
Page 2: Safety Instruction
SAFETY INSTRUCTION 1. Read all of these instructions. 2. Save these instructions for later use. 3. Follow all warnings and instructions marked on the product. 4. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 5. -
Page 6: C Autions
CONNECTING WITH EXTERNAL EQUIPMENT Be sure to turn off the power of your computer before connecting the monitor. 1. CONNECT THE VIDEO SIGNAL CABLE A. Connect one end of the signal cable to the back panel of the monitor and connect the other end to the graphic card on back of the computer. B. -
Page 8: Controls And Functions
CONTROLS AND FUNCTIONS B. SOURCE BUTTON C. MENU BUTTON D. CHANNEL BUTTONS (DOWN & UP) E. VOLUME BUTTONS (LEFT & RIGHT) REMOTE CONTROLLER SENSOR A. POWER SWITCH A. POWER ON/OFF( Turns the power ON or OFF. There will be a few seconds delay before the display appears. - Page 9 CONTROLS AND FUNCTIONS D. CHANNEL( CH: Increases or decreases the channel number. (In PC mode, down key operates as “Auto adjust”) This button allows user to enter the sub-menu of the activated function when down key is pressed on the main menu. E.
- Page 10 CONTROLS AND FUNCTIONS : Screen : Brightness Increase or decrease the intensity of the image. : Contrast Increase or decrease the intensity(lightness or dimness) of the image. : H. position (PC Mode Only) Move image horizontally on screen right or left. : V.
- Page 11 CONTROLS AND FUNCTIONS : Audio : Volume Adjust audio volume. : Equalizer (Loudspeaker Only) Boost / Cut specific frequency or compensate for frequency distortion of the sound . Select preferred Sound setting: flat, music, movie, speech and Adjust the level of the Sound frequency in user mode. : Balance (Loudspeaker Only) Adjust the balance of left and right speaker sound .
- Page 12 CONTROLS AND FUNCTIONS : OSD : H. Position Move the OSD position to right( ) or left( ). : V. Position Move the OSD position to up( ) or down( ). : Transparency Select the OSD background. : OSD Timer Select the OSD display timing.
- Page 14 CONTROLS AND FUNCTIONS : Utility : Recall Select to reset all setting to the factory default values. : Full Auto (PC Mode Only) Auto geometry and color adjustment. : Caption (NTSC Only) Enable or disable closed caption feature(CC1, CC2, CC3, CC4). : Vchip (NTSC, US Only) Initial passwords is “0000”.
- Page 15 CONTROLS AND FUNCTIONS 1) TV Guidelines : Not Rated TV-Y : Young Children TV-Y7 : Children 7 and over TV-G : General Audience TV-PG : Parent Guidance TV-14 : Viewer 14 and over TV-MA : Mature Audience (FV : Fantasy Violence V : Violence S : Sexual Situation L : Coarse Language...
- Page 16 CONTROLS AND FUNCTIONS : TV Channel (Program) This menu is possible to select, Input Source must be set ‘TV’. : Auto Search Find available channels(Program) and save automatically. : Fine Tuning Adjust a mismatch between real and programmed channel(Program). : Store / Clear Select “Store”...
- Page 17 CONTROLS AND FUNCTIONS : Exit : Exit Turn off OSD Menu. INSTRUCTION MANUAL...
-
Page 18: Remote Controller Functions
REMOTE CONTROLLER FUNCTIONS F. REMOTE CONTROLLER 1. POWER( Turns the power ON or OFF. There will be a few seconds delay before the display appears. 2. SOURCE Select pc or video(TV / Video / S-Video / SCART) sources. 3. MUTE Mute the sound. - Page 19 REMOTE FUNCTIONS 8. DISPLAY Channel display in TV Source. 9. TV Change Input Source to TV. 10. AUTO Auto geometry adjustment in PC Source. 11. EXIT Exit the On Screen Display. 12. TEXT ( Select Teletext display / Return to TV picture display. 13.
-
Page 20: Rear View
REAR VIEW G. AC INLET Power cord connection. NOTE: Power cord is used as main power disconnect device in this product. H. D-SUB CONNECTOR Connect to the video signal cable. G. AC INLET H. D-SUB CONNECTOR ACCESSORY 1. POWER CORD 2. -
Page 21: Stand Slope
STAND SLOPE TORQUE BY POSITION Recommend that the slope from 0 to 20 degree. In case of the degree is more than 20, please refer below sheet. FOLD POSITION SLOPE TORQUE(kgf cm) -3 ~20 23~27 20 ~80 78~85 80 ~95 23~27 INSTRUCTION MANUAL... -
Page 23: Power Management
POWER MANAGEMENT This monitor features a power management system to “power down” upon receipt of the VESA DPMS(The display power management signaling) from a VESA DPMS video card. The VESA DPMS-compliant video card performs this signaling system through not sending horizontal, vertical, or sync signal. This monitor enters an appropriate mode through identifying each of the three modes of the signaling system. -
Page 24: Specifications
SPECIFICATIONS LCD Type 20.1 Diagonal AM-TFT(Active-Matrix) Pixel pitch(mm) : 0.51(H) 0.51(V) BRIGHTNESS: 500cd/ (Typical) CONTRAST RATIO: 500:1(Typical) RESPONSE TIME: Tr -5msec, Tf-11msec(Typical) RESOLUTION(H x V) 800X600 @75Hz FREQUENCY HORIZONTAL: 31-48KHz VERTICAL: 56-75Hz INPUT SIGNAL VIDEO(Analog 0.7Vp-p / 75 ) SYNC(Separate TTL Level) SCART, S-VIDEO, AV(Composite, Sound L/R) PC Stereo Sound, RF(Tuner option) ACTIVE DISPLAY AREA (W x H) -
Page 25: Troubleshooting Guide
TROUBLESHOOTING GUIDE TROUBLE TROUBLESHOOTING TIP No image on display screen 1. Check that power cord of the Monitor have been connected securely into wall outlet or grounded extension cable or strip. 2. Power switch should be in the ON position and LED is lit.
