Page 1: Hedge Trimmer
SHINDAIWA OWNER’S/OPERATOR'S MANUAL AHS242 ARTICULATED HEDGE TRIMMER X7502801200 06/10 WARNING! Always wear eye and ear protection when operating this machine! To minimize the risk of injury to yourself and others, read this manual and familiarize yourself with its contents. -
Page 2: Table Of Contents
If you have questions regarding your power tool, or if you do not understand something in this manual, your Shindaiwa dealer will be glad to assist you. You may also contact Shindaiwa at the address printed on the back of this Manual. -
Page 3: Safety
10 meters away from electrical lines or branches that contact electrical lines. An articulated hedge trimmer has the potential to cause seri- ous personal injury to the operator or bystanders if misused, abused or mishandled. To reduce the risk of injury, you must maintain control at all times, and observe all safety precau- tions during operation. - Page 4 Operating Precautions ■ Never transport the articulated hedge trimmer or leave it unat- tended with the engine running. An engine that’s running could be accidently accelerated causing the blades to oscillate. ■ Make sure that the blade cover is in place when transporting or storing the articulated hedge trimmer.
-
Page 5: Safety Equipment And Labels
Cutter Blade Cover IMPORTANT! Caution, Danger, Warning, and Operation Information Labels: Make sure all informa- tion labels are undamaged and readable. Immediately replace damaged or missing information labels. New labels are available from your local authorized Shindaiwa dealer. -
Page 6: Product Description
Fuel Tank Guard ThrottleTrigger Powerhead Assembly Using the illustration as a Handle guide, familiarize yourself with the Shindaiwa AHS242 articulated hedge trimmer and its various components. Understanding your machine helps ensure top perfor- mance, longer service life, and safer operation. -
Page 7: Specifications
Specifications Model Engine type Dimensions (L x W x H) Weight Bore x stroke Displacement Fuel/oil ratio Carburetor type Fuel tank capacity Ignition Spark plug Electrode Gap Torque Air cleaner type Starting method Stopping method Transmission type Cooling System Blade Length Cutter Drive Gear Lubricant Idle Speed... -
Page 8: Assembly
Do not touch the cutter blades when the engine is running. The blades can oscillate even if the engine is idling. Position the hedge trimmer on a flat, level surface. With your right hand, grasp the outer tube near the handle. With your left hand, grip the adjustment lever on the cutter assembly. - Page 9 Travel limiter and adjustment range NOTE: This articulated hedge trimmer is equipped with a travel limiter that pre- vents the cutter assembly from rotating outside of the 90°- 225° range. The cutter assembly can be adjusted to 10 different positions ranging from 90°...
-
Page 10: Mixing Fuel
2 Stroke Mixture Oil - A 2-stroke engine oil meeting ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345/FD standards must be used. Shindaiwa One formulated for use in all Shindaiwa 2-stroke engines. Engine problems due to inadequate lubrication caused by fail- ure to use an ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345/FD certified oil will void the engine warranty. -
Page 11: Filling The Fuel Tank
Mixing Instructions 1. Fill an approved fuel container with half of the required amount of gasoline. 2. Add the proper amount of engine oil to gasoline. 3. Close container and shake to mix oil with gaso- line. 4. Add remaining gasoline, close fuel container, and remix. - Page 12 Starting the Engine (continued) Slide the ignition switch to the “ON” position. Press the primer bulb until fuel can be seen flowing in the transparent return tube. IMPORTANT! The primer system only pushes fuel through the carburetor. Repeatedly pressing the primer bulb will not flood the engine with fuel.
