DISHWASHER WET TEST
STEP 20
• Turn on power supply or plug power cord into outlet,
if equipped.
• Select a cycle to run and push the START button.
• Ensure the door is latched. Dishwasher should start.
• Check to be sure that water enters the dishwasher.
If water does not enter the dishwasher, check to be
sure that water and power are turned on.
• Check for leaks under the dishwasher. If a leak
is found, turn off power at the breaker, and then
tighten water connections. Restore power after leak
is corrected.
• Check for leaks around the door. A leak around
the door could be caused by door rubbing or
hitting against adjacent cabinets. Reposition the
dishwasher if necessary. See Step 13.
• Press and hold the START button for 3 seconds to
cancel the cycle. The unit will begin to drain. Check
drain lines. If leaks are found, turn off power at the
breaker and correct plumbing as necessary. Restore
power after corrections are made. See Steps 7, 8, 9,
10 and 17.
• Open dishwasher door and make sure all of the
water has drained. If not, check that disposer plug
has been removed and/or air gap is not plugged.
Also check drain hose to be sure it is not kinked
underneath or behind dishwasher. See Step 17.
• Press START button once again and run dishwasher
through another cycle. Check for leaks and correct if
required.
• Repeat these steps as necessary.
Dishwasher Installation
15
REPLACE FLOOR
STEP 21
PROTECT PAN
• Slide the floor protect pan under the dishwasher
until its side lock slots are close to engaging the side
mounting tabs on the dishwasher.
• Lift the pan until its lock slots contact the mounting
tabs and push the pan back to engage them.
Mounting Tab
Two on each side
of the dishwasher
Rear
Floor Protect
Pan
• When properly installed, the top of the lock slots will
be over the mounting tabs.
• Connect the leak sensor connector to the leak sensor
(on some models).
Leak Sensor
(on some models)
Floor Protect
Pan
Figure AE
Lock Slots
Two on each side of
the floor protect pan
Front
Mounting
Tab
Lock Slot
