- Page 1 Products Solutions Services BA02213F/00/EN/01.21-00 71548519 2022-02-28 Valid as of version 01.00.zz (Device firmware) Operating Instructions Liquiphant FTL51B Vibronic HART Point level switch for liquids...
- Page 2 Liquiphant FTL51B HART Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
-
Page 3: Table Of Contents
Liquiphant FTL51B HART Table of contents Table of contents About this document ....6 Electrical connection ....18 Purpose of this document . - Page 4 Table of contents Liquiphant FTL51B HART 9.4.2 FieldCare/DeviceCare via service 11.8.2 Resetting the device via operating interface (CDI) ....keys on the electronic insert ..
- Page 5 Liquiphant FTL51B HART Table of contents 15.3.11 Electromagnetic compatibility (EMC) ......58 15.4 Process ......58 15.4.1 Process temperature range .
-
Page 6: About This Document
About this document Liquiphant FTL51B HART About this document Purpose of this document These Operating Instructions contain all the information that is required in the various phases of the life cycle of the device: from product identification, incoming acceptance and storage, to mounting, connection, operation and commissioning through to troubleshooting, maintenance and disposal. -
Page 7: Symbols In Graphics
Registered trademark of the FieldComm Group, Austin, Texas, USA Bluetooth® The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Endress+Hauser is under license. Other trademarks and trade names are those of their respective owners. Apple®... -
Page 8: Incorrect Use
It meets the general safety standards and legal requirements. It also complies with the EU directives listed in the device-specific EU Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device. Endress+Hauser... -
Page 9: Functional Safety Sil (Optional)
Liquiphant FTL51B HART Product description Functional Safety SIL (optional) The Functional Safety Manual must be strictly observed for devices that are used in functional safety applications. IT security We only provide a warranty if the device is installed and used as described in the Operating Instructions. -
Page 10: Product Design
Incoming acceptance and product identification Liquiphant FTL51B HART Product design A0046337 1 Product design Housing with electronic insert and cover Temperature spacer, pressure-tight feedthrough, optional Process connection with flange Process connection with thread Standard probe with tuning fork Pipe extension probe with tuning fork... -
Page 11: Product Identification
All of the information on the measuring device is displayed along with an overview of the scope of technical documentation provided. • Enter the serial number on the nameplate into the Endress+Hauser Operations app or scan the 2-D matrix code on the nameplate with the Endress+Hauser Operations app 4.2.1... -
Page 12: Mounting
Mounting Liquiphant FTL51B HART A0034846 2 Handling the device during transportation Mounting Mounting instructions • Any orientation for device with short pipe up to approx. 500 mm (19.7 in) • Vertical orientation from above for device with long pipe •... -
Page 13: Take Viscosity Into Consideration
Liquiphant FTL51B HART Mounting A0037915 4 Typical switch points. Unit of measurement mm (in) Installation from above Installation from below Installation from the side Switch point 5.1.2 Take viscosity into consideration Low viscosity Low viscosity, e.g. water: < 2 000 mPa⋅s It is permitted to position the tuning fork within the installation socket. -
Page 14: Avoid Buildup
Mounting Liquiphant FTL51B HART 5.1.3 Avoid buildup • Use short installation sockets to ensure that the tuning fork projects freely into the vessel • Leave sufficient distance between the buildup expected on the tank wall and the tuning fork A0033239 ... -
Page 15: Weld-In Adapter With Leakage Hole
Liquiphant FTL51B HART Mounting A0031874 9 Examples of support in the event of dynamic load Marine approval: In the case of pipe extensions or sensors longer than 1 600 mm, a support is needed at least every 1 600 mm. - Page 16 Mounting Liquiphant FTL51B HART A0039125 11 Markings to align the tuning fork Installing in pipes • Flow velocity up to 5 m/s with a viscosity of 1 mPa⋅s and density of 1 g/cm (SGU). Check for correct functioning in the event of other process medium conditions.
- Page 17 Liquiphant FTL51B HART Mounting Aligning the cable entry 4 3.5 Nm A0037347 14 Housing with external locking screw and drip loop The locking screw is not tightened when the device is delivered. 1. Loosen the external locking screw (maximum 1.5 turns).
