Page 1 SyncMaster P50HP, P50HP-2, P63FP, P63FP-2 PDP Display User Manual The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance.
Page 2: Safety Instructions
Safety Instructions Notational Note These safety instructions must be followed to ensure your safety and prevent property dam- age. Make sure to read the instructions carefully and use the product in the correct manner. Warning / Caution Failure to follow directions noted by this symbol could result in bodily harm or damage to the equipment.
Page 3: Installation
Ensure that the power plug is plugged into the power outlet firmly and correctly. • Do not forcefully bend or pull the power plug and do not place any heavy material on it. • Do not connect multiple appliances to the same power outlet. •...
Page 4 Keep heating appliances as far away from the power cord or the product as possible. • Do not install it in a badly ventilated location such as a bookcase or closet. • When putting the product down, make sure to put it down softly. •...
Page 5 When cleaning the power plug pins or dusting the power outlet, clean it with a dry cloth. • When cleaning the product, make sure to disconnect the power cord. • When cleaning the product, disconnect the power cord and clean it with a soft, dry cloth. •...
Page 6 If thunder or lightning is occurring, do not touch the power cord or antenna cable. • Otherwise, this may result in electric shock or fire. Do not try to move the monitor by pulling only the wire or the signal cable. •...
Page 7 To avoid eyestrain, do not sit too close to the product. Take a rest for at least five (5) minutes after using the monitor for one (1) hour. • This reduces eye fatigue. Do not install it in an unstable location such as an unstable rack or uneven surface or a location exposed to vibrations.
Page 8 The batteries (and rechargeable batteries) are not ordinary re- fuse and must be returned for recycling purposes. The customer is responsible for returning the used or rechargeable batteries for recycling. • The customer can return used or rechargeable batteries to a nearby public recycling center or to a store selling the same type of the battery or rechargeable battery.
Page 9 Safety Instructions Do not put any heavy objects on the product. • This may result in personal injury and/or damage to the prod- uct.
Page 10: Checking The Contents Of The Package
Introduction Package Contents Note Please make sure the following items are included with your PDP Display. If any items are missing, contact your dealer. Contact a local dealer to buy optional items. Checking the Contents of the Package Remove the lock from the package box, as shown in the figure above. Lift up the package box by holding the grooves on both sides of the package...
Page 11 Manuals Quick Setup Guide (Not available in all loca- Cables Power Cord Others Remote Control Batteries (AAA X 2) (Not available in all loca- Sold separately DVI Cable Network Box RGB to BNC Cable Ferrite Core • The ferrite cores are used to shield the cables from interfer- ence.
Page 12 Your PDP Display Note The PDP device may interfere with an amateur radio or AM radio. Front SOURCE button [SOURCE] Switches from PC mode to Video mode. Changing the source is only al- lowed for external devices that are connected to the PDP Display at the time.
Page 13 Note See PowerSaver described in the manual for further information regarding power saving functions. For energy conservation, turn your PDP Display OFF when it is not needed or when leaving it unattended for long periods. Remote Control Sensor Aim the remote control towards this spot on the PDP Display. Rear Note For detailed information concerning cable connections, refer to Connecting Cables under...
Page 14 RS232C OUT/IN (RS232C Serial PORT) MDC(Multiple Display Control) Program Port RGB IN (PC Connection Terminal (In- put)) • Use a D-Sub Cable (15 pin D-Sub) - PC mode (Analog PC) • Connect the RGB IN port on the monitor to the BNC port on the PC using the RGB to BNC cable.
Page 15 AV IN [VIDEO] Connect the AV IN [VIDEO] terminal of your monitor to the video output terminal of the external device using a VIDEO cable. AUDIO OUT Headphone/External speaker output termi- nal. HDMI IN Connect the HDMI terminal at the back of your PDP Display to the HDMI terminal of your digital output device using a HDMI ca- ble.
Page 16: Remote Control
Note See Connecting Cables for further information regarding cable connections. Remote Control Note The performance of the remote control may be affected by a TV or other electronic device operating near the PDP Display , causing a malfunction due to interference with the frequen- Kensington Lock The Kensington Lock is a device used to physically fix the system when using it in a...
