TV Clear Set
True wireless TV earbuds
Model: TVCE1-EB, TVCE1
Transmitter
Model: TV Connector
Instruction manual
Use the search function, the navigation (left) or the following links:
Start
"The Sennheiser TV Clear Set"
"Product overview"
"Getting started"
"Daily use"
"FAQ/If a problem occurs ..."
"Specifications"
Sonova Communications AG
Herrenschwandweg 4
3280 Murten
Switzerland
www.sennheiser-hearing.com
Version: 05/22 A01
Advertisement
Table of Contents
Related Manuals for Sennheiser TV Clear TVCE1-EB
Summary of Contents for Sennheiser TV Clear TVCE1-EB
- Page 1 Model: TVCE1-EB, TVCE1 Transmitter Model: TV Connector Instruction manual Use the search function, the navigation (left) or the following links: Start “The Sennheiser TV Clear Set” “Product overview” “Getting started” “Daily use” “FAQ/If a problem occurs ...” “Specifications” Sonova Communications AG...
-
Page 2: Important Safety Instructions
Dispose of electrical components in accordance with your local regulations. Hazard warnings for TV Clear Earbuds ▷ External devices may only be connected if they have been tested in accordance with the relevant standards IEC 62368-1 or other applicable safety standards. 2 | Sennheiser TV Clear Set... - Page 3 ▷ If you feel pain in or behind your ear, if it is inflamed or if skin irri- tation and accelerated accumulations of earwax occur, please check with your hearing care professional or physician. Sennheiser TV Clear Set | 3...
- Page 4 Hazard warnings for transmitter „TV Connector“ ▷ External devices may only be connected if they have been tested in accordance with corresponding safety standards. Only use accessories approved by Sonova Communications AG. 4 | Sennheiser TV Clear Set...
-
Page 5: Notes On Data Collection And Processing And On Firmware Updates
“Privacy” section of the app menu. Using the “Sennheiser TV Clear” app, you can update the firmware of the product for free via an Internet connection. If the device on which... - Page 6 Sonova Communications AG is not liable for damages resulting from the loss of connection due to flat or overaged rechargeable batteries or exceeding the Bluetooth/ 2.4 GHz transmission range. Before putting the products into operation, please observe the respective country-specific regulations. 6 | Sennheiser TV Clear Set...
- Page 7 Best results are achieved when using the earbuds in line of sight to the connected device. If the audio transmission is interrupted, reduce the distance and avoid obstacles in between. Sennheiser TV Clear Set | 7...
-
Page 8: Package Contents
(size 1, 2 (pre-mounted to the earbuds) and 3) Transmitter „TV Connector“ Transmitter (model: TV Connector) USB power cable with USB-Micro-B and USB-A connector Analog 3.5 mm audio cable Optical (TOSLINK) audio cable General Quick guide Safety guide 8 | Sennheiser TV Clear Set... - Page 9 Package contents Online you can find: • Frequently Asked Questions (FAQ): www.sennheiser-hearing.com/tv-clear-faq • The Sennheiser TV Clear app for configuring the headphones and for additional functions: – Google Play store: click – Apple App store: click • Additional information (like this user manual, spec sheet): www.sennheiser-hearing.com/download...
-
Page 10: Product Overview
Retention for secure hold Size (1-3) and left (L) / right (R) marking Dome The default voice prompt language is English. This – and other configurations – can be adjusted with the Sennheiser TV Clear app. 10 | Sennheiser TV Clear Set... - Page 11 Product overview Charging case Model: TVCE1 Charging contacts left earbud Charging contacts right earbud Battery indicator light right earbud Battery indicator light case Battery indicator light left earbud USB-C charging socket Pairing button Sennheiser TV Clear Set | 11...
- Page 12 Micro-B-USB power port Audio port for: • Optical (TOSLINK) audio cable • Analog 3.5 mm audio cable Overview of the indicator light Indicator light Transmitter lights up ... is ON green ... is OFF 12 | Sennheiser TV Clear Set...
-
Page 13: Getting Started
3. Connecting the earbuds the transmitter TV Connector ▷ If you purchased the products in the Set, the earbuds will now automatically connect to the transmitter when taken out of the charging case (> 19). Sennheiser TV Clear Set | 13... - Page 14 (> 21). 6. Installing the TV Clear app on your smart- phone The Sennheiser TV Clear app allows you to use all functions and set- tings of the earbuds (> 26). • Apple App store: click •...
- Page 15 Best audio transmission is ensured with the digital optical audio con- nection. OPTICAL ANALOG Digital signal 3.5 mm audio cable fiber optic cable Ensure the chosen audio cable is firmly inserted into both the transmitter and the audio source. Sennheiser TV Clear Set | 15...
- Page 16 TV to turn on the TV loudspeakers again. Connecting the TV Clear earbuds with the transmitter ▷ Follow the steps in the chapter “Connecting your earbuds to the transmitter „TV Connector“” (> 19). 16 | Sennheiser TV Clear Set...