-
Page 18: Sliding Sleeves
Electrical connection Liquiphant FTL51B HART 4 0.7 Nm A0038224 1. If fitted: release the screw of the cover lock for the electronics compartment cover using the Allen key. 2. Unscrew the cover from the housing and inspect the cover seal. -
Page 19: Connecting Requirements
Liquiphant FTL51B HART Electrical connection Connecting requirements 6.2.1 Cover with securing screw In the case of devices for use in the hazardous area with a certain type of protection, the cover is sealed by a securing screw. NOTICE If the securing screw is not positioned correctly, the cover cannot provide secure sealing. -
Page 20: Connecting The Device
Electrical connection Liquiphant FTL51B HART Connecting the device A0046355 Connection compartment cover Housing thread The thread of the electronics and connection compartment is coated with lubricant varnish. Avoid additional lubrication. 6.3.1 Supply voltage • U = 10.5 to 35 V (Ex d, Ex e, non-Ex) •... -
Page 21: 4-20 Ma Hart
6.3.5 Overvoltage protection Devices without optional overvoltage protection Equipment from Endress+Hauser fulfills the requirements of the product standard IEC/DIN EN 61326-1 (Table 2 Industrial Environment). Depending on the type of port (DC supply, input/output port) different test levels according to IEC/DIN EN 61326-1 against transient overvoltages (Surge) are applied... -
Page 22: Wiring
Electrical connection Liquiphant FTL51B HART 6.3.6 Wiring WARNING Supply voltage might be connected! Risk of electric shock and/or explosion! ‣ If the device is used in hazardous areas, make sure to comply with national standards and the specifications in the Safety Instructions (XAs). The specified cable gland must be used. -
Page 23: Cable Entries
Liquiphant FTL51B HART Electrical connection Dual-compartment housing, L-shape A0045842 18 Connection terminals and ground terminal in the connection compartment Positive terminal Negative terminal Internal ground terminal 6.3.8 Cable entries A0045831 Cable entry Dummy plug The type of cable entry depends on the device version ordered. -
Page 24: Ensuring The Degree Of Protection
Electrical connection Liquiphant FTL51B HART M12 plug A0011175 19 M12 plug, pin assignment Signal + Not assigned Signal – Ground For more details, see the "Accessories" section. Ensuring the degree of protection 6.4.1 Degree of protection In accordance with DIN EN 60529, NEMA 250 IP66/IP68 NEMA 4X/6P (1.83 m H... -
Page 25: Operation Options
• Operation via optical operating keys on the device display (optional) • Operation via Bluetooth® wireless technology (with optional device display with Bluetooth) with Smartblue app or FieldXpert, DeviceCare • Operation via operating tool (Endress+Hauser FieldCare/DeviceCare, handheld terminal, AMS, PDM, ...) 4 to 20 mA HART (FEL60H) electronic insert... -
Page 26: Function Test Using Operating Key On Electronic Insert
Operation options Liquiphant FTL51B HART Function test using operating key on electronic insert Display A0046571 21 Operating keys on the electronic insert Operating key for reset password Operating key for proof test (> 3 s) When performing the proof test in safety instrumented systems according to SIL or WHG: comply with the instructions in the Safety Manual. -
Page 27: Structure And Function Of The Operating Menu
Structure and function of the operating menu The differences between the structure of the operating menus of the local display and the Endress+Hauser FieldCare or DeviceCare operating tools can be summarized as follows: The local display is suitable for configuring simple applications. -
Page 28: Operation Via Bluetooth® Wireless Technology (Optional)
Prerequisite • Device with device display including Bluetooth • Smartphone or tablet with Endress+Hauser SmartBlue app or PC with DeviceCare from version 1.07.05 or FieldXpert SMT70 The connection has a range of up to 25 m (82 ft). The range can vary depending on environmental conditions such as attachments, walls or ceilings. -
Page 29: Access To The Operating Menu Via The Operating Tool
Access via the operating tool is possible: • Via HART communication, e.g. Commubox FXA195 • Via Endress+Hauser Commubox FXA291 With the Commubox FXA291, a CDI connection can be established with the device interface and a Windows PC/notebook with a USB port... -
Page 30: Device Variables And Measured Values
Commissioning Liquiphant FTL51B HART Device variable Measured value Tertiary variable (TV) parameter (Third variable) Fork state Quaternary variable (QV) parameter (Quaternary variable) Sensor temperature Primary variable (PV) parameter is always applied to the current output. Level limit detection is the initial state depending on the fork state (uncovered/covered) and the safety... -