Page 17 POWER 3. Number Buttons 4. DEL / GUIDE but- 5. - VOL + SOURCE D.MENU 8. TOOLS POWER Number Buttons / GUIDE button - VOL + SOURCE D.MENU TOOLS Up-Down Left-Right buttons INFO COLOR BUTTONS TTX/MIX MTS/DUAL ENTER/PRE-CH MUTE CH/P MENU RETURN EXIT...
Page 18 9. Up-Down Left-Right but- tons INFO 11. COLOR BUTTONS TTX/MIX 13. MTS/DUAL ENTER/PRE-CH MUTE CH/P 17. TV 18. MENU RETURN Moves from one menu item to another horizontally, vertically or adjusts selected menu values. Current picture information is displayed on the upper left corner of the screen.
Page 19: Installation Vesa Bracket
When installing VESA, make sure to comply with the international VESA standards. • Purchasing VESA Bracket and Installation Information : Please contact your nearest SAMSUNG Distributor to place an order. After your order is placed, installation profes- sionals will visit you and install the bracket. Exits from the menu screen.
Page 20: Wall Bracket Installation
• At least 2 persons are needed in order to move the PDP Display. • SAMSUNG is not responsible for any product damage or any injury caused by installation at customer's discretion. Dimensions Notice For securing the bracket on a wall, use only machine screws of 6 mm diameter and 8 to 12 mm length.
Page 21: Wall Bracket Assembly
Wall Bracket Assembly Note There are two hinges(left and right). Use the correct one. Insert and tighten the Captive Screw in the direction of the arrow. When done, mount the wall bracket on the wall. Before drilling into the wall, check if the length between the two locking holes at the back of the product is correct.
Page 22: To Mount The Product On The Wall Bracket
of the brackets and hinge holes to the corresponding anchor holes and insert and tighten the 11 screws A. To mount the product on the wall bracket The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same) Remove the 4 screws on the back of the product.
Page 23: Wall Bracket Angle Adjustment
Remove safety pin (3) and insert the 4 product holders into the corresponding bracket holes (1). Then place the product(2) so that it is firmly fixed to the bracket. Make sure to re-insert and tighten the safety pin (3) to securely hold the product to the bracket. Wall Bracket Angle Adjustment Adjust the bracket angle to -2°...
Page 24 Make sure to use the top center, and not the left or the right side of the product to adjust the angle. Mechanical Layout(P63FP, P63FP-2) Mechanical Layout PDP Display Head Installation VESA Bracket • When installing VESA, make sure to comply with the international VESA standards.
Page 25 • At least 2 persons are needed in order to move the PDP Display. • SAMSUNG is not responsible for any product damage or any injury caused by installation at customer's discretion. Dimensions Notice For securing the bracket on a wall, use only machine screws of 6 mm diameter and 8 to 12 mm length.
Page 26 Wall Bracket Assembly Note There are two hinges(left and right). Use the correct one. Insert and tighten the Captive Screw in the direction of the arrow. When done, mount the wall bracket on the wall. Before drilling into the wall, check if the length between the two locking holes at the back of the product is correct.
Page 27 of the brackets and hinge holes to the corresponding anchor holes and insert and tighten the 11 screws A. To mount the product on the wall bracket The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same) Remove the 4 screws on the back of the product.
Page 28 Remove safety pin (3) and insert the 4 product holders into the corresponding bracket holes (1). Then place the product(2) so that it is firmly fixed to the bracket. Make sure to re-insert and tighten the safety pin (3) to securely hold the product to the bracket. Wall Bracket Angle Adjustment Adjust the bracket angle to -2°...
Page 29 Introduction Make sure to use the top center, and not the left or the right side of the product to adjust the angle.
Page 30: Connecting A Computer
Connections Connecting a Computer There are several ways to connect the computer to the monitor. Choose one from the following options. Using the D-sub (Analog) connector on the video card. • Connect the D-sub to the 15-pin, [RGB IN] port on the back of your PDP Display and the 15 pin D-sub Port on the computer.
Page 31 Using the HDMI (digital) output on the graphics card. • Connect the [HDMI IN] port on the PDP Display to the HDMI port on the PC using the HDMI cable. Note When the HDMI cable to the PC, ensure that you select HDMI from both the Source List and Edit Name before selecting PC or DVI device so that normal PC screen and sound can be outputted.
