E202005 Lennox Industries Inc.
Dallas, Texas, USA
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
The O23V series unit must be serviced annually.
All service must be performed by a qualified profes-
sional service technician, or equivalent.
O23V SERIES UNITS ARE NOT FOR USE IN
ZONING APPLICATIONS!
General
These instructions are intended as a general guide and do
not supersede local codes in any way. Only licensed pro-
fessional technicians, or equivalent, can install and service
the Dave Lennox Signaturet Collection O23V oil fur-
naces. In Canada, refer to CSA B139 for recommended
installation procedures. Consult authorities who have juris-
diction before installation.
Shipping & Packing List
1 − Assembled oil furnace
1 − Barometric draft control
1 − Side exhaust pipe collar
1 − Direct intake collar (AFII burner units only)
Check the components for shipping damage. If you find
any damage, immediately contact the last carrier.
03/10
*2P0310*
Downloaded from
ManualsNet.com
IMPORTANT
search engine
INSTALLATION
INSTRUCTIONS
O23V Series Units
OIL UNITS
505,082M
38152A070
03/2010
Supersedes 10/2005