Page 31: As-Delivered State
Liquiphant FTL51B HART Commissioning 9.1.1 As-delivered state If no customized settings were ordered: • Assign PV parameter Level limit detection (8/16 mA mode) • MAX safety mode • Alarm condition set to min. 3.6 mA • DIP switch for locking in OFF position •... -
Page 32: Fieldcare/Devicecare Via Service Interface (Cdi)
A0039148 Computer with FieldCare/DeviceCare operating tool Commubox FXA291 Service interface (CDI) of the device (= Endress+Hauser Common Data Interface) At least 22 mA is required to update (flash) the device firmware. Configuring the device address via software See HART address parameter. -
Page 33: Device Configuration
Liquiphant FTL51B HART Commissioning A0046404 Click "Settings" and select the desired language: A0046406 Setting the language for the local display via DeviceCare Navigation: System → Display → Language ‣ Set the desired language in the Language parameter. Device configuration 9.7.1... -
Page 34: Resetting The Password Or Device Via Operating Keys
In the Simulation submenu the user can simulate with the options Fork state (uncovered/ covered), Sensor frequency, Current output and Diagnostic event simulation. DeviceCare is available for download at www.software-products.endress.com. You must register in the Endress+Hauser software portal to download the product. -
Page 35: Protecting Settings From Unauthorized Access
Liquiphant FTL51B HART Commissioning Navigation: Diagnostics → Simulation → Simulation Protecting settings from unauthorized access 9.9.1 Locking or unlocking the hardware Display A0046569 25 Functions of the DIP switches on the electronic insert DIP switch for safety function, software-defined (SW, default=MAX) or set permanently to MIN DIP switch for locking and unlocking the device (hardware) DIP switch (2) on the electronic insert is used to lock or unlock operation. -
Page 36: Operation
Operation Liquiphant FTL51B HART Parameter configuration (Operator user role): Parameter configuration of the device is locked in the Operator user role. Unlocking access: Access to parameter configuration can be unlocked by entering the password. The user role changes back to Maintenance. -
Page 37: Sensor Frequency
The Heartbeat submenu is only available when operating via FieldCare, DeviceCare or the SmartBlue app. It contains the wizards that are provided with the Heartbeat Verification and Heartbeat Monitoring application packages. Documentation on the Heartbeat Technology: Endress+Hauser website: www.endress.com → Downloads. -
Page 38: Proof Testing For Sil/Whg Devices (Optional)
Diagnostics and troubleshooting Liquiphant FTL51B HART 10.5 Proof testing for SIL/WHG devices (optional) The "Proof test" module contains the Proof test wizard, which must be performed at appropriate intervals in the following applications: SIL (IEC61508), WHG (German Water Resources Act (Gesetz zur Ordnung des Wasserhaushalts)): •... -
Page 39: Error - Smartblue Operation With Bluetooth
Liquiphant FTL51B HART Diagnostics and troubleshooting Communication via CDI interface not working Possible cause: Wrong setting of the COM port on the computer Remedial action: Check the setting of the COM port on the computer and correct it if necessary... -
Page 40: Additional Tests
Diagnostics and troubleshooting Liquiphant FTL51B HART Connection via SmartBlue not possible Possible cause: Incorrect password entered Remedial action: Enter the correct password, paying attention to lower/upper case Connection via SmartBlue not possible Possible cause: Forgotten password Remedial action: Use the operating key on the electronic insert to reset the password or contact Endress+Hauser Service (www.addresses.endress.com) - Page 41 Liquiphant FTL51B HART Diagnostics and troubleshooting Status signals "Failure (F)" option A device error has occurred. The measured value is no longer valid. "Function check (C)" option The device is in the service mode (e.g. during a simulation). "Out of specification (S)" option The device is being operated: •...
-
Page 42: Diagnostic Event In The Operating Tool
Diagnostics and troubleshooting Liquiphant FTL51B HART 11.3 Diagnostic event in the operating tool If there is a diagnostic event in the device, the status signal appears on the top left in the status section of the operating tool together with the associated icon for event behavior according to NAMUR NE 107: •... - Page 43 Liquiphant FTL51B HART Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Diagnostic of electronic Electronics faulty 1. Restart device Alarm 2. Replace electronics HART Device Malfunction Check device specific diagnosis.