Page 32: Connecting To Other Devices
• Turn on both your computer and the PDP Display. • Contact a local SAMSUNG Electronics Service Center to buy optional items. Connecting to Other devices • AV input devices such as DVD players, VCRs or camcorders as well as your computer can be connected to the PDP Display.
Page 33: Connecting To A Camcorder
Connect an audio cable to the audio output port on the external device and [AV/COM- PONENT AUDIO IN[R-AUDIO-L]] port on the monitor, and connect the video output port on the external device to the [AV IN [VIDEO]] port on the monitor. Play the DVD, VCR or Camcorder with a DVD disc or tape inserted.
Page 34: Connecting The Bnc To Bnc Cable
Connecting the BNC to BNC cable Connect the [BNC/COMPONENT IN [R/P port on the external device using the BNC to BNC cable. Select BNC using the SOURCE button on the front of the PDP Display or on the remote control. Connecting Using a DVI Cable Connect between the [DVI OUT] port on the PDP Display and the input port on another monitor using a DVI cable.
Page 35: Connecting Using A Hdmi Cable
Connecting Using a HDMI Cable Connect input devices such as a Blu-Ray/DVD player to the [HDMI IN] terminal of the PDP Display using an HDMI cable. Select HDMI using the SOURCE button on the front of the PDP Display or on the remote control.
Page 36: Connecting A Dvd Player
Connect the red and white jacks of an RCA to stereo (for PC) cable to the same colored audio output terminals of the digital output device, and connect the opposite jack to the [DVI / RGB AUDIO IN] terminal of the PDP Display. Select HDMI using the SOURCE button on the front of the PDP Display or on the remote control.
Page 37: Connecting A Dtv Set Top (Cable/Satellite) Box
Connecting a DTV Set Top (Cable/Satellite) Box Connect a Component cable between the [BNC/COMPONENT IN [R/P port on the PDP Display and the P Connect a set of audio cables between the [AV COMPONENT AUDIO IN [R-AUDIO-L]] on the PDP Display and the AUDIO OUT jacks on the Set Top Box. Note •...
Page 38: Using The Software
Using the Software Installation Insert the installation CD into the CD-ROM drive. Click the Serial MDC installation program. Note If the screen for installing the software does not appear, install it using the Serial MDC execution file in the MDC folder of the CD-ROM. If the installation wizard screen does appear, click "Next."...
Page 39: Installation Problems
Installation Problems The installation of MDC can be affected by such factors as the video card, motherboard and the network environment. Uninstall The MDC program can be removed only by using the "Add or Remove Programs" option of ® the Windows Control Panel.
Page 40: Main Screen
Therefore, a serial cable should be connected between the serial port on a PC and the serial port on a display. Main Screen Click Start > Program > Samsung > MDC System to start the program. Select a set to see the volume of the selected set within the slider.
Page 41 Main Icons Remote control Safety Lock Port Selection Lamp Control Option... Dropdown Selectors Use the main icons to switch into each screen. Allows you to enable or disable the remote control signal receiving function of the display unit. Set the Safety Lock function. When setting the Lock function, you can only operate power and lock buttons on the remote control and set.
Page 42: Port Selection
14. Switches the OSD function On/Off. - May not be supported depending on the product. <Note> The remote control Enable/Disable function operates whether or not the power is On/Off, and this applies to all displays connected to the MDC. However, regardless of the status at the time the MDC is shut down, the remote control signal receiving function of all displays is initialized to Enable when the MDC is closed.
Page 43 Info Grid shows some basic information necessary to Power Control. (Power Status) 2) Input 3) Image Size 4) On Timer 5) Off Timer 2. Selects displays you want to adjust using the Select button or checkboxes.
Page 44 Power Control allows controlling some of the functions of the selected display. 1) Power On/Off - Turns the power of the selected display On/Off. 2) Volume - Controls the volume level of the selected display. It receives the volume value of the selected display from the sets and displays it in the slider. (If you deselect a single display or all displays, the default value 10 will be restored.) (Mute On/Off) - Turns on/off the Mute function of the selected display.
