- Page 4 All manuals and user guides at all-guides.com EURODESK MX2442A EURODESK ® Professional, ultra low-noise design 24-channel 4-bus recording & live-mixing console s 24 microphone/line inputs, 16 mono and 4 stereo s Ultra low-noise, discrete microphone preamps with +48 V phantom power and switchable low-cut filter...
-
Page 5: Table Of Contents
6.6 Talkback ............................15 7. CONNECTIONS ........................15 7.1 EURODESK MX2442A Back Panel/Serial Number ................ 15 7.2 EURODESK MX2442A Patchfield and Plug Wiring Scheme ............16 7.3 Audio Connections ........................16 8. SETTING UP ......................... 18 8.1 Selecting Inputs ..........................18 8.2 Initializing Channels for Gain Setting ..................... -
Page 6: The Manual
EURODESK MX2442A 1. THE MANUAL Thank you for expressing your confidence in us by purchasing the EURODESK MX2442A. Our first task in writing this manual is to make you feel comfortable with the special terms that are used to describe your EURODESK MX2442A and its proper use. -
Page 7: Metering
All manuals and user guides at all-guides.com EURODESK MX2442A The configuration is 24 into 4 into 2. This means that there are 24 channel inputs in total (there are 16 mono and four stereo channels), assignable to four subgroup buses (plus the main mix) which in turn may be blended into the main mix stereo output. -
Page 8: Power Supply Unit (Psu)
All manuals and user guides at all-guides.com EURODESK MX2442A 2.3 Power Supply Unit (PSU) In common with most desks of this size, the EURODESK has several hundreds of line level operational amplifiers (op-amps) inside. When being driven hard, many desks begin to show signs of stress due to power supply limitations. -
Page 9: Equalizer
3.4 Routing & Muting Routing means selecting which bus you want a channel to address. There are three stereo buses in the EURODESK MX2442A (plus a stereo solo bus). Main mix and the subgroups are selected via the assign switches . -
Page 10: Stereo Input Channels
All manuals and user guides at all-guides.com EURODESK MX2442A 4. STEREO INPUT CHANNELS The stereo input channel consists of almonst the same controls as the mono input channel except for the input, the EQ and the BALANCE control. For further information on the remaining controls, please refer to section 3 “MONO INPUT CHANNELS”. -
Page 11: Subgroups And Inserts
All manuals and user guides at all-guides.com EURODESK MX2442A 5. SUBGROUPS AND INSERTS 5.1 Subgroups The principal routes to multitrack are via the subgroup outputs. There are four mono (or two stereo) subgroups. All channels can access all of them, as can aux returns 1 and 2 ( &... - Page 12 All manuals and user guides at all-guides.com EURODESK MX2442A Please note that we didn’t draw the ground/screen connection in the following graphics to keep them as simple as possible. If you want to insert an external EQ or dynamics processor post-EQ, a subgroup insert should be used as follows: Fig.
-
Page 13: Main Section
All manuals and user guides at all-guides.com EURODESK MX2442A EURODESK insert points are, of course, simultaneously inputs and outputs. For goodness sake, get them onto a patchbay, where they can appear as independent sockets, and do away with all these fiddly Y-connectors that always seem to be the first to get knotted in the flightcase. -
Page 14: Monitoring
This is fine for a MIDI suite with overdub booth, but for the bigger studio’s headphone network using a separate headphones distribution amplifier like the BEHRINGER POWERPLAY PRO HA4600 is recommended: This allows independent level and EQ-settings for four headphone mixes; a total of 12 headphones can be connected. -
Page 15: Talkback
If the unit is damaged, please do not return it to BEHRINGER, but notify your dealer and the shipping company immediately, otherwise claims for damage or replacement may not be granted. -
Page 16: Eurodesk Mx2442A Patchfield And Plug Wiring Scheme
All manuals and user guides at all-guides.com EURODESK MX2442A 7.2 EURODESK MX2442A Patchfield and Plug Wiring Scheme Most of the inputs (inserts being the major exception) are balanced. Unbalanced equipment may be connected to balanced inputs/outputs. Either use mono 1/4"... - Page 17 All manuals and user guides at all-guides.com EURODESK MX2442A Fig. 7.1: Different plug types 7. CONNECTIONS...
-
Page 18: Setting Up
All manuals and user guides at all-guides.com EURODESK MX2442A 8. SETTING UP 8.1 Selecting Inputs 1) Mono channels accept mic or line level inputs. If you are using the mic input, make sure nothing is connected to the line input (and vice-versa). Please note that mic inputs are many times more sensitive than line inputs! Do not connect mics with phantom power switched on. -
Page 19: Desk Normalization
(You can always bounce tracks though the outboard EQ, freeing up the unit for the next task). Check out our BEHRINGER ULTRA-CURVE PRO DSP8024, which promises to be another price/performance buster. -
Page 20: Gain Optimization
(FX GAIN TOO HIGH), and the same goes for a high noise level (FX GAIN TOO LOW). Noisy FX (or synth) returns can be greatly improved by the addition of single-ended noise reduction between FX output and aux (or channel) returns. The BEHRINGER DENOISER SNR2000 is ideally suited for this purpose. -
Page 21: Modifications
10. MODIFICATIONS The following modifications require some knowledge in soldering. Only attempt that if you are experienced in using an iron on PCBs. Otherwise, refer to qualified personnel. After modification the BEHRINGER warranty becomes discretionary. Links should not be threaded into holes on the PCB. They should be soldered to the tinned areas around the holes, and bowed slightly upwards in between. -
Page 22: Specifications
7 kg BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or shown. -
Page 23: Warranty
5. Any repair or opening of the unit carried out by unauthorized this warranty as described under § 3 and 4, BEHRINGER shall, at personnel (user included) will void the warranty.
