Casio 2330 User Manual

Module No. 2330
Press B to change from mode to mode.
If you do not perform any operation for a few minutes while a setting screen (with flashing digits) is on the display, the watch automatically exits the setting screen.
Timekeeping Mode
TIMEKEEPING MODE
Pressing C in the Timekeeping Mode illuminates the display for about two sec-
onds. The backlight is disabled while a setting screen is on the display.
When using 12-hour timekeeping, a P appears on the display for "pm" times (noon
to 11:59 pm). An "am" time (midnight to 11:59 am) is indicated when there is no P
indicator on the display. 24-hour timekeeping is being used when the 24 indicator is
on the display.
Hour hand
Second hand
To set the time and date
1. While in the Timekeeping Mode, hold down A until the
24 indicator
2. Press B to move the flashing in the sequence shown below.
Press B.
Seconds
Day Month
3. While the seconds setting is selected (flashing), press C to reset it to 00.
If you press C while the seconds setting is in the range of 30 to 59, the seconds
are reset to 00 and 1 is added to the minutes. If the seconds setting is in the range
of 00 to 29, the minutes count is unchanged.
While the DST (Daylight Saving Time) setting is selected, press C to toggle it on
and off.
DST indicator 2
DST indicator 1
DST OFF
Daylight Saving Time (DST), which is also sometimes called "summer time" ad-
vances the time for one hour, as is the custom in some areas during the summer.
Remember that not all countries or even local areas use Daylight Saving Time.
DST indicator 1 flashes while the DST setting is selected. It also appears in the
Timekeeping Mode and Alarm Mode to indicate that DST is turned on. DST indica-
tor 1 does not appear in the Timekeeping Mode when DST is turned off.
DST indicator 2 appears (flashing) only while the DST setting is selected on the
setting screen. 0 indicates that DST is turned off, while 1 indicates that DST is
turned on.
While the 12/24 setting is selected, press C to toggle it between 12-hour and 24-
hour timekeeping.
4. While any other digits are selected (flashing), press C to increase the selected
digits. Holding down changes them at high speed.
5. After you make the settings you want, press A to exit the setting screen.
The day of the week is automatically set in accordance with the date.
The date can be set within the range of January 1, 2000 to December 31, 2039.
When setting the year, you need to specify only the rightmost two digits. To specify
the year 2001, for example, set 01.
To set the hands
When the analog setting does not match the time shown on the display, use the
following procedure to correct the analog setting.
1. When the second hand reaches the 12 o'clock position (00 seconds), pull out the
crown to stop the second hand.
2. Hold down A until the seconds digits appear and flash on the display.
3. Rotate the crown to set the hour and minutes.
4. When the seconds count on the digital display reaches 00, press in the crown to
restart the second hand.
5. Press A to exit the setting screen.
Countdown Alarm Mode
Press B.
Minute hand
PM indicator
Hour : Minutes
Month Day of week
Day
seconds digits appear and flash on the display. This
indicates the setting screen.
DST Hour Minutes
Year
DST indicator 2
DST indicator 1
Press C.
DST ON
GENERAL GUIDE
About the Auto Light Switch Function
When the auto light switch function is turned on, the backlight automatically turns on
for two seconds under the conditions described below. Avoid wearing the watch on
the inside of your wrist. Doing so causes the auto light switch to operate when not
needed, which shortens battery life.
Moving the watch to a position that is parallel to the ground and then tilting it
towards you approximately 40 degrees causes the backlight to illuminate.
The backlight may not illuminate if the face of the watch is more than 15 degrees off
parallel to the left or right. Make sure that the back of your hand is parallel to the
ground.
Parallel to ground
Static electricity or magnetic force can interfere with proper operation of the auto
light switch function. If the backlight does not illuminate, try moving the watch back
to the starting position (parallel with the ground) and then tilt it back toward you
again. If this does not work, drop your arm all the way down so it hangs at your side,
and then bring it back up again.
Under certain conditions the backlight may not light until about one second or less
after turn the face of the watch towards you. This does not necessarily indicate
malfunction of the backlight.
To switch the auto light switch function on and off
12/24
In the Timekeeping Mode (except when making any settings), hold down C for two
seconds to turn the auto light switch function on and off.
The auto light switch indicator is shown on the display in all modes while the auto
light switch function is on.
In order to protect against running down the battery, the auto light switch function is
automatically turned off approximately five hours after you turn it on. Repeat the
above procedure to turn the auto light switch function back on if you want.
Pressing C in the Timekeeping Mode (except when making any settings) illumi-
nates the display, regardless of the auto light switch's on/off setting.
Caution
The backlight of this watch employs an electro-luminescent (EL) light, which loses
its illuminating power after very long term use.
Frequent use of the backligfht shortens the battery life.
The watch emits an audible sound whenever the display is illuminated. This is be-
cause the EL light vibrates slightly when lit. It does not indicate malfunction of the
watch.
Warning!
Never try to read your watch when mountain climbing or hiking in areas that
are dark or in areas with poor footing. Doing so is dangerous and can result
in serious personal injury.
Never try to read your watch when running where there is the danger of acci-
dents, especially in locations where there might be vehicular or pedestrian
traffic. Doing so is dangerous and can result in serious personal injury.
Never try to read your watch when riding on a bicycle or when operating a
motorcycle or any other motor vehicle. Doing so is dangerous and can result
in a traffic accident and serious personal injury.
When you are wearing the watch, make sure that its auto light switch function
is turned off before riding on a bicycle or operating a motorcycle or any other
motor vehicle. Sudden and unintended operation of the auto light switch can
create a distraction, which can result in a traffic accident and serious personal
injury.
Day Counter Mode
ABOUT THE BACKLIGHT
Parallel to ground
More than 15 degrees
too high
Auto light switch
indicator
Hold down C.
ON
2330-1
Alarm Mode
40
More than 15 degrees
too low
OFF