Page 45: Input Source
1) Source OSD - Sets whether the Source OSD will be displayed to indicate when the Source is changed. 2) Not Optimum Mode OSD - Sets whether the Optimum Mode OSD will be displayed to indicate if the current mode is not supported. 3) No Signal OSD - Sets whether the No Signal OSD will be displayed to indicate when there is no signal.
Page 46 • PC Mode Info Grid shows some basic information necessary to Input Source Control.
Page 47: Image Size
- Changes the Input Source of the selected display to PC. - Changes the Input Source of the selected display to BNC. - Changes the Input Source of the selected display to DVI. - Changes the Input Source of the selected display to TV. - Changes the Input Source of the selected display to DTV.
Page 48 Info Grid shows some basic information necessary to Image Size Control. ( Power Status) - Shows the power status of the current display. 2) Image Size - Shows the current Image Size of the display in use. 3) Input - Info Grid displays only the displays whose Input Source is PC, BNC, DVI and DP. 4) PC Source - Click Image Size in the main menu to display the PC, BNC, DVI and DP tabs.
Page 49 Info Grid shows some basic information necessary to Image Size Control. 1) To adjust Image Size in TV, AV, S-Video, Component, HDMI1, HDMI2 or DTV mode, click the Video Source tab. Select the display you want to adjust by using the Select button or by checking the checkbox. 2) Info Grid displays only the display having TV, AV, S-Video, Component, HDMI1, HDMI2 or DTV as input source.
Page 50 Info Grid shows some basic information necessary to Time Control. 1) Set clock - Set the current time for the selected display (PC Time). - To change the current time, first change the PC Time. 2) Timer - Sets up Timer1, Timer2, Timer3 and Holiday Management. 3) Shows whether Timer is activated.
Page 51 1) On Time - Sets the time in hours, in minutes and as AM/PM for turning the selected monitor on. 2) Off Time - Sets the time in hours, in minutes and as AM/PM for turning the selected monitor off. 3) Volume - Selects the volume when the selected monitor is turned on.
Page 52: Pip Size
1) Specifies the date. 2) Delete All - Deletes all of the holidays. 3) Add - Adds the specified date. - Deletes the schedule in the selected line. The Holiday Management function can be turned on or off in the Timer setup menu. The Input source of MagicInfo works only on MagicInfo model.
Page 53: Pip Source
Info Grid shows some basic information necessary to PIP Size Control. 1) PIP Size - Shows the current PIP Size of the display in use. 2) OFF - Turns off the PIP of the selected display. 3) Large - Turns on the PIP of the selected display and changes the size to Large. 4) Small - Turns on the PIP of the selected display and changes the size to Small.
Page 54 Info Grid shows some basic information necessary to PIP Source Control. 1) PIP Source - PIP Source can be controlled with turning on the LCD Display power. 2) PC - Changes the source of the PIP of the selected display to PC. 3) BNC - Changes the source of the PIP of the selected display to BNC.
Page 55 Settings Picture 1. Click Settings of the main icons and the Settings Control screen appears. Basic information required to adjust the Picture is displayed in the main menu. Settings for the selected monitor will be displayed if one of the connected monitors is selected, and the default settings will be displayed if all monitors are selected by clicking All and Select.
Page 56 - Adjusts the Color Temp for the selected display. 9) Brightness Sensor - Adjusts the Brightness Sensor for the selected display. 10) Dynamic Contrast - Adjusts the Dynamic Contrast for the selected display. HDMI2 may not be supported depending on the product. Brightness Sensor may not be supported depending on the product.
Page 57 3) Brightness - Adjusts Brightness for the selected display. 4) Red - Adjusts red Color of the selected display. - Available only for NT. 5) Green - Adjusts green Color of the selected display. - Available only for NT. 6) Blue - Adjusts blue Color of the selected display.
Page 58: Image Lock
Basic information required to adjust Audio is displayed in the display window. Settings for the corresponding SET will be imported and displayed on the slider if a display ID is selected, and the default settings will be displayed if all display IDs are selected by clicking All and Select.