- Page 17 4. Leave the earbuds in the case and continue to “Connecting your earbuds to your phone (or tablet)” (> 18) or “Connecting your ear- buds to the transmitter „TV Connector“” (> 19). Sennheiser TV Clear Set | 17...
- Page 18 1. Open the “Bluetooth” settings and activate Bluetooth on your phone. 2. Wait until you see the „Sennheiser TV Clear“ in the list of available devices and select it. 3. Your phone will now connect to the earbuds and the indicator lights of the charging case will stop blinking.
- Page 19 • To connect manually, go to your devices Bluetooth menu, select “Sennheiser TV Clear” from the list or short press either of the earbud buttons while wearing them. Sennheiser TV Clear Set | 19...
- Page 20 The size of the adapter may be different for the left and right ear. Make sure the left and right side of the adapter and earbud are aligned (L= left side, R = right side). 20 | Sennheiser TV Clear Set...
- Page 21 Select the correct side for insertion into your ear. 1. With the dome pointing to your ear canal and downward, gently insert the earbud. 2. Rotate the retention until it sits firmly and comfortably in the bowl of the ear. Sennheiser TV Clear Set | 21...
-
Page 22: Daily Use
2. When removing the earbuds from the case they will connect to the phone automatically within 12 seconds. 3. This is indicated in the phones status screen or the Bluetooth menu (exact details may depend on your phone model) 22 | Sennheiser TV Clear Set... - Page 23 The default configuration on the right earbud is Ambient Aware- ness function Off/On and on the left earbud Pause/Resume play- back. Controls only are active when the earbud is inserted into the ear correctly. Sennheiser TV Clear Set | 23...
- Page 24 Making a phone call To make a hands-free phone call, ensure the earbuds are connected to the phone and correctly inserted into your ears (> 18 and 21). Call 24 | Sennheiser TV Clear Set...
- Page 25 When putting the primary back to the charging case, they switch role and the other earbud will become the primary. The switch between primary earbuds can take up to 5 seconds and you may hear an interruption. This is normal. Sennheiser TV Clear Set | 25...
- Page 26 • The configurations of the double tap function can be changed with the TV Clear app. Using the Sennheiser TV Clear app We recommend to benefit from the Sennheiser TV Clear app. It offers many advantages such as: • Earbuds stay up-to-date with the latest firmware.
- Page 27 • Bluetooth will disconnect when earbuds are placed into the case. When not in use it is recommended to store the earbuds safely in the case. Ensure the charging contacts are free of dirt and debris. Sennheiser TV Clear Set | 27...
- Page 28 • Placing the earbuds into the charging case. • Opening or closing the lid of the charging case. • Plugging the power cable into a power source. • When placing on a wireless Qi-charging pad. 28 | Sennheiser TV Clear Set...
- Page 29 The indicator lights will dim after 10 seconds if the lid is closed. Spoken voice messages will inform about the remaining bat- tery when earbuds are being worn. State of charge is also displayed in the Sennheiser TV Clear app. Cleaning the ear adapter Over time, earwax can accumulate in the earbud silicone adapter.
- Page 30 To download the app please refer to the links provided in “Using the Sennheiser TV Clear app” (> 26). The app will automatically detect whether there is an new version available.
- Page 31 The earbuds are reset to factory default settings, indicated by orange blinking indicator lights. Hold Press All 3 LEDs After factory reset you must perform the pairing process again as described in “Put the earbuds into pairing mode” (> 17). Sennheiser TV Clear Set | 31...
- Page 32 Adjust the audio delay time (reduce the compared to the streamed audio source speakers is delay) in the audio settings menu of your audio in the TV Clear ear- too high audio source buds 32 | Sennheiser TV Clear Set...
-
Page 33: Specifications
< 90% Weight earbuds: approx. 7 g each charging case: approx. 50 g both earbuds and charging case: 64 g Bluetooth Version Bluetooth 4.2 compatible, class 1 Transmission frequency 2,402 MHz to 2,480 MHz Sennheiser TV Clear Set | 33... - Page 34 63 x 63 x 12 mm (2.5” x 2.5” x 0.46“) Weight approx. 30 g Temperature range operation: 0 to +40°C (+32°F to +104°F). storage: -20 to +60°C (-4°F to +140°F). Relative humidity, non operation: < 90% condensing storage: < 90% 34 | Sennheiser TV Clear Set...
-
Page 35: Manufacturer Declarations
TV Connector) is in compliance with the essential requirements of the Radio Equipment Directive 2014/53/EU. To obtain a copy of the declaration of conformity please visit: www.sennheiser-hearing.com/download UK declaration of conformity • RoHS Regulations (2012) • Radio Equipment Regulations (2017) Sennheiser TV Clear Set | 35... - Page 36 The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sonova AG is under license. Other company and product names mentioned herein are trade- marks of their respective owners. 36 | Sennheiser TV Clear Set...