-
Page 13: Stopping The Engine
Checking Unit Condition NEVER operate the unit with the pro- tective devices removed! Use only authorized Shindaiwa parts and accessories with your Shindaiwa hedge trimmer. Do not make modifica- tions to this unit without written approv- al from Shindaiwa. -
Page 14: Safe Operation
PERFORMANCE AND DURABILITY TO AUTHORIZED PARTS MAY IMPAIR THE EFFECTIVENESS OF THE EMISSION CONTROL SYSTEM AND MAY HAVE A BEARING ON THE OUTCOME OF A WARRANTY CLAIM. Using non-standard replacement parts could invalidate your Shindaiwa warranty. WARNING! Before performing any mainte-... -
Page 15: Daily Maintenance
CAUTION! Operating the trimmer with worn or improperly adjusted cutters will reduce cutter performance and may also damage your machine. Never operate the machine with damaged or worn cutters. - Page 16 Maintenance (continued) 10-Hour maintenance (more frequently in dusty conditions) Remove the air cleaner cover by loosening the cover screw(s) and lifting. Remove the air cleaner element. ■ In dusty applications the filter should be gently blown out with compressed air daily or 2 to 3 times per week.
- Page 17 Use a hooked wire to extract the fuel filter from inside the fuel tank. Inspect the fuel filter element. If it shows signs of contamination, replace with a genuine Shindaiwa replacement fuel filter element. CAUTION! Make sure you do not pierce the fuel line with the end of the hooked wire.
- Page 18 Gently tap the muffler on a wood surface to dislodge any loose car- bon. Reassemble the spark arrester, muf- fler and engine cover in the reverse order of disassembly. IMPORTANT! If you note excessive carbon buildup, con- sult with an authorized Shindaiwa servicing dealer. Screws...
-
Page 19: Long Term Storage
1,100 feet above sea level (ASL) (96.0 kPa). To maintain proper engine operation and emission compliance above 1,100 feet ASL the carburetor may need to be adjusted by an authorized Shindaiwa service dealer. If the engine is adjusted for operation above 1,100 feet ASL, the carburetor must be re-adjusted when operating the engine below 1,100 feet ASL, otherwise severe engine damage may result. -
Page 20: Troubleshooting Guide
89 or higher mixed with an air cooled engine oil that meets or exceeds ISO-L-EGD and/or JASO FD classifi ed oils at 50:1 gasoline/oil ratio. ENGINE DOES NOT START Possible Cause Consult with an authorized Shindaiwa servicing dealer. Faulty recoil starter. Fluid in the crankcase. Internal damage. Tighten and re-test. - Page 21 89 or higher mixed with an air cooled engine oil that meets or exceeds ISO-L-EGD and/or JASO FD classifi ed oils at 50:1 gasoline/oil ratio. Consult with an authorized Shindaiwa servicing dealer. Consult with an authorized Shindaiwa servicing dealer.
- Page 22 Restart. Idle engine until cool. Adjust idle. Check Specifi cations page for correct idle speed. Consult with an authorized Shindaiwa servicing dealer. Adjust idle. Check Specifi cations page for correct idle speed.
-
Page 23: Warranty Statement
The owner shall demonstrate reasonable care and use, and follow preventative maintenance, storage, fuel and oil usage as pre- scribed in the operator’s manual. Should a product diffi culty occur, you must, at your expense, deliver or ship your Shindaiwa unit to an authorized Shindaiwa servicing dealer for warranty repairs (within the applicable warranty period), and arrange for pick-up or return of your unit after the repairs have been made. - Page 24 89 octane or higher. Gasohol which contains a maximum 10% ethanol (grain alcohol) or 15% MTBE (methyl/tertiary/butyl/ether) is also approved. The prescribed mixing ratio of gasoline to oil is listed on the Shindaiwa oil label and covered in your operator’s manual.
- Page 25 Authorized Dealer within 100 miles, ECHO Inc. will pay to ship the unit to the nearest authorized dealer. If you have questions regarding your warranty coverage, you should contact ECHO Inc. at 1-800-673-1558, web site WWW.ECHO-USA.COM or contact Shindaiwa at 1-877-986- 7783, web site WWW.SHINDAIWA.COM.
- Page 26 NOTES...
- Page 27 NOTES...
-
Page 28: Servicing Information
Genuine Shindaiwa Parts and Assemblies for your Shindaiwa products are available only from an Authorized Shindaiwa Dealer. When you do need to buy parts always have the Model Number, Type and Serial Number of the unit with you. You can find these numbers on the engine. For future reference, write them in the space provided below.