Page 59: Maintenance
Info Grid shows some basic information necessary to Settings Control. 1) Image Lock - Available only for PC, BNC. 2) Coarse - Adjusts Coarse of the selected display. 3) Fine - Adjusts Fine of the selected display. 4) Position - Adjusts Position of the selected display. 5) Auto Adjustment - Self-Adjust to the incoming PC signal.
Page 60 An "Info Grid" showing several basic data items appears. 1) Maintenance - Allows the Maintenance Control function for all input sources. 2) Lamp Control - Automatically adjusts the backlight of the selected display at a specified time. The Manual Lamp Control automatically turns off if you adjust using the Auto Lamp Control. - Allows you to adjust the backlight of the selected display regardless of the time.
Page 61: Video Wall
1) Scroll - This function is used to remove the afterimages that occur when a still screen is displayed on the selected display for a long time. 2) Pixel Shift - This allows the screen to be moved finely at the specified time interval. 3) Safety Screen - The Safety Screen function is used to prevent afterimages from occurring when a still screen is displayed on the monitor for a long time.
Page 62 1) Video Wall - A Video Wall is a set of video screens that are connected together, so that each screen shows a part of the whole picture or so that the same picture is repeated on each screen. 2) Video Wall Control - Video Wall properties can be configured.
Page 63 1) On / Off - Turns on/off the Video Wall function of the selected display. 2) Format - The format can be selected to see a divided screen. Full Natural 3) Video Wall (Screen divider) - The screen can be divided into. You can select a number of screens with a different layout when dividing.
Page 64: Troubleshooting
The Input source of TV works only on TV model. The Maintenance Control function is available only for the displays where the power status is ON. Troubleshooting 1. The display you wish to control does not appear on the Power Control Info Grid - Check the connection of RS232C.
Page 65 Adjusting the PDP Display Input Available Modes • PC / DVI / BNC • • HDMI • MagicInfo • Component Note • MagicInfo can only be enabled when a network box is connected. • The HDMI port and network box cannot be connected at the same time. Source List MENU →...
Page 66 Name the input device connected to the input jacks to make your input source selection easier. VCR / DVD / Cable STB / HD STB / Satellite STB / AV Receiver / DVD Receiver / Game / Camcorder / DVD Combo / DHR / PC Note •...
Page 67 MagicBright is a new feature providing the optimum viewing environment depending on the contents of the image you are watching. Currently four different modes are available: Enter- tain, Internet, Text and Custom. Each mode has its own pre-configured brightness value. You can easily select one of the four settings by simply pressing the MagicBright control button.
Page 68 Brightness MENU → → ENTER → → , Adjusts the Brightness. Sharpness MENU → → ENTER → → , → ENTER Adjusts the Sharpness. Color Tone MENU → → ENTER → The color tones can be changed. Cool Normal Warm Custom Note If you set the Color Tone to Cool, Normal, Warm, or Custom, the Color Temp function is...
Page 69 Note If you adjust the picture by using the Color Control function, Color Tone will turn to the Cus- tom mode. MENU → → ENTER → → , → ENTER → Green MENU → → ENTER → ENTER→ → , Blue MENU →...
Page 70 Removes noise such as vertical stripes. Coarse adjustment may move the screen image area. You may relocate it to the center using the horizontal control menu. Fine MENU → → ENTER → ENTER → → , Removes noise such as horizontal stripes. If the noise persists even after Fine tuning, repeat it after adjusting the frequency (clock speed).
Page 71 Selects either On or Off with the signal Balance. Signal Control MENU → → ENTER → → → ENTER → R-Gain MENU → → ENTER → ENTER G-Gain MENU → → ENTER → → ENTER B-Gain MENU → → ENTER → →...
Page 72 B-Offset MENU → → ENTER → → , → Size MENU → → ENTER → → ENTER The Size can be switched. 16:9 Picture [ AV / HDMI / Component Mode] Available Modes • PC / DVI / BNC • •...
Page 73 The PDP Display has four automatic picture settings ("Dynamic", "Standard", "Movie" and "Custom") that are preset at the factory. Dynamic, Standard, Movie, or Custom can be activated. Dynamic Standard Movie Custom Custom By using the on-screen menus, the contrast and brightness can be changed to your personal preference.