-
Page 44: Event Logbook
Diagnostics and troubleshooting Liquiphant FTL51B HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Diagnostic event Deactivate simulation Warning simulation active Configuration Sensor Unit 1. Check sensor configuration Warning invalid 2. Check device configuration... -
Page 45: Filtering The Event Logbook
Liquiphant FTL51B HART Diagnostics and troubleshooting In addition to the operating time when the event occurred, each event is also assigned a symbol that indicates whether the event has occurred or is finished: • Diagnostic event • : Occurrence of the event •... -
Page 46: Resetting The Device
Diagnostics and troubleshooting Liquiphant FTL51B HART Info number Info name I1513 Download finished I1514 Upload started I1515 Upload finished I1551 Assignment error fixed I1552 Failed: Main electronic verification I1554 Safety sequence started I1555 Safety sequence confirmed I1556 Safety mode off... -
Page 47: 11.10 Firmware History
Sterilization in Place Repair 13.1 General notes 13.1.1 Repair concept Endress+Hauser repair concept • The devices have a modular design • Customers can carry out repairs For more information on service and spare parts, please contact your Endress+Hauser sales representative. Endress+Hauser... -
Page 48: Repair Of Ex-Certified Devices
WARNING Incorrect repair can affect electrical safety! Explosion Hazard! ‣ Only specialist personnel or the Endress+Hauser service team may carry out repairs on Ex-certified devices. ‣ Relevant standards and national regulations on hazardous areas, safety instructions and certificates must be observed. -
Page 49: Disposal
(WEEE), the product is marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Do not dispose of products bearing this marking as unsorted municipal waste. Instead, return them to Endress+Hauser for disposal under the applicable conditions. -
Page 50: Plug-In Jack
Accessories Liquiphant FTL51B HART 115 (4.53) 140 (5.51) 32 (1.26) A0038280 28 Weather protection cover for single compartment housing, aluminum. Unit of measurement mm (in) 14.4 Plug-in jack The plug-in jacks listed are suitable for use in the temperature range –25 to +70 °C (–13 to +158 °F). -
Page 51: Sliding Sleeves For Unpressurized Operation
• Weight: 0.54 kg (1.19 lb) • Order number: 52003981 • Order number: 52011891, approval: with inspection certificate EN 10204 - 3.1 material More detailed information and documentation are available: • Product Configurator on the Endress+Hauser website www.endress.com • Endress+Hauser sales organization www.addresses.endress.com 14.6... - Page 52 Accessories Liquiphant FTL51B HART 60 (2.36) 60 (2.36) G 1 A G 1½A (1 NPT) (1½ NPT) A0037667 32 High pressure sliding sleeves. Unit of measurement mm (in) G 1, DIN ISO 228/I • Material: 1.4435 (AISI 316L) • Weight: 1.13 kg (2.49 lb) •...
-
Page 53: Technical Data
• Weight: 1.32 kg (2.91 lb) • Approval: with inspection certificate EN 10204 - 3.1 material • Order number: 71118695 More detailed information and documentation are available: • Product Configurator on the Endress+Hauser website www.endress.com • Endress+Hauser sales organization www.addresses.endress.com Technical data 15.1... -
Page 54: Load
Ex connection data See safety instructions (XA): All data relating to explosion protection are provided in separate Ex documentation and are available from the Downloads Area of the Endress+Hauser-website. The Ex documentation is supplied as standard with all Ex devices. Endress+Hauser... -
Page 55: Protocol-Specific Data
Liquiphant FTL51B HART Technical data 15.2.7 Protocol-specific data HART • Manufacturer ID: 17 (0x11) • Device type code: 0x11C4 • Device revision: 1 • HART specification: 7 • DD revision: 1 • Device description files (DTM, DD) information and files at: •... -
Page 56: Heartbeat Technology
Technical data Liquiphant FTL51B HART 15.2.9 Heartbeat Technology Heartbeat Technology module The software package consists of 3 modules. These three modules combined check, evaluate and monitor device functionality and process conditions. • Heartbeat Diagnostics • Heartbeat Verification • Heartbeat Monitoring 15.3... -
Page 57: Storage Temperature
Liquiphant FTL51B HART Technical data 15.3.2 Storage temperature –40 to +80 °C (–40 to +176 °F) Optional –50 °C (–58 °F) or –60 °C (–76 °F) With M12 plug, elbowed: –25 to +80 °C (–13 to +176 °F) 15.3.3 Humidity Operation up to 100 %. -
Page 58: 15.3.10 Pollution Degree
Technical data Liquiphant FTL51B HART 15.3.10 Pollution degree Pollution level 2 15.3.11 Electromagnetic compatibility (EMC) • Electromagnetic compatibility as per EN 61326 series and NAMUR recommendation EMC (NE21) • With regard to the safety function (SIL), the requirements of EN 61326-3-x are satisfied •... -
Page 59: Overpressure Limit
Liquiphant FTL51B HART Technical data Process pressure range of the sensors [psi] [bar] 1450 +150 [°C] +302 [°F] A0038268 Permitted pressure rating when the "100 bar (1 450 psi)" option is selected. For exceptions, see the "Process connections" section. Canadian CRN approval: The maximum permitted process pressure is limited to 90 bar (1 305 psi) only in combination with the CRN approval. -
Page 60: Pressure Tightness
Technical data Liquiphant FTL51B HART 15.4.8 Pressure tightness Up to vacuum In vacuum evaporation plants, select the 0.4 g/cm density setting. 15.4.9 Solids contents ⌀ ≤ 5 mm (0.2 in) 15.5 Additional technical data Current Technical Information: Endress+Hauser website: www.endress.com → Downloads. Endress+Hauser... -
Page 61: Index
Liquiphant FTL51B HART Index Index About this document Mounting requirements Symbols - description ..... . . 6 Switch point ......12 Access authorization to parameters Read access . - Page 64 *71548519* 71548519 www.addresses.endress.com...