Page 74 Color MENU → → ENTER → → , → ENTER → Adjusts the picture Color. Tint MENU → → ENTER → → , → ENTER → Adds a natural tone to the display. Color Tone MENU → → ENTER → The color tones can be changed.
Page 75: Digital Nr (Digital Noise Reduction)
Note This function is only enabled if the Color Tone is set to Off. Size MENU → → ENTER → The Size can be switched. 16:9 - Sets the picture to 16:9 wide mode. Zoom 1 - Magnifies the size of the picture on the screen. Zoom 2 - Magnifies the size of the picture more than “Zoom 1”.
Page 76 Note Digital NR function is not available for all resolutions. Film Mode MENU → → ENTER → → ENTER → The Film Mode feature offers you a theater-quality viewing experience. Film Mode is supported in AV, Component (480i / 1080i) and HDMI (480i / 1080i). (In HDMI mode, this function can be available when the input signal is interlaced scan;...
Page 77 The PDP Display has a built-in high fidelity stereo amplifier. Standard Selects Standard for the standard factory settings. Music Selects Music when watching music videos or concerts. Movie Selects Movie when viewing movies. Speech Selects Speech when watching a show that is mostly dialogue (i.e., news). Custom Selects Custom if you want to adjust the settings according to your personal preferences.
Page 78 Emphasizes high frequency audio. Balance MENU → → → ENTER → → , → ENTER Allows you to Adjusts the sound balance between the left and right speakers. Auto Volume MENU → → → ENTER → Reduces the difference in volume control between broadcasters. SRS TS XT MENU →...
Page 79 • • HDMI • MagicInfo • Component Note • MagicInfo can only be enabled when a network box is connected. • The HDMI port and network box cannot be connected at the same time. Language MENU → → → → ENTER → You can choose one of 13 languages.
Page 80 Sleep Timer MENU → → → → ENTER → → Turns the PDP Display off automatically at certain times. Timer1 / Timer2 / Timer3 MENU → → → → ENTER → → ENTER→ [Timer1 / Timer2 / Timer3] → ENTER →...
Page 81 MENU → → → → ENTER → → ENTER → [Holiday Management]→ ENTER → [Add] → , / , → ENTER You can register holidays. • Delete Selected MENU → → → → ENTER → → ENTER → [Holiday Management]→ , → ENTER → → , → ENTER → [Delete Selected] →...
Page 82 Menu Transparency MENU → → → → ENTER → → ENTER Change the transparency of the background of the OSD. High Medium Opaque Safety Lock Change PIN MENU → → → → ENTER → → → [0∼9] → [0∼9] → [0∼9] → [0∼9] The password can be changed.
Page 83 This is the function that locks the OSD in order to keep the current settings or to prevent others from adjusting the settings. Energy Saving MENU → → → → ENTER → → ENTER → This feature adjusts the power consumption of the unit in order to save energy. Note If Energy Saving mode is Off, you can obtain the maximum display brightness.
Page 84 Note When Video Wall is running, the Auto Adjustment, Image Lock, and Size functions are not available. Video Wall does not operate in MagicInfo mode. Video Wall MENU → → → → ENTER → → ENTER → → ENTER → Turns Off/On the Video Wall function of the selected display Off/On.
Page 85 → ENTER → Sets how many parts the screen should be divided horizontally. Five adjustment levels: 1, 2, 3, 4, and 5. Vertical MENU → → → → ENTER → → ENTER → → → → → ENTER → Sets how many parts the screen should be divided vertically. Five adjustment levels: 1, 2, 3, 4, and 5.
Page 86 Safety Screen The Safety Screen function is used to prevent afterimages that may appear when a still picture is displayed on the screen over a long time. • The Safety Screen function scrolls the screen for the specified period of time. •...
Page 87 Sets how many pixels the screen moves vertically. Five adjustment levels: 0, 1, 2, 3, and 4. Time MENU → → → → ENTER → → ENTER → ENTER Set the time interval for performing the horizontal or vertical movement, respectively. Timer Timer MENU →...
Page 88 You can change the Safety Screen Type. Scroll Eraser All White Pattern Period MENU → → → → ENTER → → → ENTER → Use this function to set the execution period for each mode set in the timer. Time MENU →...
Page 89 • Mode-All White, Pattern : 1, 5, 10, 20 30 min Scroll MENU → → → → ENTER → → This function prevents after-images on the screen by moving all the pixels on the PDP ac- cording to a pattern. Use this function when there are remaining after-images or symbols on the screen, especially when you displayed a still image on the screen for a long time.
Page 90: Resolution Select
This function prevents after-images on the screen by changing the color of pixels to white. Use this function when there are remaining after-images or symbols on the screen, especially when you displayed a still image on the screen for a long time. Pattern MENU →...
Page 91 1280 x 768 1360 x 768 1366 x 768 Note Selecting the menu is only allowed when the graphics resolution is set to 1024 x 768 @ 60Hz, 1280 x 768 @ 60Hz, 1360 x 768 @ 60Hz or 1366 x 768 @ 60Hz. Power On Adjustment MENU →...
Page 92 MENU → → → → ENTER → → ENTER → Image Reset MENU → → → → ENTER → → ENTER → Note Available in PC mode only The Reset function is not available when Video Wall is On. Color Reset MENU →...
Page 93: Multi Control
• Component Note • MagicInfo can only be enabled when a network box is connected. • The HDMI port and network box cannot be connected at the same time. Multi Control Assigns an individual ID to the SET. MENU → →...
Page 94 • For MagicInfo in Device mode, moving external devices while booting may cause errors. Set up external devices only if the PDP Display turns on. • Do not unplug the LAN cable used for the network (ex: video display). Otherwise, the program (MagicInfo) may stop.
Page 95 Adjusting the PDP Display You can select an Application to be executed in your computer when Windows starts. 2. Select TCP/IP - step 2 In step 2 of MagicInfo Setup Wizard, you don’t have to go to Network Setting on the desktop to make your settings for TCP/IP.
Page 96 Adjusting the PDP Display When using multiple languages, you can choose and set a specific language among them. 4. Select Screen Type - step 4 You can select which rotation type will be applied to your device. 5. Setup Information...
Page 97 Adjusting the PDP Display Shows the settings that have been selected by the user. Note If the MagicInfo icon is not displayed on the notification area, double click the MagicInfo icon on the window desktop. The icon will appear.
Page 98: Troubleshooting
Troubleshooting Self-Test Feature Check Note Check the following items yourself before calling for assistance. Contact a Service Center for problems that you cannot solve by yourself. Self-Test Feature Check Turn off both your computer and the PDP Display. Unplug the video cable from the back of the computer. Turn on the PDP Display.
Page 99: Symptoms And Recommended Actions
2) Maintaining the Flat Panel Display Screen. Clean with a soft cloth (cotton flannel) smoothly. Symptoms and Recommended Actions Note A PDP Display recreates visual signals received from the computer. Therefore, if there is a problem with the computer or the video card, this can cause the PDP Display to become blank, have poor coloring, become noisy, and video mode not supported, etc.
Page 100: Problems Related To The Screen
Check if the signal cable between the computer and the PDP Display is securely con- nected. (Refer to Connecting a Computer) Problems related to the Screen Note Problems related to the PDP Display screen and their solutions are listed. The screen is blank and the power indicator is off. Ensure that the power cord is firmly connected and the PDP Display is on.
Page 101: Problems Related To Audio
The screen color is inconsistent. Adjust color using Custom under OSD Color Adjustment menu. The color image is distorted by dark shadows. Adjust color using Custom under OSD Color Adjustment menu. The color white is poor. Adjust color using Custom under OSD Color Adjustment menu. The Power Indicator blinks.
Page 102 Check if the batteries are empty. Check if the power is on. Check if the power cord is securely connected. Check if a special fluorescent or neon lamp is on in the vicinity. Q & A How can I change the frequency? The frequency can be changed by reconfiguring the video card.
Page 103 Troubleshooting Note Before calling for assistance, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the In- formation section or contact your dealer.
Page 104: Specifications
P50HP-2 P63FP, P63FP-2 Maximum Pixel Clock SyncMaster P50HP, P50HP-2 SyncMaster P50HP, P50HP-2 SyncMaster P63FP, P63FP-2 50 " Diagonal (126 cm) 63 " Diagonal (160 cm) 1105.65 mm (H) X 622.08 mm (V) 1393.92 mm (H) X 784.08 mm (V) 0.81 mm (H) X 0.81 mm (V) 0.726 mm (H) x 0.726 mm (V)
Page 105 Dimensions (W x H x D) / Weight SyncMaster 1204.6 x 724.1 x 97.1 mm / 47.4 x 28.5 x 3.8 inch / 32.0 kg / P50HP, P50HP-2 70.6 lbs SyncMaster 1503.5 x 894.0 x 99.4 mm / 59.2 x 35.2 x 3.9 inch / 52.0 kg / 114.6 lbs...
Page 106: Preset Timing Modes
However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows. Normal Opera- Power saving tion P50HP, The power P50HP-2 consumption may differ de- pending on the region.
Page 107 VESA, 1280 x 1024 63.981 VESA, 1280 x 1024 79.976 VESA, 1360 x 768 47.712 (P50HP, P50HP-2) VESA, 1920 x 1080 66.587 (P63FP, P63FP-2) Horizontal Frequency The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Hor- izontal Cycle is called the Horizontal Frequency.
Page 108: For Better Display
You can have an uneven picture quality on screen if the best picture quality is not provided for PDP. • Resolution: 1360 x 768(P50HP, P50HP-2) Resolution: 1920 x 1080(P63FP, P63FP-2) •...
Page 109 Power Off, Screen Saver, or Power Save Mode • Turn the power off for 4 hours after 20 hours in use • Turn the power off for 2 hours after 12 hours in use • Set the Monitor to power off with the PC Display Properties Power Scheme. •...
Page 110 • Use Bright colors with little difference in luminance. - Cycle : Change the characters color and background color every 30 minutes • Every 30 minutes, change the characters with movement. • All area display Moving image together with Logo periodically. - Cycle: Display moving image together with Logo for 60 seconds after 4 hours in use.
Page 111 Note ( Please check CD's User Guide at "OSD Function", some model's will not availa- ble. ) Apply the Screen Erasing function on Product • Apply the Screen Erasing function - Symptom: 2 Vertical blocks move with erasing the display Note ( Please check CD's User Guide at "OSD Function", some model's will not availa- ble )
Page 112 Appendix Contact SAMSUNG WORLDWIDE Note If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. U.S.A CANADA MEXICO ARGENTINA BRAZIL CHILE COLOMBIA COSTA RICA ECUADOR EL SALVADOR GUATEMALA HONDURAS JAMAICA NICARAGUA PANAMA PUERTO RICO REP.
Page 113 POLAND 0 801 1SAMSUNG(172678) 022-607-93-33 PORTUGAL 80820 (7267864) SLOVAKIA 0800 - SAMSUNG(726-7864) http://www.samsung.com SPAIN 902 - 1 - SAMSUNG (902 172 678) SWEDEN 0771 726 7864 (SAMSUNG) http://www.samsung.com SWITZERLAND 0848 - SAMSUNG (7267864, CHF 0.08/min) 0845 SAMSUNG (7267864) ARMENIA 0-800-05-555...
Page 114 3030 8282 http://www.samsung.com 1800 110011 1800 3000 8282 1800 266 8282 0800-112-8888 http://www.samsung.com 021-5699-7777 0120-327-527 http://www.samsung.com 1800-88-9999 http://www.samsung.com 0800 SAMSUNG (0800 726 http://www.samsung.com 786) 1-800-10-SAMSUNG http://www.samsung.com (726-7864) 1-800-3-SAMSUNG (726-7864) 1-800-8-SAMSUNG (726-7864) 02-5805777 1800-SAMSUNG(726-7864) http://www.samsung.com 0800-329-999 http://www.samsung.com 1800-29-3232 http://www.samsung.com...
Page 115: Correct Disposal
Vertical Frequency Horizontal Frequency Interlace and Non-Interlace Methods Plug & Play Resolution SRS TS XT Multiple Display (MDC) Correct Disposal Correct Disposal of This Product (Waste Electrical & Electronic Equipment) - Eu- rope only (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
Page 116 Reproduction in any manner whatsoever without the written permission of Samsung Elec- tronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this ma- terial.
Page 117 Appendix...
